Life Gets Better With
USE AND CARE GUIDE
E02GS020
MODEL#: F19007-A1
ANS Z21.97 CSA 2.41-2017
Outdoor Decorative Gas Appliances
Questions, problems, missing parts? Before returning to the store,
please contact our Customer Service
service@alphamarts.com
THANK YOU
We appreciate the trust and con dence you have placed in PHI VILLA through the purchase of our product. We strive to continually create quality
products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing PHI VILLA!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the F19007-A1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PHI VILLA F19007-A1

Summary of Contents for PHI VILLA F19007-A1

  • Page 1 THANK YOU We appreciate the trust and con dence you have placed in PHI VILLA through the purchase of our product. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.

  • Page 2: Table Of Contents

    Table of Contents Table of Contents Operation Instructions Warnings & Important Safety Information Care and Maintenance Speci cation & Package Contents Warranty Assembly instructions WARNING: For Outdoor Use Only. INSTALLER: Leave this manual with the appliance. Installation and service must be performed CONSUMER: Retain this manual for future reference by a quali ed installer, service agency, or the gas supplier.
  • Page 3 IMPORTANT SAFETY INFORMATION The installation must conform with local codes or, in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1 NFPA 54; National Fuel Gas Code; Natural Gas and Propane Installation Code, CSA B149.1; or Propane Storage and Handling Code, CSA B149.2, as applicable.

  • Page 4: Speci Cation & Package Contents

    IMPORTANT SAFETY INFORMATION (About Propane Gas) The propane gas supply cylinder to be used must be constructed and marked in accordance with the U.S. Deparment of Transportation (D.O.T.) Speci cations for propane gas Cylinders, or the Standard for Cylinders, Spheres and Tubes for Transportation of Dangerous Goods and Commission, CAN/CSA-B339, as applicable.

  • Page 5: Assembly Instructions

    PACKAGE CONTENTS PART DESCRIPTION QUANTITY 1 pc Fire table 1 pc Door Weather cover 1 pc Lava rock (5.51 Ibs) 1 box ASSEMBLY INSTRUCTIONS 1. Carefully unpack all parts from the box, compare parts with package content listed above, make sure all parts are present before beginning assembly of product.
  • Page 6 ASSEMBLY INSTRUCTIONS Place the gas cylinder into the cylinder holder. Secure the cylinder by tightening clockwise the retention point found on the cylinder holder, so that the cylinder cannot move from side to side or fall down. Connect the regulator, screw the black handle clockwise to tighten, turn the black handle counterclockwise to remove.

  • Page 7: Operation Instructions

    OPERATION INSTRUCTIONS Battery Make sure the control knob is in the “OFF” position. Unscrew the push button cap on the ignitor module located on the control panel to access the battery compartment. The ignitor module requires one AAA size battery. BATTERY IS NOT INCLUDED. WARNING: 1.
  • Page 8 OPERATION INSTRUCTIONS gas valve-hose connection (Figure 9) inlet tube-bellows connection (Figure 10) To perform a leak test: 1. Make 2~3 oz. of leak solution by mixing one part liquid dishwashing detergent and three parts water. Noted: make sure control knob is “OFF”. 2.

  • Page 9: Care And Maintenance

    OPERATION INSTRUCTIONS Observe Flame Height When Lit: The burner will display blue and yellow ames. These ames should be a blue / yellow color between 1~2 in. height, (See Figure 12). These ames should not be yellow or produce thick smoke. This would indicate an obstruction of air ow through the burners.

  • Page 10: Warranty

    WARRANTY Firepits Burner, steel re pit bowl, all mechanical parts and ttings to control panel and burner assembly, and all re pit tops that are not cast aluminum are warranted for a period of one (1) year from original date of purchase, against defects in material and or workmanship. Rust is not covered.
