Graco 24K414 Instructions

Instructions
Set / Reset Point
Pressure Switch
Set and reset point pressure switch used to
detect pressure changes.
Not approved for use in European explosive
atmospheres.
Models: 24K414
Equivalent: IFM Electronic GMBH PK6220
Maximum Working Pressure: 5800 psi (400 bar, 40
MPa)
Important Safety Instructions
Read all warnings and instructions in this manual
and the instructions included with your operating
system or pump. Save these instructions.
Warnings
The following warnings are for the setup, use, grounding, main-
tenance, and repair of this equipment. The exclamation point
symbol alerts you to a general warning and the hazard sym-
bols refer to procedure-specific risks. When these symbols
appear in the body of this manual, refer back to these Warn-
ings. Product-specific hazard symbols and warnings not cov-
ered in this section may appear throughout the body of this
manual where applicable.
ELECTRIC SHOCK HAZARD
This equipment must be grounded. Improper grounding,
setup, or usage of the system can cause electric shock.
•
Turn off and disconnect power at main switch before
disconnecting any cables and before servicing
equipment.
•
Connect only to grounded power source.
•
All electrical wiring must be done by a qualified
electrician and comply with all local codes and
regulations.
SKIN INJECTION HAZARD
High-pressure fluid from dispense device, hose leaks, or
ruptured components will pierce skin. This may look like
just a cut, but it is a serious injury that can result in ampu-
tation. Get immediate surgical treatment.
•
Do not point dispense device at anyone or at any
part of the body.
•
Do not put your hand over the fluid outlet.
•
Do not stop or deflect leaks with your hand, body,
glove, or rag.
•
Follow Pressure Relief Procedure in this manual,
when you stop dispensing and before cleaning,
checking, or servicing equipment.
•
Tighten all fluid connections before operating the
equipment.
•
Check hoses and couplings daily. Replace worn or
damaged parts immediately.
