Installation &
Operation Manual
BHS-3123 Series
Bariatric Lavatory

Table of Contents

Pre-Installation Information �������������������������������������3
Physical Dimensions ����������������������������������������������4
Rough-In Dimensions ���������������������������������������������5
Mounting Dimensions ���������������������������������������������6
Checking Contents �������������������������������������������������7
Required Installation Supplies �������������������������������� 8
Parts List/Hardware Identification �������������������������� 9
Installation Instructions ���������������������������������������������
Step 1: Pedestal Mounting ������������������������������� 10
Step 2: Drain Assembly #320014 �������������������� 10
Step 3: Basin and Pedestal Assembly ������������� 11
Step 4: Final Assembly ������������������������������������12
Adjustable Mixing Valve Installation ����������������� 13
Care and Maintenance �����������������������������������������14
Drawing ��������������������������������������������������������������������
Exploded-view Detail and BOM ������������������������ 15
Warranty ���������������������������������������������������������������16
MADE IN THE U.S.A.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BHS-3123 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Willoughby Industries BHS-3123 Series

  • Page 1: Table Of Contents

    Installation & Operation Manual BHS-3123 Series Bariatric Lavatory Table of Contents Pre-Installation Information �������������������������������������3 Physical Dimensions ����������������������������������������������4 Rough-In Dimensions ���������������������������������������������5 Mounting Dimensions ���������������������������������������������6 Checking Contents �������������������������������������������������7 Required Installation Supplies �������������������������������� 8 BHS-3123 Parts List/Hardware Identification �������������������������� 9 Installation Instructions ���������������������������������������������...
  • Page 2 (Page left intentionally blank) Bariatric Lavatory Installation & Operation Manual BHS-3123 Series (Page left intentionally blank) Willoughby Industries, Inc. TOLL FREE (800) 428-4065 ● LOCAL (317) 875-0830 ● FAX (317) 875-0837 Rev. 8/2023 www.willoughby-ind.com Page 2...
  • Page 3: Pre-Installation Information

    Flush lines thoroughly to hook-up When installing the Willoughby Industries' BHS-3123 Series Bariatric Lavatory deck systems: Before Step 1 of the installation instructions, ensure that the rough-ins are in the correct location� The valve assembly, including the spray head, MUST NOT BE connected until after all lines have been flushed to remove the small particles of debris that are inherent with new construction projects and all chemicals that are used in flushing are purged from the system.
  • Page 4: Physical Dimensions

    Physical Dimensions- BHS-3123 Bariatric Lavatory Installation & Operation Manual BHS-3123 Series Physical Dimensions- BHS-3123 Willoughby Industries, Inc. TOLL FREE (800) 428-4065 ● LOCAL (317) 875-0830 ● FAX (317) 875-0837 Rev. 8/2023 www.willoughby-ind.com Page 4...
  • Page 5: Rough-In Dimensions

    Rough-In Dimensions- BHS-3123 Bariatric Lavatory Installation & Operation Manual BHS-3123 Series Rough-In Dimensions- BHS-3123 BHS-3123 Plumbing Rough-In Detail Willoughby Industries, Inc. TOLL FREE (800) 428-4065 ● LOCAL (317) 875-0830 ● FAX (317) 875-0837 Rev. 8/2023 www.willoughby-ind.com Page 5...
  • Page 6: Mounting Dimensions

    Mounting Dimensions- BHS-3123 Bariatric Lavatory Installation & Operation Manual BHS-3123 Series Mounting Dimensions- BHS-3123 BHS-3123 Mounting Details Willoughby Industries, Inc. TOLL FREE (800) 428-4065 ● LOCAL (317) 875-0830 ● FAX (317) 875-0837 Rev. 8/2023 www.willoughby-ind.com Page 6...
  • Page 7: Checking Contents

    NOTE: Before beginning installation, all supply, drain and waste piping for the BHS-3123 must be completed according to specified rough-ins. If you have not received rough-in details, please contact Willoughby Industries, Inc. (800) 428-4065 IMPORTANT: These installation instructions cover all of the Willoughby Industries Inc.
  • Page 8: Required Installation Supplies

    • Supply piping • Silicone caulk WARNING: Willoughby Industries does not assume any responsibility for personal injury or damage to equipment due to an improperly installed BHS-3123 Bariatric Lavatory. Willoughby Industries, Inc. TOLL FREE (800) 428-4065 ● LOCAL (317) 875-0830 ● FAX (317) 875-0837 Rev.
  • Page 9: Parts List/Hardware Identification

    Parts List / Hardware Identification Bariatric Lavatory Installation & Operation Manual BHS-3123 Series Parts List / Hardware Identification ITEM DESCRIPTION PART NUMBER FAUCET 900215 LAVATORY BASIN BHS3123-XX* DRAIN ASSEMBLY 320014 PEDESTAL ASSEMBLY S300833 FLAT WASHER, 1/4-20 X 1" O�D� 600650 1/4-20 X 1/2"...
  • Page 10: Installation Instructions

    Installation Instructions Bariatric Lavatory Installation & Operation Manual BHS-3123 Series Installation Instructions Step 1: Pedestal Mounting Parts Supplied: • Pedestal (pre-assembled) Note: Hardware for floor & wall anchoring by others Place pedestal in position using pre-installed concrete floor anchors to locate.
  • Page 11: Step 3: Basin And Pedestal Assembly

    Installation Instructions (cont.) Bariatric Lavatory Installation & Operation Manual BHS-3123 Series Installation Instructions (cont.) Step 3: Basin and Pedestal Assembly Caution: Do not leave basin on the pedestal unsupported, as it may fall and cause damage or personal injury. 1�) Line up the brass threaded inserts on the bottom of the basin with the 4 holes on the top of the pedestal, secure with (4) 1/4-20 x 1/2”...
  • Page 12: Step 4: Final Assembly

    Installation Instructions (cont.) Bariatric Lavatory Installation & Operation Manual BHS-3123 Series Installation Instructions (cont.) Step 4: Final Assembly 1�) Install faucet (use instructions supplied with faucet)� Make all final plumbing connections to the drain and valve inlets. 3�) Test the system for leaks (both supply and waste)�...
  • Page 13: Adjustable Mixing Valve Installation

    Installation Instructions (cont.) Bariatric Lavatory Installation & Operation Manual BHS-3123 Series INSTALLATION INSTRUCTIONS Installation Instructions (cont.) IS-P-e480 HydroGuard T/P Series e480 ® Lavatory Combination Valve Installation Instructions To Install Figure 1 NOTE: Installation should be in accordance with accepted plumbing practices. Flush all piping thoroughly before installa- Outlet tion.
  • Page 14: Care And Maintenance

    Care and Maintenance Bariatric Lavatory INSTALLATION INSTRUCTIONS Installation & Operation Manual INSTALLATION INSTRUCTIONS BHS-3123 Series Care and Maintenance Care and Maintenance Care and Maintenance Solid Surface Care Solid Surface Care Aquasurf ® surfaces may be easily cleaned using conventional cleaning agents such as an ammonia Surfaces may be easily cleaned using conventional cleaning agents such as an ammonia Aquasurf ®...
  • Page 15: Exploded-View Detail And Bom

    Care and Maintenance Bariatric Lavatory Installation & Operation Manual BHS-3123 Series Willoughby Industries, Inc. TOLL FREE (800) 428-4065 ● LOCAL (317) 875-0830 ● FAX (317) 875-0837 Rev. 8/2023 www.willoughby-ind.com Page 15...
  • Page 16: Warranty

    Willoughby Industries, Inc� Willoughby Industries, Inc� shall not otherwise be liable under any indirect damages caused by defects in the repair or replacement thereof�...
