ME-1515
Enclosure for AC-825IP
Series
Installation Guide
1. Introduction
The ME-1515 is a lockable metal enclosure that houses the AC-825IP access control series and can be used to house
one AC-825IP unit or two x-805 expansions boards.
The ME-1515 enclosure has a Universal Power Socket (UPS) with a C14 standard plug for the VAC switcher power
supply, as well as an audio speaker sounder for chime, bell, and siren.
The ME-1515 has a VDC power management board with charger for a 12 V / 7 Ah lead acid battery, and output power
supply.
The unit has a LED illumination bar that is connected to the controller boards and lights when the enclosure door is
open. The illumination bar includes a tamper switch and a green power status LED at the front of the enclosure.
1.1. Related Documents
•
AC-825IP Hardware Installation and User Manual
•
AC-825IP PCBA DIN Rail Access Controller Manual
•
R/S/D/P-805 Series Installation Guide
2. Technical Specifications
Electrical Characteristics
Enclosure SMPS
PCBA Input Power
Backup Battery
Environmental Characteristics
Operating Environment
Operating Temp. Range
Operating Humidity Range
Physical Characteristics
Dimensions (H x W x D)
1
Weight
1
For weight purposes, the ME-1515 enclosure includes the metal box, AC input, DC output and LED bar.
www.rosslaresecurity.com
Input: 100 to 240 VAC, 1.6 A, 50–60 Hz, switch mode power management board, C13
power cord
Output: 15 VDC, 4 A
15 VDC, 2 A, regulated power management board
12 V sealed lead acid (SLA) up to 7 Ah
Indoor
0°C to 40°C (32°F to 104°F)
0% to 85% (non-condensing)
404 x 346 x 101 mm (15.9 x 13.6 x 4.0 in.)
1
4.5 kg (159.3 oz)
1
Advertisement
Table of Contents
Related Manuals for Rosslare ME-1515
Summary of Contents for Rosslare ME-1515
- Page 1 The ME-1515 enclosure has a Universal Power Socket (UPS) with a C14 standard plug for the VAC switcher power supply, as well as an audio speaker sounder for chime, bell, and siren. The ME-1515 has a VDC power management board with charger for a 12 V / 7 Ah lead acid battery, and output power supply.
- Page 2 ME-1515 Installation Guide 3. Installation The installation shall be in accordance with US National Electrical Code NFPA 70. 3.1. Mounting the ME-1515 When selecting an area for mounting, ensure the location is flat. To mount the ME-1515: 1. Drill holes in the wall, using the hole locations on the back cover of the enclosure as a guide.
- Page 3 To wire the ME-1515: 1. Connect the backup battery red and black wires. 2. Put the power cord into the slot on the ME-1515 case and secure it if necessary. 3. Do a check that the green power status LED lights are on.
- Page 4 All technical specifications weights, measures and colors shown, are best approximations. Rosslare can not be held responsible and assumes no legal liability for the accuracy or completeness of the information provided. Rosslare reserves the right to change, delete, or otherwise modify the information, which is represented, at any time, without any prior notice.
