Fxlion BP-HP600 User Manual

BP-HP600
I
Product Appearance
Ⅱ
Battery Basic Features
•Use high rate Li-ion battery cells, it can discharge at
a high rate up to 30A, and compatible with 400W
high-power equipment.
•High power intelligent protection chip is applied, and
t h e b a t t e r y h a s o v e r c h a r g e , o v e r d i s c h a r g e ,
t e m p e r a t u r e a n d o v e r- c u r r e n t p r o t e c t i o n . Wi t h
overload self recovery design.
•Compact structural design, integrated shell and
output terminal design, ultra-high volume energy
density ratio, truly achieving the ultimate high
capacity of Li-ion battery within a small volume.
•Ip54 waterproof grade, perfectly compatible with the
demand of LED lights, cameras, and other film and
television equipment with waterproof requirements.
Ⅲ
Specification
BP-HP600
Capacity
D-tap*2 Output
Battery Output
Discharge Temperature
Charge Temperature
Dimension
Weight
Waterproof Grade
User Manual
High Power Waterproof Battery
Thanks for choosing Fxlion products!
Please read this user manual before use to enable you could properly use, storage and
maintenance of the products.
Packing List: 1.Battery BP-HP600*1
14.4V 38.8Ah 559Wh
14.4V/10.0A(Max)
14.4V/30A/400W(Max)
-20~55℃
0~45℃
161.7mm(L)×104.7mm(W)×105.5mm(H)
2784g
IP54
2.User Manual *1
•T h e w a t e r p r o o f d e s i g n a n d 3 0 A h i g h - p o w e r
discharge meet the demand for high-power LED lights
in the market, especially for LED lights above 300W
which can use portable V-mount battery directly.
•2*D-Tap design, each with an output power of up to
10A,High Power output can synchronous power
external equipment or High power external equipment
while outputting battery.
•The shell is made of special materials, which is
shockproof can meet requirements of daily outdoor
Li-ion battery use.
•5-Level LED indicators.
•Optional charger: suitable for 16.8V chargers, it is
recommended to use a FXLION charger with a
charging power of 16.8V/4A or above.
Ⅳ
Cautions !
•
Must accordance with instructions to use and store.
•
Please charge by Fxlion charger or Fxlion recommended charger.
•
Do not put battery into water or fire.
•
Waterproof grade IP54, able to work just in small rain.
•
Waterproof grade is tested in laboratory.
•
Avoid strong impact.
•
Do not heated or disassemble.
•
Avoid short-circuit.
•
Keep away from children.
•
Battery should be charged to 50% power status when need long time
storage, charge and discharge once every three months.
