Operation

1
Operating the tool
This Spline Drive Tool is designed to operate on 90 PSIG.
Lower pressure (below 90 PSIG) will reduce performance
of the tool. Higher air pressure (over 90 PSIG) raises the
performance of the tool beyond its rated capacity and
could cause serious damage to tool and user.
3
Removing the drill attachment
WARNING: Disconnect tool from air supply before servicing
or changing accessories.
To remove the drill attachment:
Remove the air supply from the tool.
Loosen knurled nut to remove drill attachment.
Universal Tool a Division of Florida Pneumatic Mfg. Corp.
851 Jupiter Park Lane, Jupiter FL 33458
2
Installing drill attachment
WARNING: Disconnect tool from air supply before servicing
or changing accessories.
To install the drill attachment:
Remove the air supply from the tool.
Insert the drill attachment as far as possible into the
attachment position.
Tighten knurled nut to secure drill attachment.
4
Chaning drill bits
WARNING: Disconnect tool from air supply before servicing
or changing accessories.
With tool disconnected from air supply, use pin part
# 9389358 to lock spindle. Once spindle is locked drill bits
can be threaded or unthreaded.
