CONTENTS
Unpacking Instructions ........... 2
Package Contents .................. 2
Features & Benefits: 5-in-1....... 3
Setup .................................... 7
5-in-1 Sensor Setup ................ 7
Display Setup ........................ 8
Set the Time, Date & Units ...... 9
Backlight Settings ................... 9
Placement Guidelines ............10
Questions?
0808 234 6244
SAVE THIS MANUAL FOR FUTURE REFERENCE.
Professional Weather Centre
5-in-1 Sensor Installation........ 11
Using the Weather Centre .....12
Rainfall Tracking ...................13
Weather Ticker .....................14
Troubleshooting ....................15
Care & Maintenance.............17
Calibration ...........................17
Specifications........................19
FCC Information ...................19
Customer Support ................ 20
Contact Customer Support at
or visit www.AcuRite.com.
Instruction Manual
model 02085
Advertisement
Table of Contents
Related Manuals for ACU-RITE 02085
Summary of Contents for ACU-RITE 02085
-
Page 1: Table Of Contents
Instruction Manual Professional Weather Centre model 02085 CONTENTS Unpacking Instructions ... 2 5-in-1 Sensor Installation..11 Package Contents ....2 Using the Weather Centre ..12 Features & Benefits: 5-in-1..3 Rainfall Tracking ....13 Features & Benefits: Display..4 Weather Ticker .....14 Setup ........ -
Page 2: Unpacking Instructions
Congratulations on your new AcuRite product. To ensure the best possible product performance, please read this manual in its entirety and retain it for future reference. Unpacking Instructions Remove the protective film that is applied to the LCD screen prior to using this product. -
Page 3: Features & Benefits: 5-In-1
Features & Benefits 5-in-1 SENSOR 5. Temperature & Humidity Sensors 1. Rainfall Collector Funnel (internal) 2. Solar Cell Panel 6. Mounting Point Converts sunlight into power to run 7. Wind Speed Anemometer internal aspirating fan. Internal Aspirating Fan 8. Wind Direction Vane (not shown) 9. -
Page 4: Features & Benefits: Display
Features & Benefits Display... - Page 5 1. Previous 2 Wind Directions 18. Barometric Pressure Arrow icon indicates direction 2. Backlight Button pressure is trending. For momentary backlight and 19. “ “ Button dimmer settings. Changes the rainfall data being 3. Current Wind Speed displayed (#17). 4. Current Wind Direction 20.
- Page 6 Back of Display 02085CUKDI BACK OF DISPLAY 1. Plug-in for Power Adapter 5. CLEAR RECORD / RESET Button Press to clear data recorded 2. Integrated Keyhole since 12:00 am. Press and HOLD For easy wall mounting. for full reset to factory defaults. 3.
-
Page 7: Setup
SETUP 5-in-1 Sensor Setup Set the A-B-C Switch cause alkaline batteries to function improperly. Use lithium batteries in Locate the A-B-C switch inside the the 5-in-1 sensor for temperatures battery compartment. Set the A-B-C below -20ºC/-4ºF . switch to A, B or C. You must select 1. -
Page 8: Display Setup
Display Setup Set the A-B-C Switch Install or Replace Backup Batteries (optional) The A-B-C switch is located inside the battery compartment. It can Insert 3 x AA alkaline batteries be set to A, B or C. However, into the battery compartment, you must select the same letter as shown. -
Page 9: Set The Time, Date & Units
Set the Time, Date & Units Press the “ ” button, located on the front of the display, to enter SET MODE. Once in set mode, the preference you are currently setting will blink on the display. To adjust the currently selected (flashing) item, press and release the “ “... -
Page 10: Placement Guidelines
Placement for Maximum Accuracy AcuRite sensors are sensitive to surrounding environmental conditions. Proper placement of both the display and the sensor are critical to the accuracy and performance of this product. Display Placement Place the display in a dry area free of dirt and dust. To ensure accurate temperature measurement, place out of direct sunlight and away from heat sources or vents. -
Page 11: 5-In-1 Sensor Installation
5-in-1 Sensor Installation Guidelines INSTALLATION HEIGHT Mount the sensor at a minimum height of 1.5 metres (5 feet) off the ground, in an open area. Higher is better for wind measurements - the National Weather Service recommends 10 metres (33 feet) high! MOUNTING OPTIONS The included mounting bracket is designed to screw directly onto wooden posts or surfaces that are 45mm x 95mm (2”x 4”) or... -
Page 12: Using The Weather Centre
OPERATION Using the Professional Weather Centre Learning Mode Self-Calibrating Forecasting use a unique algorithm to analyze changes in pressure over a time period (called Learning Mode) to determine your altitude. After 14 days, the Learning Mode icon disappears from the display screen. At this point, the self-calibrated pressure is tuned in to your location and the unit is ready for superior weather prediction. -
Page 13: Rainfall Tracking
Rainfall Tracking This weather station features enhanced tracking of historical rainfall data. Rain accumulation data is displayed for the current day, week, or month (most recent rainfall total). The rain indicator illustrates today’s rain collection up to 25 mm (1 inch). Press the “... -
Page 14: Weather Ticker
Weather Ticker ™ The Weather Ticker automatically flashes your real-time weather information and alerts as text in the lower part of the display screen. The possible WEATHER TICKER messages are as follows: HEAT INDEX-XX WIND CHILL-XX DEW POINT-XX IT FEELS LIKE XX OUTSIDE TODAY’S HIGH HUMIDITY...OUTDOOR XX / INDOOR XX TODAY’S LOW HUMIDITY...OUTDOOR XX / INDOOR XX TODAY’S HIGH TEMP...OUTDOOR XX / INDOOR XX... -
Page 15: Troubleshooting
Troubleshooting Problem Possible Solution • Relocate the display and/or the 5-in-1 sensor. The units must be within 100 m (330 ft) of each other. • Make sure both units are placed at least .9 m (3 feet) away from electronics that may interfere with the wireless communication (such as TVs, microwaves, computers, etc). - Page 16 Troubleshooting Problem Possible Solution • Make sure both the display and 5-in-1 sensor are placed away from any heat sources or vents (see page 10). Inaccurate • Make sure both units are positioned away from moisture sources (see page 10). temperature or humidity •...
-
Page 17: Care & Maintenance
Care & Maintenance Display Care Clean with a soft, damp cloth. Do not use caustic cleaners or abrasives. Keep away from dust, dirt and moisture. Clean ventilation ports regularly with a gentle puff of air. 5-in-1 Sensor Care Clean the Sensor Clean with a soft damp cloth. - Page 18 INDOOR TEMPERATURE INDOOR HUMIDITY BAROMETRIC PRESSURE (must be set to MANUAL mode to calibrate)* *To change from AUTO to MANUAL pressure mode and vice versa, press AND HOLD the “ ” button for 5-7 seconds. The display indicates the current pressure mode selected, “AUTO” or “MANUAL”. The “ ”...
-
Page 19: Specifications
Specifications TEMPERATURE RANGE Outdoor: -40ºC to 70ºC; -40ºF to 158ºF Indoor: 0ºC to 50ºC; 32ºF to 122ºF HUMIDITY RANGE Outdoor: 1% to 99% Indoor: 1% to 99% WIND SPEED 0 to 159 kph; 0 to 99 mph WIND DIRECTION 16 points INDICATORS 0.25 mm (0.01 inches) and up RAINFALL MEASUREMENT... - Page 24 Weather Temperature Weather Kitchen Clocks Stations & Humidity Alert Radio Thermometers & Timers It’s More than Accurate, it’s AcuRite offers an extensive assortment of precision instruments, designed to provide you with information you can depend on to Plan your day with confidence ™...
