ASSEMBLY INSTRUCTIONS FOR ACME FURNITURE
Thank you for purchasing the quality product. Be sure to check all packing material carefully for small parts which may
have come loose inside the carton during shipment. Separate, identify and count all parts and metal hardware. Compare
with all parts list to be sure all parts are present. If any part (s) are missing or damaged, please contact your local furniture
dealer. For efficient and speedy service, please indicate the model number and code letter of part (s) needed.
***Do not fully tighten bolts and screws until fully assembled***
PART LIST :
PART# DESCRIPTION
1 Headboard
1
2 Headboard Support
2 3 Footboard
4 Ear Panel
3
5 Ear Panel Support
6 Side Rail
7 Slat with 3 holes
4
8 Leg Support
9 Bed Leg
3
Attention:
*** Some number parts listed on the instruction sheet may not be in parts bag as they may already be assembled.
Carefully check parts and packing materials prior to ordering replacements.
MODEL #BD 01183 Q
HARDWARE LIST :
NO
QTY
A
1
B
2
C
1
D
2
E
2
2 F
5 G
5 H
I
2
J
K
4
8
7
9
DESCRIPTION
Allen Key With Ball
JCBC Bolt M6 x 20mm
JCBC Bolt M6 x 40mm
JCBC Bolt M6 x 60mm
CSK Screw M4 x 32mm
CSK Screw M4 x 45mm
Adjuster
Spring Washer M6
Flat Washer Medium M7 x 19 x 2.0
Flat Washer Large 3/8 x 25 x 1.0
L- Bracket (150 x 40 mm)
5
6
QTY
1
16
13
6
10
4
5
30
30
14
4
1
2
Revised Date: 05 OCT 2022
PAGE 1 OF 5
