- Page 1 Model M3628PUT Portable Ultracapacitor Tester Customer Reference Manual ● ● Web: www.bonitron.com Tel: 615-244-2825 Email: info@bonitron.com...
- Page 2 Bonitron has seen thousands of products engineered since 1962 and welcomes custom applications. With engineering, production, and testing all in the same facility, Bonitron is able to ensure its products are of the utmost quality and ready to be applied to your application.
- Page 3 RIVE PTIONS In 1975, Bonitron began working with AC inverter drive specialists at synthetic fiber plants to develop speed control systems that could be interfaced with their plant process computers. Ever since, Bonitron has developed AC drive options that solve application issues associated with modern AC variable frequency drives and aid in reducing drive faults.
-
Page 4: Table Of Contents
Power Switch / Circuit Breaker ....................16 4.3. Screens & Menu Navigation ....................16 4.3.1. Main Menu ..........................16 Figure 4-1: M3628PUT Charging Profile ................... 17 Figure 4-2: M3628PUT Interface Screen Tree ................... 18 4.4. Faults ..........................20 4.4.1. Overtemp ............................. 20 4.4.2. - Page 5 Table of Contents 6.1. Ratings Chart ........................... 23 Table 6-1: Ratings Chart ........................23 6.2. Dimensional Drawing ......................23 Figure 6-1:M3628PUT Dimensions ....................23 6.3. Block Diagram ........................23 Figure 6-2: Block Diagram ......................... 23 7. A ..........................25 PPENDIX 7.1. Application Notes ........................25 7.1.1.
- Page 6 M3628PUT This page intentionally left blank...
-
Page 7: Introduction
URPOSE AND COPE This manual is a user’s guide for the Model M3628PUT. It will provide the user with the necessary information to successfully connect and operate the M3628PUT. In the event of any conflict between this document and any publication and/or documentation related to any associated hardware (capacitor bank, etc.), the latter... -
Page 8: Symbol Conventions Used In This Manual And On Equipment
M3628PUT 1.4. YMBOL ONVENTIONS SED IN THIS ANUAL AND ON QUIPMENT Earth Ground or Protective Earth AC Voltage DC Voltage Electrical Hazard - Identifies a statement that indicates a shock or electrocution hazard that must be avoided. DANGER! DANGER: Identifies information about practices or circumstances that can lead to personal injury or death, property damage, or economic loss. -
Page 9: Product Description / Features
User’s Manual RODUCT ESCRIPTION EATURES The M3628PUT is designed for testing of ultracapacitors. As ultracapacitors age and wear, their capacitance decreases, and their ESR increases. This can result in decreased system performance, and ultimately, process failure. Measurement of an ultracapacitor's capacitance and ESR can help avoid expensive preemptive replacement. -
Page 10: Part Number Breakdown
U R R E N T N P UT O LT AG E ODEL UMBER The Base Model Number for all Portable Ultracapacitor Testers is M3628PUT. UTPUT OLTAGE ATING The Maximum Output Voltage Rating indicates the DC output voltage the unit can supply. -
Page 11: General Precautions And Safety Warnings
IMPROPER OPERATION PRODUCT IGNORING THESE WARNINGS RESULT SERIOUS BODILY INJURY OR DEATH! B M3628PUT EFORE CONNECTING THE TO A CAPACITOR BANK ENSURE THAT THE BANK IS FULLY DISCHARGED BY CHECKING WITH A VOLTMETER ELECTROCUTION C M3628PUT’ ONNECTING THE... - Page 12 M3628PUT This page intentionally left blank...
-
Page 13: Nstallation Nstructions
NSTRUCTIONS 3.1. NVIRONMENT While closed, the M3628PUT is water, dust, and crush resistant. When open and in operation, the unit should be used only in dry, clean areas. Ensure that the interior of the unit casing is kept dry. 3.2. -
Page 14: Source Considerations
3.2.3. ONSIDERATIONS To ensure the most accurate possible measurements, the capacitor under test should be charged to its full rated voltage. Note that the M3628PUT will discharge the attached load capacitor to 2VDC. This unit is thus not recommended for use on ultracapacitors rated at less than 5VDC. -
Page 15: Operation
UNCTIONAL ESCRIPTION The M3628PUT is a digitally controlled DC supply capable of sourcing between 1 and 7 amps at between 0 and 130VDC. The unit is powered by standard 50-60 Hz AC. The output voltage is controlled by the digital interface panel on the front of the unit. -
Page 16: Voltage Present Indicator
M3628PUT present system activity. In the event the unit is accidentally set to charge to a higher voltage than is safe for one load, this button should be pressed immediately. 4.2.7. OLTAGE RESENT NDICATOR Do not use this light as an indication that the output is safe to work on! - Page 17 User’s Manual Figure 4-1: M3628PUT Charging Profile 4.3.1.1.1. ROFILE INAL OLTAGE From this screen the user may set the final charge voltage. The right and left buttons control which digit is being edited, and the up and down buttons increment or decrement that digit. Enter will save changes.
- Page 18 M3628PUT Figure 4-2: M3628PUT Interface Screen Tree Dwg: 090114 Rev: 20120803...
- Page 19 User’s Manual 4.3.1.1.6. HARGE ROFILE ONFIRM At this screen the user is asked to confirm the Profile settings. Enter will start charging. Cancel will abort charging. 4.3.1.1.7. XECUTING ROFILE This screen displays the present output voltage and current and seconds left for each step. It transitions to the "Discharging" screen (4.3.1.2.6.) when the output voltage reaches the set point and is held for the specified number of seconds.
-
Page 20: Faults
Check the polarity of the leads attached to the ultracapacitor under test. 4.4.4. This fault indicates that the fuse in the charging link of the M3628PUT has failed. Power down the unit and replace the fuse with one of comparable specifications (Section 5.1). -
Page 21: Maintenance And Troubleshooting
If a problem persists after following the steps below, contact the product supplier or your system integrator for assistance. Repairs or modifications to this equipment are to be performed by Bonitron approved personnel only. Any repair or modification to this equipment by personnel not approved by Bonitron will void any warranty remaining on this unit. -
Page 22: Technical Help
M3628PUT 5.3. ECHNICAL If technical help is required, please have the following information available when contacting Bonitron (615-244-2825 or email:info@bonitron.com): Model number of unit Serial number of unit Name of original equipment supplier (if available) Brief description of the application ... -
Page 23: Engineering Data
0-130VDC Output Current 0-7.0A Discharge Resistor .6 Ohm 6.2. IMENSIONAL RAWING Figure 6-1:M3628PUT Dimensions 18.0” 22.0” 10.5” Note: Handle is not included in dimensions and retracts flush with the unit when not needed. 6.3. LOCK IAGRAM Figure 6-2: Block Diagram... - Page 24 M3628PUT This page intentionally left blank...
- Page 25 A short description is below. Ensure the capacitor bank is fully discharged and floated. Apply power to the M3628PUT. Attach the output leads to the capacitor bank directly. If you are forming the capacitors in a drive, ensure that you are directly across the DC bus, not attached through the braking circuit.
- Page 26 M3628PUT connecting the load. Record the calculated capacitance and ESR somewhere safe, along with the designation of the capacitor being tested. Multiple tests may be performed if desired, to ensure repeatability. Once the procedure is completed successfully, the capacitor bank or equipment can be returned to storage or put into use, as appropriate.
- Page 28 D_M3528PUT_CMAN_VALL_01a 04/07/2014 521 Fairground Court ● Nashville, TN 37211 ● USA Tel: (615) 244-2825 ● Fax: (615) 244-2833 ● Web: www.bonitron.com ● Email: info@bonitron.com...
