Instructions
Field Sensitive Magnetic
Proximity Cycle Switch
DC-powered 4-pin FSM proximity switches are not recommended for use on series divider
valves operating at less than 20 cycles per minute.
Part No. 557752, 558938
10,000 psi (69 MPa, 689 bar) Maximum Operating Pressure
Important Safety Instructions
Read all warnings and instructions in this
manual. Save these instructions.
- Use with MX, MXP & MGO Valve Sections -
313229B
ENG
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Graco 558938
Summary of Contents for Graco 558938
- Page 1 - Use with MX, MXP & MGO Valve Sections - DC-powered 4-pin FSM proximity switches are not recommended for use on series divider valves operating at less than 20 cycles per minute. Part No. 557752, 558938 10,000 psi (69 MPa, 689 bar) Maximum Operating Pressure Important Safety Instructions Read all warnings and instructions in this manual.
- Page 2 Warnings Warnings The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclama- tion point symbol alerts you to a general warning and the hazard symbol refers to procedure-specific risk. Refer back to these warnings. Additional, product-specific warnings may be found throughout the body of this manual where applicable.
- Page 3 Valve Assembly Installation Valve Assembly Installation Grounding 4. Screw in appropriate proximity switch using seal/gasket supplied. For MX and MXP valve sec- tions, torque to 6-8 ft/lbs for o-ring seal; 10 ft/lbs for gasket seals. NOTICE Do not over torque! Excessive torque will cause The equipment must be grounded.
-
Page 4: Technical Data
Technical Data B: Replacing existing cycle pin. NOTICE 1. Determine which valve section and side is the most Do not over torque! Excessive torque will cause convenient location for the switch. switch failure. For MGO torque adaptor to 25-30 ft/lbs and the switch to 6-8 ft/lbs. -
Page 5: Wiring Instructions
Technical Data Wiring Instructions In order to make proper electrical connections, connector cables must be used. The following connect cables are available: 4-Pin Cable Options for DC Powered Applications 5-Pin Cable Options for AC Powered Applications with LED Power/Operation Lights (No Operational Indicators in Cables) Connector Polarity... -
Page 6: Graco Standard Warranty
With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
