- Page 1 GH60WH 60CM 4 ZONE GAS HOB Instruction Manual PO number : Please read these instructions carefully before use and retain for future reference. Before switching on your appliance – Always check for any damage that may have been caused in transit.
-
Page 2: Table Of Contents
CONTENTS Safety Instructions ............2-5 Specification ..............5 Appliance Overview ............6-7 Installation ..............7-12 Operating Instructions ..........12-14 Cleaning and Maintenance ........14-16 Troubleshooting ............17-18 Fuse Replacement ............18 Service & Disposal Information ........19 IMPORTANT SAFETY INSTRUCTIONS Read and follow all of the instructions even if you feel you are familiar with the product, and find a place to keep this manual handy for future reference. - Page 3 6. Check the voltage of the appliance matches the household voltage, which is located on the rating label. 7. All appliances containing any electrical components must be earthed. 8. When installing, ensure that the gas pipe and electrical cable do not touch any part of the appliance. 9.
- Page 4 23. It is not recommended to store anything on top of the appliance. 24. After use, always ensure that burners are switched off. 25. After use the appliance will stay hot for some time, even after it is switched off. Keep children well away at all times. 26.
-
Page 5: Specification
1/1000 of the gas is in the air. SPECIFICATION Technical Specification Supplier Name Statesman Model GH60WH Type of Hob Pan Support Wire rack Top Plate Enamel Dimensions (H x W x D) mm... -
Page 6: Appliance Overview
APPLIANCE OVERVIEW 1. Rapid Burner 2. Semi-rapid Burners 3. Auxiliary Burner 4. Hob Top 5. Control Knobs Control Panel Dials A. Rapid Burner B. Back Semi-rapid Burner C. Near Semi-rapid Burner D. Auxiliary Burner... -
Page 7: Installation
Accessories Bracket X4 Sealing Strip (Sponge) X4 Screw X4 Injector X4 Gas Pipe Bend X1 Instruction Manual X1 INSTALLATION This appliance should only be installed by a registered CORGI gas safe engineer. Before installing the appliance ensure that the area that you have selected is suitable and allows enough ventilation for the appliance. - Page 8 Sponge (Sealing Strip) The thickness of the sponge is 3mm. The width of the sponge is 10mm. Do not use a silicon sealant to seal the appliance against the aperture. This will make it difficult to remove the appliance from the aperture in future, particularly if it needs to be serviced.
- Page 9 Gas supply replacement and installation guidelines: NG > LPG LPG > NG The gas rail The gas rail seal seal Ø11.5 Female coupler G1/2”Female coupler • It is the law that all gas appliances are installed by competent persons in accordance with the current edition of the Gas Safety Installation and Use Regulations.
- Page 10 Change the Injector of the Burners • Remove the pan support, burner lid and flame spreader. • Unscrew the injector using a 7mm box spanner and replace with new injector correct for the new gas supply. Ensuring that the new injector is firmly tightened.
- Page 11 • Before replacing the Flame Spreader and Burner Cap, ensure that the Injector is not blocked. • A full operational test and a test for possible leaks must be carried out after a gas conversion. • After completing conversion, the quailified gas engineer will need to mark “V”...
-
Page 12: Operating Instructions
• 50 mm clearance around the appliance and between the hob surface and any combustible materials. • You must have a gap of at least 25mm and at most 74mm between the underneath of the appliance and any surface that is below it. - An oven must have forced ventilation to install a hob above it. - Page 13 • Keep the Control Knob depressed for a further 15 seconds after the flame has ignited. • If the flame does not ignite or stay on, then repeat the process. • The required setting can now be selected by turning the control knob. •...
- Page 14 Safety and Energy Saving Do not use small diameter cookware Always use cookware that is on large burners. suitable for each burner, The flame should never come up the to avoid wasting gas and sides of the cookware. discolouring the cookware. Avoid cooking without a lid or with the Place a lid on the cookware.
-
Page 15: Cleaning And Maintenance
CLEANING & MAINTENANCE IMPORTANT: • Cleaning operations must only be carried out when the appliance is completely cool. • The appliance should be disconnected from your mains supply before commencing any cleaning process. • Clean the appliance regularly, preferable after each use. •... - Page 16 Burners • Remove the burner lids and Flame Spreaders by pulling them upwards and away from the top plate. • Soak them in hot water and a little detergent or washing up liquid. • After cleaning and washing them, wipe and dry them carefully. Make sure that the flame holes are clean and completely dry.
-
Page 17: Troubleshooting
TROUBLESHOOTING If you are having problems with your appliance, please use our troubleshooting guide below. If you are unable to resolve the issue using this guide please ring our Customer Service Department on 0844 848 5861. Please have the model code and purchase information available. Note: Any repairs should be done by a qualified technician. -
Page 18: Fuse Replacement
Fault Possible Cause Solution Yellow flame The holes in the flame spreader Clean the flame spreader. are clogged Refer to ‘Cleaning and Maintenance’ Different gas is used Check the gas used is correct Gas smell Gas leakage Stop using the appliance and close any functioning burners. -
Page 19: Service & Disposal Information
SERVICE AND SPARE PARTS Should you experience any difficulty in using your Statesman appliance at any time, you may contact your Statesman Retailer or call our Customer Service Department on: 0844 848 5861 Please have the following details ready;... - Page 20 Ipswich, IP3 9RR 0844 848 5861 Disclaimer: Statesman operate a policy of continual improvement and development. We therefore reserve the right to change/alter the specification and appearance of our appliances without prior notice. All diagrams and images shown in this manual are for illustration purposes only.
