Life Gets Better With
USE AND CARE GUIDE
E02GS035
MODEL#: F190147-A1
ANS Z21.97 CSA 2.41-2017
Outdoor Decorative Gas Appliances
Questions, problems, missing parts? Before returning to the store,
please contact our Customer Service
service@alphamarts.com
THANK YOU
We appreciate the trust and con dence you have placed in PHI VILLA through the purchase of our product. We strive to continually create quality
products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing PHI VILLA!

Advertisement

loading
Need help?

Need help?

Do you have a question about the F190147-A1 and is the answer not in the manual?

Questions and answers

Related Manuals for PHI VILLA F190147-A1

Summary of Contents for PHI VILLA F190147-A1

  • Page 1 THANK YOU We appreciate the trust and con dence you have placed in PHI VILLA through the purchase of our product. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.

  • Page 2: Table Of Contents

    Table of Contents 8-10 Table of Contents Operation Instructions Warnings & Important Safety Information Care and Maintenance Package Contents Warranty Assembly instructions Maximum inlet supply pressure: 13 inch w.c. (3.24 kPa) Minimum inlet supply pressure: 8 inch w.c. (1.99 kPa) WARNING: For Outdoor Use Only.
  • Page 3 IMPORTANT SAFETY INFORMATION 1. This appliance is for outdoor use only, and should NOT be used in a building, garage or any other enclosed area. 2. DO NOT operate, light or use this appliance within ten feet (3.05 m) of walls, structures or buildings. 3.
  • Page 4 IMPORTANT SAFETY INFORMATION j. A re causing serious injury or damage to property may occur if the above is not followed exactly. 16. Your outdoor repit has been checked at all factory connections for leaks. Recheck all connections as described in the “Operating Instructions”...
  • Page 5 47. Use only the regulator assembly provided. Use only the replacement regulator assembly speci ed by Use only the burner provided. Use only the replacement burner speci ed by PHI VILLA. 48. Use only PHI VILLA factory-authorized parts. The use of any part that is not factory authorized can be dangerous and will void your warranty.

  • Page 6: Package Contents

    PACKAGE CONTENTS PART DESCRIPTION QUANTITY Fire pit body Fixture fastener Glass beads (2.2 lbs) 1 bag ASSEMBLY INSTRUCTIONS 1. Carefully unpack all parts from the box, compare parts with package content listed above, make sure all parts are present before beginning assembly of product.
  • Page 7 ASSEMBLY INSTRUCTIONS 4. Remove the xture fastener (B) from the repit. Attach the repit by aligning the post through the umbrella hole, then tighten the xture fastener (B) clockwise (See Figure 3). post umbrella hole Figure 3 5. Connecting propane cylinder (See Figure 4) Only cylinders marked “propane”...
  • Page 8 ASSEMBLY INSTRUCTIONS 7. Place the glass beads (B) into the re pit body (A). Approx 2.2 lbs of glass beads are needed (See Figure 6) . NOTE: Leave the pilot box uncovered by glass beads. WARNING Keep children away during assembly, as this item contains glass beads, which are small pieces and can be swallowed by children.

  • Page 9: Operation Instructions

    OPERATION INSTRUCTIONS WARNING Before using this outdoor repit, make sure you have read, understand and are following all information provided in the “Safety Information” section beginning on page 2 and 3. Failure to follow those instructions can cause death, serious injury or property damage. Cylinder/Gas line connection 1.
  • Page 10 OPERATION INSTRUCTIONS 6. Push and turn control panel counterclockwise to “High” position (See Figures 8). 7. Use a match or a lighter to light the re bowl (See Figure 8). Continue to press the control knob for 15 seconds before it is released. 8.

  • Page 11: Care And Maintenance

    CARE AND MAINTENANCE CAUTION 1. All cleaning and maintenance should be done when outdoor repit is cool and with the fuel supply disconnected. 2. DO NOT clean any outdoor repit part in a self-cleaning oven. The extreme heat will damage the nish. 3.

  • Page 12: Warranty

    WARRANTY Firepits Burner, steel re pit bowl, all mechanical parts and ttings to control panel and burner assembly, and all re pit tops that are not cast aluminum are warranted for a period of one (1) year from original date of purchase, against defects in material and or workmanship. Rust is not covered.
