Fxlion BP-7S500 User Manual

BP-7S500
I
Product Appearance
Ⅱ
Battery Basic Features
•Use high rate Li-ion battery cells, it can discharge at
a high rate up to 20A, and compatible with 500W
high-power equipment.
•High power intelligent protection chip is applied, and
t h e b a t t e r y h a s o v e r c h a r g e , o v e r d i s c h a r g e ,
t e m p e r a t u r e a n d o v e r- c u r r e n t p r o t e c t i o n . Wi t h
overload self recovery design.
•Compact structural design, integrated shell and
output terminal design, ultra-high volume energy
density ratio, truly achieving the ultimate high
capacity of Li-ion battery within a small volume.
•Ip54 waterproof grade, perfectly compatible with the
demand of LED lights, cameras, and other film and
television equipment with waterproof requirements.
Ⅲ
Specification
BP-7S500
Capacity
Full Power Voltage
Battery Output
D-tap*2 Output
Discharge Temperature
Charge Temperature
Dimension
Weight
Waterproof Grade
User Manual
High Power Waterproof Battery
Thanks for choosing Fxlion products!
Please read this user manual before use to enable you could properly use, storage and
maintenance of the products.
Packing List: 1.Battery BP-7S500*1
25.2V 19.4Ah 489Wh
29.4V
25.2V/20A/500W (Max)
25.2V/10.0A (Max)
-20~55℃
0~45℃
161.7mm(L)×104.7mm(W)×105.5mm(H)
2506g
IP54
2.User Manual *1
• T h e w a t e r p r o o f d e s i g n a n d 2 0 A h i g h - p o w e r
discharge meet the demand for high-power LED lights
in the market, especially for LED lights above 500W
which can use portable 26V V-mount battery directly.
•2*D-Tap design, 26V output voltage same as battery,
each with an output power of up to 10A. High Power
output can synchronous power external equipment or
high power external equipment while outputting
battery.
•The shell is made of special materials, which is
shockproof can meet requirements of daily outdoor
Li-ion battery use.
•5-Level LED indicators.
•Optional charger: suitable for 29.4V chargers, it is
recommended to use a FXLION charger with a
charging power of 29.4V/4A or above.
Ⅳ
Cautions !
•Must accordance with instructions to use and store.
• P l e a s e c h a r g e b y F x l i o n c h a r g e r o r F x l i o n
recommended charger.
•Do not put battery into water or fire.
•Waterproof grade IP54, able to work just in small
rain.
•Waterproof grade is tested in laboratory.
•Avoid strong impact.
•Do not heated or disassemble.
•Avoid short-circuit.
•Keep away from children.
•Battery should be charged to 50% power status
when need long time storage, charge and discharge
once every three months.
