Life Gets Better With
USE AND CARE GUIDE
E02GS015
MODEL#: F200034-A1
ANS Z21.97 CSA 2.41-2017
Outdoor Decorative Gas Appliances
Questions, problems, missing parts? Before returning to the store,
please contact our Customer Service
service@alphamarts.com
THANK YOU
We appreciate the trust and con dence you have placed in PHI VILLA through the purchase of our product. We strive to continually create quality
products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing PHI VILLA!

Advertisement

loading
Need help?

Need help?

Do you have a question about the E02GS015 and is the answer not in the manual?

Questions and answers

Related Manuals for PHI VILLA E02GS015

Summary of Contents for PHI VILLA E02GS015

  • Page 1 THANK YOU We appreciate the trust and con dence you have placed in PHI VILLA through the purchase of our product. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.

  • Page 2: Table Of Contents

    Table of Contents Table of Contents Natural Gas Conversion Warnings & Important Safety Information Operation Instructions 9-11 Speci cation & Package Contents Care and Maintenance Assembly instructions Warranty WARNING: For Outdoor Use Only. INSTALLER: Leave this manual with the appliance. Installation and service must be performed CONSUMER: Retain this manual for future reference by a quali ed installer, service agency, or...
  • Page 3 IMPORTANT SAFETY INFORMATION The installation must conform with local codes or, in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1 NFPA 54; National Fuel Gas Code; Natural Gas and Propane Installation Code, CSA B149.1; or Propane Storage and Handling Code, CSA B149.2, as applicable.

  • Page 4: Speci Cation & Package Contents

    IMPORTANT SAFETY INFORMATION (About Propane Gas) The propane gas supply cylinder to be used must be constructed and marked in accordance with the U.S. Deparment of Transportation (D.O.T.) Speci cations for propane gas Cylinders, or the Standard for Cylinders, Spheres and Tubes for Transportation of Dangerous Goods and Commission, CAN/CSA-B339, as applicable.

  • Page 5: Assembly Instructions

    PACKAGE CONTENTS PART DESCRIPTION QUANTITY Fire table Door Weather cover Natural gas ori ce Lava rock (13.2 Ibs/pack) 1 pack ASSEMBLY INSTRUCTIONS 1. Carefully unpack all parts from the box and compare parts with the package content listed above, making sure all parts are present before beginning assembly of the product.
  • Page 6 ASSEMBLY INSTRUCTIONS 3. Open the door. Place the gas cylinder into the gas cylinder support and connect the regulator by turning the black handle clock- wise to tighten. To remove the regulator, turn the black handle counter-clockwise. Secure the gas cylinder by tightening clockwise the retention point found on gas cylinder support (G), so that the gas cylinder cannot move from side to side or fall down.

  • Page 7: Natural Gas Conversion

    NATURAL GAS CONVERSION STOP STOP NATURAL GAS CONVERSION Natural gas conversion must be performed only by natural gas provider or a service company. 1. Disconnect the propane hose from the gas valve (see Figure 6). Caution: The propane tank shall be shut off prior to disconnecting the propane hose, before proceeding with the conversion. gas valve propane hose Figure 6...
  • Page 8 NATURAL GAS CONVERSION 4. Connect the natural gas hose to the gas valve by screwing clockwise tightly (see Figure 9). Plug the natural gas xture into the nat- ural gas supply system (see Figure 10). The conversion kit should be CSA certi ed. Below are several suggested CSA certi ed con- version kits for your reference.

  • Page 9: Operation Instructions

    OPERATION INSTRUCTIONS Battery Make sure the control knob is in the “OFF” position. Unscrew the push button cap on the ignitor module located on the control panel to access the battery compartment. The ignitor module requires one AAA size battery, (see Figure 12). BATTERY IS NOT INCLUDED. WARNING: 1.
  • Page 10 OPERATION INSTRUCTIONS gas valve / regulator hose connection (Figure 16 ) inlet tube / bellows connection (Figure 17) To perform a leak test: 1. Make 2~3 oz. of leak solution by mixing one part liquid dishwasher detergent and three parts water. Noted: make sure control knob is “OFF”.

  • Page 11: Care And Maintenance

    OPERATION INSTRUCTIONS Observe Flame Height When Lit: The burner will display blue and yellow ames. These ames should be a blue / yellow color between 1~2 in. height (see Figure 19). These ames should not be yellow or produce thick smoke. This would indicate an obstruction of air ow through the burners.

  • Page 12: Warranty

    WARRANTY Firepits Burner, steel re pit bowl, all mechanical parts and ttings to control panel and burner assembly, and all re pit tops that are not cast aluminum are warranted for a period of one (1) year from original date of purchase, against defects in material and or workmanship. Rust is not covered.
