STATESMAN ECH77TC Instruction Manual

77cm 5 zone ceramic hob
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ECH77TC
77cm 5 ZONE CERAMIC HOB

Instruction Manual

Serial number:
Please read these instructions carefully before use and retain for future reference.
Before switching on your appliance – Always check for any damage that may have been caused in transit.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ECH77TC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for STATESMAN ECH77TC

Summary of Contents for STATESMAN ECH77TC

  • Page 1: Instruction Manual

    ECH77TC 77cm 5 ZONE CERAMIC HOB Instruction Manual Serial number: Please read these instructions carefully before use and retain for future reference. Before switching on your appliance – Always check for any damage that may have been caused in transit.

  • Page 2: Table Of Contents

    CONTENTS Important Safety Instructions ........3 Specification ..............4 Appliance Overview ............5 Installation ..............6-8 Operating Instructions ..........8-11 Cleaning and Maintenance ..........12 Trouble Shooting Guide ..........13 Disposal Information ...........14...

  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS Read and follow all of the instructions even if you feel you are familiar with the product, and find a place to keep this manual handy for future reference. Important: This product is intended for domestic household use only. When using electrical appliances, basic safety precautions should always be followed: 1.

  • Page 4: Specification

    TECHNICAL SPECIFICATION Supplier Name / Trade Mark Statesman Model Number ECH77TC Type of Hob Ceramic Number of Cooking Zones Heating Technology Radiation For circular cooking zones or area: Diameter of Zone 1: 165mm useful surface area per cooking zone, rounded...

  • Page 5: Appliance Overview

    APPLIANCE OVERVIEW Fig 1. 1. Maximum 1200 W Zone 5. Maximum 1200 W Zone 2. Maximum 1800 W Zone 6. Glass Plate 3. Maximum 1000/ 2200 W Zone 7. Control Panel 4. Maximum 1800 W Zone Control Panel Fig 2. 1.

  • Page 6: Installation

    INSTALLATION This appliance should only Fig 3. be installed by a qualified technician. Before installing the appliance ensure that the area that you have selected is suitable and allows enough ventilation for the appliance. A (mm) B (mm) 50 min. C (mm) 20 min.

  • Page 7: Installation

    Fig 5. Screw Bracket Screw Hole Base 5. The appliance can now be inserted into the cut hole and secured to the worktop (Fig. 6). WORK TOP WORK TOP Fig 6. BRACKET BRACKET Connecting to the Mains Power Supply The power supply should be connected in compliance with the relevant standard, or a single-pole circuit breaker.

  • Page 8: Operating Instructions

    • The cable must be checked regularly and only replaced by a properly qualified technician. • Ensure the appliance is connected to an isolating switch providing full disconnection from the mains supply. The appliance must not be connected to the mains supply by means of a 13A plug and socket.
  • Page 9 8. To switch the appliance off touch the ON/OFF Control (Fig. 14). Fig 14. Important: If a heat setting is not chosen within 1 minute then the appliance will automatically switch off. Important: The heat setting can be modified at any point during cooking.
  • Page 10 Timer Control The timer can be used in two different ways: a) Minute Minder (countdown mode): in this case the timer will not switch off any cooking zones when the time is up. b) Cooking Timer (switching a zone off): once the set time is up the selected cooking zone will switch off (maximum is 99 minutes).
  • Page 11 5. Set the time by touching the Slider Control e.g. 9, the time that has been set is 95 minutes (Fig. 29). Insert Fig. 29 Fig 29. 6. The timer count down will start immediately and the display will show the Fig 28.

  • Page 12: Cleaning And Maintenance

    CLEANING AND MAINTENANCE Regular cleaning will prevent any salts or minerals from accumulating on the hob and discolouring the glass. It is recommended to use a specialist ceramic cleaner to restore the surface, but use sparingly to avoid coating the hob top too thickly. Too much cream cleaner will lead to discolouration. Use a dry, clean cloth to polish the surface.

  • Page 13: Trouble Shooting Guide

    TROUBLESHOOTING If you are having problems with your appliance, please use our troubleshooting guide below. If you are unable to resolve the issue using this guide please ring our Customer Service Department on 0844 848 5861. Please have the model code and purchase information available. Fault Possible cause Solution...

  • Page 14: Disposal Information

    DISPOSAL The European Directive 2012/19/EU on Waste Electrical and Electronic Equipment (WEEE), requires that old household electrical appliances must not be disposed of in normal unsorted municipal waste. Old appliances must be collected separately in order to optimise the recovery and recycling of the materials they contain and reduce the impact on human health and the environment.
  • Page 16 Ipswich, IP3 9RR 0844 848 5861 Disclaimer: Statesman operate a policy of continual improvement and development. We therefore reserve the right to change/alter the specification and appearance of our appliances without prior notice. All diagrams and images shown in this manual are for illustration purposes only.
