Fxlion BP-BV300 User Manual

BP-BV300 BP-BV200
I

Features Product Appearance

Ⅱ

Battery Basic Features

•Patented intelligent program, without any external
accessories, the battery can automatically switch
voltage 14.4V/28.8V intelligently.
•Bi-voltage battery, can output 14.4V power the
camera and lighting, also can output 28.8V power
camera and high power lighting.
•With 2*D-Tap,1*USB-C and 1*USB-A multiple
outputs options for equipment power supply.
•More safe and compatible structure, with rubber
corners can adapt to falling in the work without
damaging the shell.
•The ultra volume energy ratio design,use high power
cells,rechargeable Li-ion battery, no memory effect.
•Build in smart PCB for over-heat,over-charge,over-
discharge and over-current protections.
Ⅲ
Specification
BP-BV300
Capacity
Battery Output
D-tap*2 Output
USB-A Output
USB-C Input/Output
Discharge Temperature
Charge Temperature
Dimension
Weight
User Manual
Bi-Voltage Battery
Thank you for choosing to use the FXLION products
In order to enable you to correctly use, store and maintain the products,
please read the instructions carefully.
Packing List: 1.Battery BP-BV300 *1/BP-BV200 *1
14.4V 20.4Ah 293Wh / 28.8V 10.2Ah 293Wh
14.4V/18A (Max) / 28.8V/10A (Max)
14.4V/10A(Max) when battery in 14.4V status
16.0V/4A(Max) when battery in 28.8V status
5V/2.4A， 9V/2A， 12V/1.5A
5V/3A， 9V/3A， 12V/3A， 15V/3A， 20V/3A，
PD fast charge protocols,
available only when battery in 14.4V status.
-20℃~+55℃
0~+45℃
154mm (L)*100mm(W)*85mm(H)
1650g
2.User Manual *1
•5-level indicators.
•Precise program control show battery cycles/battery
voltage/battery current/power Percentage on LCD
screen.
•Build in smart communication system, can display
the battery voltage / battery capacity / operating time /
working current on the camera with communication
function.
•Can be charged by 16.8V V-lock or USB-C charger,
no need use 28V charger. Use special materials for
battery negative and positive can bear the temperature
up to 230℃, The problem of high-temperature
d a m a g e d c o m p o n e n t s c a u s e d b y h i g h c u r r e n t
discharge is solved.
BP-BV200
Capacity
Battery Output
E-Tap*2 Output
USB-A Output
USB-C Input/Output
Discharge Temperature
Charge Temperature
Dimension
Weight
14.4V 13.6Ah 196Wh / 28.8V 6.8Ah 196Wh
14.4V/18A (Max) / 28.8V/10A (Max)
14.4V/10A(Max) when battery in 14.4V status
16.0V/4A (Max) when battery in 28.8V status
5V/2.4A， 9V/2A， 12V/1.5A
5V/3A， 9V/3A， 12V/3A， 15V/3A， 20V/3A，
PD fast charge protocols,
available only when battery in 14.4V status.
-20℃~+55℃
0~+45℃
154mm (L)*100mm (W)*66mm (H)
1195g
