ACU-RITE 02027 Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

CONTENTS
Package Contents .................. 2
Product Registration ............... 2
Setup .................................... 5
Sensor Setup ......................... 5
Display Setup ........................ 6
Clock .................. 7
®
Backlight Settings ................... 7
Questions?
(877) 221-1252 or visit www.AcuRite.com.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
model 02027/02022WB
Placement Guidelines ............. 8
Troubleshooting ....................10
Care & Maintenance .............12
Calibration ...........................12
Specifications ........................14
FCC Information ...................14
Customer Support .................15
Warranty..............................15
Contact Customer Support at
Instruction Manual
Weather Station
battery ..13
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 02027 and is the answer not in the manual?

Questions and answers

Related Manuals for ACU-RITE 02027

Summary of Contents for ACU-RITE 02027

  • Page 1: Table Of Contents

    Instruction Manual Weather Station model 02027/02022WB CONTENTS Unpacking Instructions ... 2 Placement Guidelines ..... 8 Package Contents ....2 Using the Weather Station ..9 Product Registration ....2 Troubleshooting ....10 Features & Benefits: Sensor ..2 Care & Maintenance .....12 Features &...

  • Page 2: Unpacking Instructions

    Congratulations on your new AcuRite product. To ensure the best possible product performance, please read this manual in its entirety and retain it for future reference. Unpacking Instructions Remove the protective film that is applied to the LCD screen prior to using this product.

  • Page 3: Features & Benefits: Display

    Features & Benefits 16 15 DISPLAY UNIT 8. Barometric Pressure Arrow icon indicates the direction 1. Current Outdoor Temperature the pressure is trending. Arrow icon indicates the direction the 9. Moon Phase temperature is trending. 10. Low/High Humidity Records 2. Low/High Temperature Records Lowest and highest indoor Lowest and highest outdoor humidity recorded since midnight.
  • Page 4 Features & Benefits BACK OF DISPLAY UNIT 1. All-Time Records Button 6. Reset Button Press to access all-time high and low Full reset to factory defaults. records. 7. Plug-in for Power Adapter 2. Adjust Up Button 8. A-B-C Switch for setup preferences. ID code that must match sensor’s A-B-C 3.

  • Page 5: Setup

    SETUP Sensor Setup Set the A-B-C Switch conditions. Cold temperatures can cause alkaline batteries The A-B-C switch is located inside to function improperly. Use the battery compartment. It can lithium batteries in the sensor for be set to A, B or C. However, temperatures below -4ºF / -20ºC.

  • Page 6: Display Setup

    Display Unit Setup Set the A-B-C Switch 2. Insert 3 x AA alkaline batteries into the battery compartment, Locate the A-B-C switch inside as shown. Follow the polarity the battery compartment. Set (+/–) diagram in the battery the A-B-C switch to A, B or C. compartment.

  • Page 7: Intelli-Time ® Clock

    Intelli-Time Clock ® Intelli-Time products are pre-programmed with the correct time and date. Intelli-Time technology instructs the time and date to set themselves. All you need to do is select your Time Zone and Daylight Saving Time preferences. The clock will then automatically set itself and change for Daylight Saving Time. Set the Time, Date &...

  • Page 8: Placement Guidelines

    Placement for Maximum Accuracy AcuRite sensors are sensitive to surrounding environmental conditions. Proper placement of both the display unit and outdoor sensor are critical to the accuracy and performance of this product. Display Unit Placement Place the display unit in a dry area free of dirt and dust. Display unit stands upright for tabletop use or is wall-mountable.

  • Page 9: Using The Weather Station

    OPERATION Using the Weather Station Learning Mode Self-Calibrating Forecasting uses a unique algorithm to analyze changes in pressure over a time period (called Learning Mode) to determine your altitude. After 14 days, the Learning Mode icon disappears from the display screen. At this point, the self-calibrated pressure is tuned in to your location and the unit is ready for superior weather prediction.

  • Page 10: Troubleshooting

    LOW records. To manually clear all of today’s HIGH recorded values, press and hold the “ ” button for 2 seconds. Dashes display to confirm you have cleared the HIGH records. Press the “ ” button to cycle through the all-time high and low recorded values (one record is shown at a time) for outdoor and indoor temperature and humidity.
  • Page 11 • Weather Forecast icon predicts conditions for the next 12 to 24 hours, not current conditions. • Has Learning Mode icon disappeared from the display unit? Learning Mode must complete before forecast and pressure will be accurate. Inaccurate forecast • Allow unit to run continuously for 33 days. Battery removal or resetting the display unit will restart Learning Mode.

  • Page 12: Care & Maintenance

    Care & Maintenance Display Unit Care Clean with a soft, damp cloth. Do not use caustic cleaners or abrasives. Keep away from dust, dirt and moisture. Clean ventilation ports regularly with a gentle puff of air. Outdoor Sensor Care Clean with a soft damp cloth. Do not use caustic cleaners or abrasives. Calibration The indoor / outdoor temperature and humidity readings, and barometric pressure can be calibrated on the display unit to improve accuracy.

  • Page 13: Replace Intelli-Time Battery

    Replace Intelli-Time Battery Intelli-Time technology is powered by a pre-installed coin-cell battery that stores the time and date settings. The battery has a shelf life of several years. To replace the CR2032 Intelli-Time battery: 1. Locate the coin cell battery compartment door on the back of the display unit, inside the battery...

  • Page 14: Specifications

    Specifications TEMPERATURE RANGE Outdoor: -40ºF to 158ºF; -40ºC to 70ºC Indoor: 32ºF to 122ºF; 0ºC to 50ºC HUMIDITY RANGE 1% - 99% RH (relative humidity) WIRELESS RANGE 330 ft / 100 m depending on home construction materials OPERATING FREQUENCY 433 MHz POWER Display: 5v power adapter 3 x AA alkaline batteries (optional)

  • Page 15: Customer Support

    Customer Support AcuRite customer support is committed to providing you with best-in- class service. For assistance, please have the model number of this product available and contact us in any of the following ways: (877) 221-1252 info@chaney-inst.com AcuRite 24/7 support at www. .com Installation Videos Register your Product...
  • Page 16 ©Chaney Instrument Co. All rights reserved. AcuRite is a registered trademark of the Chaney Instrument Co., Lake Geneva, WI 53147. All other trademarks and copy- rights are the property of their respective owners. AcuRite uses patented technology. Printed in China 02027 INST 051614 Visit www.AcuRite.com/patents for details.
