Operation

1
Operating the ratchet wrench
□ This Ratchet Wrench is designed to operate on 90 PSIG.
Low pressure (below 90 PSIG) will reduce the power
output. Higher pressure (over 90 PSIG) raises the tool
performance beyond its rated capacity and could result in
serious damage to the tool and/or operator.
3
Installing and removing the sockets
WARNING: Disconnect the tool from air the supply before
servicing or changing accessories.
To install the sockets:
□
Disconnect the tool from the air source.
□
Select the suitable and desirable socket size.
□
Press fit the anvil into the socket.
To remove the impact socket:
□
Disconnect the tool from the air source.
□
Use your hand or suitable tool to remove the socket.
Universal Tool a Division of Florida Pneumatic Mfg. Corp.
851 Jupiter Park Lane, Jupiter FL 33458
2
Changing the output torque direction
□ This tools features the reverse switch to change the
output torque direction to tighten (assemble) or loosen
(disassemble) the bolt or fastener. Control the output torque
direction by turning the reverse switch to the F (Forward)
or R (Reverse) position to change the direction.
4
Tightening or loosening the bolt or
fastener
□ Fit the socket in.
□ Hold the ratchet wrench with one hand.
□ Use the tool to tighten or loosen the bolt or fastener.
