Fxlion BM-HV300 User Manual

BM-HV300 BM-HV200
I
Product Appearance
Ⅱ
Battery Basic Features
•The ultra volume energy ratio design, use high power
cells, rechargeable Li-ion battery, no memory effect.
•Intelligent SMBus design, battery capacity, voltage,
working current, running time, and cycles could be
read by camera.
•Intelligent control protection: over-heat, over-
charge, over-discharge, and over-current protection.
•Be equipped with two D-tap outputs.
•USB-C PD fast charge protocols.
•D-Tap, USB-A, USB-C automatically detect load,
when there is no load, battery turn to low-power
mode; when there is load, battery start working. This
d e s i g n e ff e c t i v e l y r e d u c e t h e s t a t i c p o w e r
consumption of battery and expand battery life-span.
Ⅲ
Battery specification
BM-HV300
Capacity
Battery Output
D-tap*2 Output
USB-A Output
USB-C Input/Output
Discharge Temperature
Charge Temperature
Dimension
Weight
User Manual
B-mount Battery
Thanks for choosing Fxlion products!
Please read this user manual before use to enable you could properly use, storage and
maintenance of the products.
Packing List: 1.Battery BM-HV300 *1/BM-HV200 *1
28.8V 10.2Ah 293Wh
21.6V~33.6V/250W(Max)
16V/4A 64W(Max), DC16V(constant)
5V/2A
5V/3A， 9V/3A， 12V/3A， 15V/3A， 20V/3A
-20℃~+55℃
0~+45℃
154 （ L） mm×100(W)mm×87(T)mm
1650g
2.User Manual *1
•Internal modular design is simple, stable and
reliable.
•Battery cover is made by special material, which can
protect battery from drop off in daily outdoor shooting
use.
•5-level LED power indicators.
BM-HV200
Capacity
Battery Output
E-Tap*2 Output
USB-A Output
USB-C Input/Output
Discharge Temperature
Charge Temperature
Dimension
Weight
28.8V 6.7Ah 196Wh
21.6V~33.6V/250W(Max)
16V/4A 64W(Max), DC16V(constant)
5V/2A
5V/3A， 9V/3A， 12V/3A， 15V/3A， 20V/3A
-20℃~+55℃
0~+45℃
154(L)mm*100(W)mm*68(H)mm
1225g
