Clevetronics L10 LUBPRO-SM-UPS Assembly, Installation & Maintenance Instructions

Testing:
Once connected to the 240V UPS backup mains supply, ensure the UPS unit has been allowed to charge.
Conduct the following tests:
• For the first test, the lamp must remain illuminated for at least 2 hours after disconnection from the
mains supply with the UPS running from the battery.
Subsequent tests require the unit to illuminate for at least 90 minutes. The results of all tests are
•
required to be recorded in a service logbook, which is to be kept on-site at all times. If the unit fails to
remain illuminated for the requisite time, remedial action must be taken to repair the situation and
once completed, the unit must pass a subsequent test. For more specific information, please refer to
the current edition of the AS 2293.3 Standard.
Ultrablade Maintenance:
LED Lamp Replacement:
Use only the LED Strip recommended in the
•
Spares Parts list of this instruction.
Remove the screw holding the driver PCA.
•
Remove the PCA.
• Remove the 4 screws holding the battery
bracket. Remove the bracket.
• Disconnect the signal cable from LED strip.
• Remove 4 self-tapping screws and unclip the
LED strip.
• Install the new LED strip following the above
procedure in reverse.
Rated Emergency Lumen Output in accordance with AS2293.1, not applicable
for –TH (theatre) version (refer to spacing tables for installation positions):
Refer to the Technical Label for classification information.
Warranty:
For Product Warranty information and Terms and Conditions of Sales please refer to our website
http://clevertronics.com.au/terms-conditions-sale-australia-nz/
Trouble Shooting:
Below are a list of common problems and their
possible causes.
Fault: The Status LED indicator and main
lamp is not illuminated.
Check: A.C. is connected and is turned on.
Fault: Lamp does not illuminate in
emergency mode.
Check: A.C. is connected.
Lamp is correctly inserted.
UPS battery condition.
L10 ™ Ultrablade Pro Surface Mount LED Exit
Uninterrupted Power Supply
Installation & Maintenance Instruction Leaflet
Designed in Australia to comply with the requirements
of AS2293.3: 2005 and AS/NZS CISPR15: 2017
Models:
LUBPRO-SM-UPS Premium Ultrablade Pro Surface Mount LED Exit - UPS
LUBPRO-SM-DALI-UPS DALI Ultrablade Pro Surface Mount LED Exit - UPS
LUBPRO-SM-DALI-BLK-UPS DALI Ultrablade Pro Surface Mount Black LED Exit - UPS
Spare Parts:
8002178 – PCA: UBP LED strip PCB Assy
8002343 – PCA: LUBPRO CT10142-L9 6C40 UPS
Important:
It is illegal for anyone, except for a licensed electrician to install or maintain this product. Before installation,
ensure that the electricity supply has been switched off and isolated. Installation must be carried out in
accordance with the relevant Australian and International Standards.
Victoria (Head Office & Manufacturing)
Website: www.clevertronics.com.au
Email:
info@clevertronics.com.au
Phone: +61 3 9559 2700
Fax: +61 3 9559 2799
New South Wales
Phone: +61 2 8805 6400
Fax: +61 2 8805 6444
Queensland
Phone: +61 7 3442 9700
Fax: +61 7 3442 9777
South Australia/Northern Territory
Phone: +61 8 8301 8800
Fax: +61 8 8351 8286
Western Australia
Phone: +61 8 9207 0000
Fax: +61 8 9207 0088
New Zealand
Phone: +64 800 548 448
1942413 V1.1 7 September 2021
