34 Inch Gas Fire Pit Table
R
C
US
Please keep this instruction manual for future reference
READ INSTRUCTION MANUAL BEFORE ATTEMPTING ASSEMBLE OR
Assembly Instructions
OPERATE THIS PRODUCT.
Keep the screws and parts out of reach of children.
DANGER
LEAKING LP-GAS MAY CAUSE A FIRE OR EXPLOSION IF IGNITED
CAUSING SERIOUS BODILY INJURY OR DEATH.
CONTACT LP GAS SUPPLIER FOR REPAIRS, OR DISPOSAL OF THIS
WARNING
DO NOT USE OR STORE CYLINDER IN A BUILDING,
GARAGE OR ENCLOSED AREA.
WARNING:
・
Know the odor of LP-gas. If you hear, see or smell
leaking LP-gas, immediately get everyone away
from the cylinder and call the Fire Department.
Do not attempt repairs.
・
Caution your LP-gas supplier to:
Be certain cylinder is purged of trapped air prior
to first filling.
Be certain not to over fill the cylinder.
Be certain cylinder requalification date is checked.
・
LP-gas is heavier than air and may settle in low
places when dissipating.
・
Contact with the liquid contents of cylinder will
cause freeze burns to the skin.
・
Do not allow children to tamper or play with cylinder.
・
When not connected for use, keep cylinder valve
turned off. Self contained appliances shall be limited
to a cylinder of 30 lb capacity or less.
・
Do not use, store or transport cylinder where it would
be exposed to high temperatures. Relief valve may
open allowing a large amount of flammable gas to
escape.
・
When transporting, keep cylinder secured in
an upright position which cylinder valve turned off.
DO NOT REMOVE, DEFACE, OR OBLITERATE THIS LABEL
*EXCEPT AS AUTHORIZED BY ANSI/NFPA 58.
DANGER. Do not store a spare LP cylinder under or near a barbecue grill, or other
heat sources. NEVER fill an LP cylinder beyond 80% full: a fire causing death or
serious injury may occour.
WARNING
(Made in China)
Model #: GFT-30132R
Item # : PF19902
·
FLAMMABLE GAS UNDER PRESSURE.
CYLINDER OR UNUSED LP-GAS.
·
FOR OUTDOOR USE ONLY.*
WHEN CONNECTING FOR USE:
・
Use only in compliance with appliable codes.
・
Read and follow manufacturer's instructions.
・
Consult manufacturer's instructions
concerning the cylinder connection provided
with your appliance.
・
Be sure regulator vent is not pointing up.
・
Turn off all valves on the appliance.
・
Do not check for gas leaks with a match or
open flame. Apply soapy water at areas
marked "X". Open cylinder valve. If bubble
appears, close valve and have LP-gas
service person make needed repairs. Also,
check appliance valves and connections to
make sure they do not leak before lighting
appliance.
・
Light appliance(s) following manufacturer's
instructions.
・
When appliance is not is use, keep the
cylinder valve closed.
X
Pressure relief valve
X
Cylinder
X
Cylinder valve hand wheel
Point of connection
X
X
Liquid level indicator
(optional)
Advertisement
Related Manuals for PHI VILLA GFT-30132R
Summary of Contents for PHI VILLA GFT-30132R
- Page 1 Model #: GFT-30132R Item # : PF19902 Assembly Instructions 34 Inch Gas Fire Pit Table · DANGER FLAMMABLE GAS UNDER PRESSURE. LEAKING LP-GAS MAY CAUSE A FIRE OR EXPLOSION IF IGNITED CAUSING SERIOUS BODILY INJURY OR DEATH. CONTACT LP GAS SUPPLIER FOR REPAIRS, OR DISPOSAL OF THIS CYLINDER OR UNUSED LP-GAS.
-
Page 2: Table Of Contents
Table of Contents Table of Contents ............2 Operating Instructions .........1 Safety Information............2-4 Maintenance............Pre-Assembly...……………………...……………………. 5 Care and Cleaning ..........14 ..………………...……………………. 6 Troubleshooting ............ Package Contents Assembly..……………………………… ………..…8-1 Safety Information Read the instruction before use. This appliance must be installed in accordance with such regulations as are enforced. -
Page 3: Safety Information
Safety Information (continued) WARNING: You must provide propane gas and propane cylinder. Use a standard 20 lb. propane cylinder only. Use this heater only with a propane vapor withdrawal supply system. See Chapter 5 of the Standard for Storage and Handling of Liquefied Petroleum Gas, ANS/NFPA 58. - Page 4 Safety Information (continued) WARNING: Solid fuels shall not be burned in this appliance. The installation must conform with local codes or, in the absence of local codes, ANSIZ223. 1/NFPA54, NFPA58 Natural Gas and Propane Installation Code, CSA B149.1, or Propane Storage and Handling Code, B149.2. This appliace must be isolated from the gas supply piping system by closing its individual manual shutoff valve during any pressure testing of the gas supply piping system at test pressures equal to or less than 1/2 psi (3.5 kPa).
-
Page 5: Pre-Assembly
Pre-Assembly PLANNING ASSEMBLY Carefully remove all pieces from the carton and make sure that you have all parts (refer to the hardware and package contents list). If you are missing parts, please contact 855-600-9294 for further assistance. YOUR OWNER’S MANUAL Keep and store this Owner’s Manual for future reference. -
Page 6: Package Contents
Package Contents... - Page 7 Package Contents Parts Reference Image Description Lid Handle Table Top Side Panel Side Panel With Igniter Door Left Leg Right Leg Left Door Leg Right Door Leg Propane Tank Support Lava Rock AAA Battery...
- Page 8 Assembly Step 1: Place table top (C) upside down on a flat, protected surface. Attache left leg (G), right leg (H), left door leg(I) and right door leg ( J) to table top (C) with four M6*12MM bolts (AA). Please use Phillips head screwdriver (not included).
- Page 9 Assembly (continued) Step 4: Position as shown. Attach propane tank support(K) to legs (G, H, I and J) with M6*12MM bolts (AA). Please use Phillips head screwdriver (not included). Please tighten all the screws for step 1-4. Step 5: Attach handle (A) to the lid (B) with washer (DD)and M5*10MM bolt (BB).
- Page 10 Assembly (continued) Ignition S tep 7: Position assembled unit to a desired location. Place lava rocks (L) into the fire bowl. Ensure lava rocks do not cover the ignition portion of the burner. Place lid (B) to cover the top. The lid must be removed when the burner is in operation.
- Page 11 Operating WARNING: Never use this appliance for other than the intended use. DO NOT use this appliance to prepare food. Initial Lighting: When lit for the first time, the appliance emits a slight odor. This is a normal temporary condition caused by the “burn-in ”...
-
Page 12: Operating Instructions
Operating (continued) LEAK TESTING OPERATION WARNING: A leak test must be performed annually or if a part of the gas system is replaced. WARNING: Never use an open flame to check for gas leaks. Be certain no sparks or open flames are in the area while you check for leaks. - Page 13 Operating (continued) LIGHTING CAUTION: Keep the outdoor gas appliance area clear and free from combustible materials, gasoline and other flammable vapors and liquids. CAUTION: Do NOT obstruct the flow of combustion and ventilation air. CAUTION: Check and clean burner/venturi tubes for insects and insect nests. A clogged tube can lead to a fire.
-
Page 14: Maintenance
Maintenance Storage between uses: □ Turn the control knob to “OFF” position. □ Disconnect LP source. □ Store heater upright in an area sheltered from direct contact with inclement weather (such as rain, sleet, hail, snow, dust and debris). □ If desired, cover heater to protect exterior surfaces and to help prevent build up in air passages. NOTE: Wait until heater is cool before covering. -
Page 15: Troubleshooting
Troubleshooting PROBLEM PROBLEM CAUSE SOLUTION The flame and heat are The propane lighting Ensure lighting procedure is followed carefully. The valve low when the valve is procedure was not followed must be in the off position when the tank valve is turned on. turned to high.
