- Page 1 Model M3628UCT Ultracapacitor Cell Tester Customer Reference Manual ● ● Web: www.bonitron.com Tel: 615-244-2825 Email: info@bonitron.com...
- Page 2 Bonitron has seen thousands of products engineered since 1962 and welcomes custom applications. With engineering, production, and testing all in the same facility, Bonitron is able to ensure its products are of the utmost quality and ready to be applied to your application.
- Page 3 RIVE PTIONS In 1975, Bonitron began working with AC inverter drive specialists at synthetic fiber plants to develop speed control systems that could be interfaced with their plant process computers. Ever since, Bonitron has developed AC drive options that solve application issues associated with modern AC variable frequency drives and aid in reducing drive faults.
- Page 4 M3628UCT This page intentionally left blank.
-
Page 5: Table Of Contents
4.4.2. Main Menu ........................... 18 Figure 4-3: M3628UCT Example Test Cycle ................18 Figure 4-4: M3628UCT Example Measurement Stage ............19 Figure 4-5: M3628UCT Example V-I Curve and Operating Area ........... 20 4.5. Faults 22 4.5.1. Over-Current ........................22 4.5.2. Over-Voltage ........................22 4.5.3. - Page 6 M3628UCT 4.5.5. Timeout ..........................23 5. T ........................24 ROUBLESHOOTING Table 5-1: Troubleshooting ....................... 25 6. E ........................27 NGINEERING 6.1. Ratings Chart ..........................27 Table 6-1: Ratings Chart ......................27 Table 6-2: Dimensions ......................27 7. A .......................29 PPLICATION OTES 7.1. Typical Capacitor Testing Procedure ..................29...
-
Page 7: Introduction
URPOSE AND COPE This manual is a user’s guide for the model M3628UCT. It will provide the user with the necessary information to successfully connect and operate the M3628UCT. In the event of any conflict between this document and any publication and/or documentation related to any associated hardware (capacitor bank, etc.), the latter... -
Page 8: Symbol Conventions Used In This Manual And On Equipment
M3628UCT 1.4. YMBOL ONVENTIONS SED IN THIS ANUAL AND ON QUIPMENT Earth Ground or Protective Earth AC Voltage DC Voltage DANGER: Electrical hazard - Identifies a statement that indicates a shock or electrocution hazard that must be avoided. DANGER! DANGER: Identifies information about practices or circumstances that can lead to personal injury or death, property damage, or economic loss. -
Page 9: Roduct Escription
Capacitors stored for long periods of time also display chemistry changes, which gradually reduces capacitance and increases ESR. The Bonitron M3628UCT is a portable, digitally controlled DC power supply and capacitor test system with a variable output voltage and current limit. It can perform accurate, informative measurements of an ultra-capacitor’s capacitance and ESR. -
Page 10: Part Number Breakdown
U R R E N T P U T O L T A G E ODEL UMBER The base model number for all Ultra-Capacitor Cell Testers is M3628UCT. UTPUT OLTAGE ATING The Max Output Voltage rating indicates the maximum DC output voltage the unit can supply, which is indicated by a code letter. -
Page 11: General Specifications
User’s Manual 2.3. ENERAL PECIFICATIONS Table 2-3: General Specifications Table ARAMETER PECIFICATION Input Voltage 110-120 VAC 1Ø Test Voltage Range 2.0-20.0VDC Test Current Range 1-30ADC Minimum Test Capacitance Maximum Test Capacitance 6,500F 0.1mΩ Minum Measurable ESR 500mΩ Maximum Measurable ESR Maximum Test Time 90 minutes Controls... -
Page 12: General Precautions And Safety Warnings
M3628UCT ENERAL RECAUTIONS AND AFETY ARNINGS • T HIS UNIT PRODUCES VOLTAGES CAPABLE OF CAUSING INJURY OR DEATH • F OR USE BY QUALIFIED AND TRAINED PERSONNEL ONLY • IMPROPER OPERATION PRODUCT IGNORING THESE WARNINGS RESULT SERIOUS BODILY INJURY OR DEATH! •... -
Page 13: Installation Instructions
NSTRUCTIONS 3.1. NVIRONMENT While closed, the M3628UCT is water, dust, and crush resistant. When open and in operation, the unit should be used only in dry, clean areas. Ensure that the interior of the unit casing is kept dry. 3.2. -
Page 14: Source Considerations
M3628UCT 3.2.2. OURCE ONSIDERATIONS Input voltage should not exceed the rating—120VAC or 240VAC depending on model—or damage to the unit may result. To guarantee correct system operation at all output voltages, the source must be capable of supplying at least 10 amps for 120VAC supply or 5 amps for a 240VAC supply. Failure to meet the minimum current requirement may result in improper operation. -
Page 15: Operation
UNCTIONAL ESCRIPTION The M3628UCT is a digitally controlled DC supply capable of sourcing and sinking 1 to 30 amps between 2 and 20VDC. The unit is powered by standard 50-60 Hz 120VAC/240VAC. The output voltage and current is set by the digital interface panel on the front of the unit. -
Page 16: Dc Output And Measurement Connectors
M3628UCT DC O 4.3.2. UTPUT AND EASUREMENT ONNECTORS Four PowerPole connectors provide the user with DC output voltage between 0 and 20VDC, a charge/discharge path for the current to and from the capacitor being tested, and precision Kelvin measurements for ESR. The standard cables shipped with the system include either two high-current alligator clips or ring terminals, and two measurement clip leads. -
Page 17: Safety Bleeder Resistor
This selection indicator is moved using the up and down buttons. If a line on the menu represents another screen, that screen is accessed with the Enter button. The Cancel button will return the display to the parent screen. See Figure 4-3. Figure 4-2: M3628UCT Interface Screen Tree TEST MENU Adjust Charge... -
Page 18: Status/Idle
The ESR measurement uses a pulse technique and will similarly automatically adjust the current to an appropriate value. Figure 4-3: M3628UCT Example Test Cycle Hold Current (A) Voltage (V) - Page 19 User’s Manual Figure 4-4: M3628UCT Example Measurement Stage Example Measurement Stage Test Current (A) Voltage (V) Hold Time (s) 4.4.2.1.1. HARGE OLTAGE From this screen the user may set the final voltage they wish to charge the load to. The right and left buttons control which digit is presently being edited, and the up and down buttons increment or decrement that digit.
- Page 20 Operating the system in charge mode causes it to behave as a current limited voltage source. An example V-I curve is shown in Figure 4-5 below. Figure 4-5: M3628UCT Example V-I Curve and Operating Area Adjustable Current Limit Fixed Current Limit Voltage (V) 4.4.2.2.1.
- Page 21 User’s Manual 4.4.2.2.2. HARGE URRENT From this screen the user may set the maximum current with which they wish to charge the load. The right and left buttons control which digit is presently being edited, and the up and down buttons increment or decrement that digit.
-
Page 22: Faults
4.5.4. EMPERATURE This fault indicates that at least one of the switching transistors has exceeded a safe operating temperature. If the fault will not clear after allowing time to cool, your unit is likely damaged. Contact Bonitron for service options. -
Page 23: Timeout
User’s Manual 4.5.5. IMEOUT This fault indicates that the system has spent more than 30 minutes in a particular stage. - Page 24 M3628UCT This page intentionally left blank.
-
Page 25: Troubleshooting
ROUBLESHOOTING If a problem occurs on start-up or during normal operation, refer to the problems described below. If a problem persists after following the steps below, contact Bonitron Tech Support, the product supplier or your system integrator for assistance. Repairs or modifications to this equipment are to be performed by Bonitron approved personnel only. - Page 26 • Check the output voltage with a separate voltmeter. If the voltage Red voltage present light never turns on regardless of is above 2VDC, your unit may require service. Contact Bonitron. output voltage Always monitor the output voltage while operating the unit. Ensure that the attached loads do not exceed their rated voltage, as catastrophic damage, injury, or death may occur.
-
Page 27: Engineering Data
User’s Manual 6. E NGINEERING 6.1. ATINGS HART Table 6-1: Ratings Chart Input Voltage 120VAC/240VAC Output Voltage 0 - 20VDC Output Current 0 - 30A Table 6-2: Dimensions Height 9 in. (with top closed) Width 13.9 in. Depth 22.0 in. - Page 28 M3628UCT This page intentionally left blank.
-
Page 29: Application Notes
A short description of how to use the M3628UCT to test a capacitor cell or module is given below. Ensure the capacitor is discharged. - Page 30 M3628UCT If the bank is put into service, test the capacitor bank periodically, on a schedule recommended by the capacitor manufacturer. Ensure that all tests are performed in a similar ambient temperature; otherwise comparison between results may not be valid. If over time the bank capacitance falls below the manufacturer- recommended percentage of the original recorded capacitance, discard and replace the capacitor.
- Page 31 This page intentionally left blank.
- Page 32 D_M3628UCT_CMAN_VALL_00b 6/27/2023 521 Fairground Court ● Nashville, TN 37211 ● USA Tel: (615) 244-2825 ● Fax: (615) 244-2833 ● Web: www.bonitron.com ● Email: info@bonitron.com...
