- Page 1 Browan Communications Inc. No.15-1, Zhonghua Rd., Hsinchu Industrial Park, Hukou, Hsinchu, Taiwan, R.O.C. 30352 Tel: +886-3-6006899 Fax: +886-3-5972970 Document Number BQW_02_0030.002 Femto Lite Indoor Gateway User Manual...
-
Page 2: Revision History
Revision History Revision Date Description Author .001 Feb. 09, 2021 First release Gary .002 June. 06, 2021 Update WEB GUI Jason/Joey Power input 5V DC/2A ... -
Page 3: Copyright
The reproduction and distribution of the documentation and software supplied with this product and the use of its contents are subject to written authorization from BROWAN COMMUNICATIONS INC. Trademarks The product described in this document is a licensed product of BROWAN COMMUNICATIONS INC... -
Page 4: Table Of Contents
Package Label ............................. 7 Package Content ..........................7 CHAPTER 3 – USER MANUAL ......................8 3.1 Connect Femto Lite ........................8 3.2 Femto Lite Setting ......................... 8 STEP 1 : Firmware Upgrade ......................10 STEP 2 : SET LORA ........................10... -
Page 5: Chapter 1 - Introduction
Gateway based on the latest LoRaWAN specification. Product Design The dimension of WLRRTES-106 Femto Lite Indoor Gateway is with the dimension of 116 x 91 x 27 mm, and with one LAN port, one Micro-USB port for 5V DC/2A power input, four LED indicators, and one reset button. -
Page 6: Chapter 2 - Hardware Details
Chapter 2 – Hardware Details LED Indicators LED sequence: Power(System), WAN, WiFi, LoRa One Orange, Three Green Solid LED is for static status, blanking means the system is upgrading or active devices linked to the corresponding port Solid On Blinking Power Booting Power ON... -
Page 7: Back Label
Figure 2 – IO Ports Back Label The marking information is located at the bottom of the apparatus. Figure 3 – Back Label... -
Page 8: Package Label
Package Label Item Description Product BOX Brown Box Labeling Model/ MAC/ Serial Number/ Type Approval Package Content Description Quantity Femto Lite IoT Gateway Power adapter (100-240VAC 50/60Hz to 5VDC/2A) Ethernet Cable 1 meter (UTP) -
Page 9: Chapter 3 - User Manual
Chapter 3 – User Manual 3.1 Connect Femto Lite You can connect to the gateway via WiFi interface which the SSID and password are printed on the back label by default. Figure 4 – Back Label The rule of gateway SSID is Femto_Lite-xxxxxx where the last digits are the last 6 digits of the MAC address The PC will fetch the IP address of range 192.168.4.x except 192.168.4.1 assigned... - Page 10 Figure 5 – WEB UI-1 Figure 6 – WEB UI-2 Now you can configure the gateway through the WEB UI.
-
Page 11: Step 1 : Firmware Upgrade
OTA server. The OTA server has to be configured by the python tool. Please contact BROWAN for any support. Click the “Enable” and “Save” buttons to enable the OTA or “Disable” function. - Page 12 Figure 10 – Configure LoRa Setting There are two modes for the LoRa configuration.[Basic Station and Packet Forwarder] Figure 11 – LoRa Mode STEP 2.1 Basic Station mode Select the “LoRa Basics Station” mode. The CUPS server and LNS server have to be configured when the gateway is in the Basic Station mode.
- Page 13 Enable the CUPS server if it is necessary for the network. Type – The certificate type of the CUPS.[Boot/Regular] The gateway will search “Regular” type of certificate for the priority if you select the “Boot” type. It will search “Boot” type of certificate if the gateway can not find the “Regular”...
- Page 14 Figure 15 – LoRa Packet Forwarder mode Configure the Gateway Info/Radio setting/Channel Assignment/LBT Settings for the packet forwarder mode. Figure 16 – Gateway settings Radio Settings – configure the central frequency in Hz.
- Page 15 Figure 17 – Radio settings Channel Assignment – configure the center frequency offset of each channel. Figure 18 – Channel Assignment-1...
- Page 16 Figure 19 – Channel Assignment-2...
-
Page 17: Step 3 : Set Wan
Check “Enable LBT” to enable the LBT setting or uncheck to disable. Figure 20 – LBT Settings Click “Save” to accept or “Cancel” to abort. STEP 3 : SET WAN The gateway support either “Ethernet” or “Wi-Fi” connection as the internet backhaul. Figure 21 –... - Page 18 Figure 22 – WAN connection ETHERNET STATUS – The information of IP address/Subnet Mask/Gateway/DNS. ETHERNET SETTING - Configure the IP address of WAN.[Static IP/DHCP client] Static IP – Setup the IP address/Subnet Mask/Default Gateway/DNS of the static IP. Contact the network administrator for the static IP address information. DHCP –...
- Page 19 Figure 23 – DHCP client STEP 3.2 Wi-Fi Select “Wi-Fi” to be the internet backhaul connection. The gateway WiFi interface is the Access Point by default which SSID is “Femto_Lite-XXXXXX” printed on the back label. The administrator can only access the WEB UI through the Access Point mode to configure the gateway.
- Page 20 MANUAL CONNECT – Specify the remote AP SSID and enter the password if necessary. Click “Join” to accept or “Cancel” to abort. Figure 25 – Wi-Fi manual connection The gateway will scan the nearby access point automatically. Just click the SSID for the WiFi connection.
