- Page 1 MIP 800 | MIP 1600 MIP 806CI | MIP 1606CI Multituner | IP streamers Operation instructions...
-
Page 2: Table Of Contents
Operation instructions | MIP 8-00 | MIP 16-00 | MIP 8-06 | MIP 16-06 Table of contents Product description ..................................... 5 1.1. General ......................................5 1.2. Scope of delivery ....................................5 1.3. Inputs/multituner ....................................6 1.4. Output transport stream ................................... 7 1.5. - Page 3 5.10. Logs ........................................ 41 5.10.1. Log entries ..................................... 41 5.11. Licenses ......................................42 5.11.1. Licenses for Software Extensions ............................42 Use of CA modules (MIP 08-06 and MIP 16-06) ............................44 6.1. Insertion of CA modules .................................. 44 6.2. CI menu ......................................44 6.2.1.
- Page 4 Use the device only as described in these operating instructions and in particular in accordance with the state of the art. If the device is used for other purposes, no warranty will be assumed! Herewith AXING AG declares that the marked products comply with the valid guidelines. WEEE Nr. DE26869279 | Electrical and electronic components must not be disposed of as residual waste, it must be disposed of separately.
-
Page 5: Product Description
1. Product description 1.1. General MIP 8-00 Eight independent multituner inputs Transmodulates 8 × DVB-S/S2/S2x/T/T2/C into 512 SPTS (Single Program Transport Stream) or 8 MPTS (Multi Program Transport Stream) MIP 8-06 Like MIP 8-00, with 6 CI slots MIP 16-00 16 independent multituner inputs Transmodulates 16 ×... -
Page 6: Inputs/Multituner
Operation instructions | MIP 8-00 | MIP 16-00 | MIP 8-06 | MIP 16-06 1.3. Inputs/multituner Devices with multituner can receive DVB-S/S2/S2x, DVB-T/T2 or DVB-C. For receiving DVB-T/T2 or DVB-C the LNB power has to be switched off before connecting a antenna cabel to one of the HF inputs (see 4.1.2 on page 16)! Direct connection to the LNBs The devices have a remote supply voltage for the LNB and DiSEqC 1.0 functionalities at the inputs. -
Page 7: Output Transport Stream
Feeding-in a redundant input signal (function on request) The AXING MIP-headend series can be fed from an additional redundant input signal source. Switching can be be triggered through various selectable criteria (input level, bit error rate etc.). In the example the DiSEqC command is used to switch from the main antenna to the redundant backup antenna. Both satellite antennas must be aligned to the same satellite reception position. -
Page 8: Smartportal
1.6. SMARTPortal The AXING SMARTPortal connects each AXING headend device with a cloud-based portal and thus provides worldwide access to the devices. The connection is password-saved and scrambled. The only requirement on site is an internet connection of the device e. g. via LAN, EoC, EoC-WLAN-Bridge, 3G/LTE-Router. -
Page 9: Display Elements And Connectors
1.7. Display elements and connectors 1. LED IPTV stream: Green (blinking) No IPTV stream (no input signal, tuner not configured, no program selected, no program configured for output) Green IPTV stream ok IPTV stream overload. 2. Equipotential bonding connection 3. Mains connection 4. -
Page 10: Mounting And Installation
Operation instructions | MIP 8-00 | MIP 16-00 | MIP 8-06 | MIP 16-06 2. Mounting and Installation Installation must be performed by authorized and skilled electricians only. Before mounting and installation, pull the mains plug (1)! The antenna system must be installed and grounded according to the EN 60728-11 standard. 2.1.1. -
Page 11: Rf Installation
2.4. RF Installation 2.4.1. Connection to DVB-S/S2/S2x Connection to the LNBs On the SAT-IF input the devices have a remote supply voltage for the LNB and use DiSEqC 1.0 functionalities. Therefore, they can be connected directly to the LNB. Multiswitches as input distributors Optionally, you can also use multiswitches as input distributors. -
Page 12: Configuration
Operation instructions | MIP 8-00 | MIP 16-00 | MIP 8-06 | MIP 16-06 3. Configuration The device is configured via the graphical user interface of the integrated web interface. To access the user interface, you need a standard PC/laptop with a network interface and the actual version of the installed web browser. -
Page 13: Login And Logout
3.1. Login and logout The web-based user interface is protected against unauthorized access. When accessing the user interface, the first thing is the password request. Enter the default password: Ramsen8262 Click ENTER PASSWORD. If you are not automatically forwarded to the start page, click OPEN PAGE. -
Page 14: Front Page
Operation instructions | MIP 8-00 | MIP 16-00 | MIP 8-06 | MIP 16-06 3.2. Front page The relevant information required for the function of the system are shown on the front page. The decisive thing is the quality of the signals at the INPUT and the utilization of the OUTPUT. Input The bit error rate BER of all four tuners is shown on the left side. -
Page 15: Initialization
4. Initialization Choose INITIALIZATION from the main menu. 4.1. Phase 1 During the first phase of the initialization, the tuner settings required for the scan are made and the station scanning is carried out. The tuners work independently from each other and after the same principle. 4.1.1. -
Page 16: Dvb-C, Dvb-T Or Dvb-T2
Operation instructions | MIP 8-00 | MIP 16-00 | MIP 8-06 | MIP 16-06 4.1.2. DVB-C, DVB-T or DVB-T2 Before connecting an antenna cable to a tuner, the LNB Power has to be set to Off! Click TUNER 1…8/16 to select one tuner. ... -
Page 17: Bit Error Rate
4.1.3. Bit error rate The BIT ERROR RATE is shown. The amount of bit errors for the last 1,000,000 transferred bits is calculated. 4.1.4. Found programmes After a successful station scanning, the radio and TV stations are shown in the area FOUND PROGRAMS. The table contains information about the Program Name, the Type and the Encryption. -
Page 18: Initialization Phase 2
Operation instructions | MIP 8-00 | MIP 16-00 | MIP 8-06 | MIP 16-06 4.2. Initialization phase 2 In the initialization PHASE 2, the found programmes are subdivided by tuner. Depending on which transport stream output has been selected (SPTS or MPTS, see 5.2.1 on page 33), the programs are selected in phase 2. -
Page 19: Spts - Advanced Options
4.2.2. SPTS – Advanced options Below the settings for tuners 1 to 8 or 16, advanced options for the transport streams can be configured. Specify a special PID for the Event Information Table (EIT). In some countries the EIT is not transmitted with PID 18 (e.g. Israel PID 90). In this case, the headend can change this PID to PID 18. - Page 20 Operation instructions | MIP 8-00 | MIP 16-00 | MIP 8-06 | MIP 16-06 Specify a special PID of the Service Description Table (SDT). The Service Description Table (SDT) contains information about the transmitted programmes (services). It is usually transmitted with the PID 17.
-
Page 21: Mpts
4.2.3. MPTS If MPTS (Multi Program Transport Stream) is selected as the transport stream output (see 5.2.1 on page 33), then the programs can be assigned to the 8 or 16 output transport streams. All lines of the programme table have colored buttons M1, M2 …. The buttons correspond to the MPTS. The allocation of the buttons is given in the COLOR CODES legend. -
Page 22: Mpts - Cross Multiplex Mode
Operation instructions | MIP 8-00 | MIP 16-00 | MIP 8-06 | MIP 16-06 Assigning programmes Every tuner is assigned to an MPTS. The programmes of the tuner can only be assigned to the associated MPTS. For example, click in table TUNER 1 on M1. The program is assigned to MPTS 1. - Page 23 Assigning programmes to the MPTS In the cross multiplex mode, the tuners are no longer assigned to one MPTS. Programs, which are assigned to MPTS 1 Click e.g. in the table TUNER 2 to TUNER 3 on M1. The programs are assigned to MPTS 2. Spliting the programmes of a transonder If there are to much programms transmitted in one transponder, they can be splitted to several MPTS.
-
Page 24: Mpts - Advanced Options
Operation instructions | MIP 8-00 | MIP 16-00 | MIP 8-06 | MIP 16-06 4.2.6. MPTS – Advanced options In Phase 2 click on ADVANCED OPTIONS. A dialog with options will open. Specify a special PID for the Event Information Table (EIT). In some countries the EIT is not transmitted with PID 18 (e.g. - Page 25 Add non-referenced PIDs To enable an Over-the-Air upgrade, non-referenced PIDs can be manually added to the output modulators. Notes: • The function requires a valid license for “PID-Filtering” (see 5.11 on page Fehler! Textmarke nicht definiert.). • In PHASE 1 a transport stream must already be selected which contains the unreferenced PID/PIDs. To enable an Over-the-Air upgrade, non-referenced PIDs can be manually added to the output modulators.
-
Page 26: Select All Programs
Operation instructions | MIP 8-00 | MIP 16-00 | MIP 8-06 | MIP 16-06 4.2.7. Select all programs Activate the option Select all incoming programs, with each program of the tuner the button is activated. 4.2.8. LCN (Logical Channel Numbering) The LCN function enables channel allocation for the station scan of the TV devices. -
Page 27: Pid Filtering (With Mks 1-01)
4.2.10. PID Filtering (with MKS 1-01) The transport streams consist of packets that are identified by PIDs (Packet Identifier). With the fee-based software extension MKS 1-01, individual packages can be filtered out of the transport stream. Click on one of the programs. The table with the packages contained in the program is opened. -
Page 28: Initialization Phase 3
Operation instructions | MIP 8-00 | MIP 16-00 | MIP 8-06 | MIP 16-06 4.3. Initialization phase 3 In PHASE 3, the output transport streams are configured. 4.3.1. SPTS If SPTS (Single Program Transport Stream) is selected as the transport stream output (see 5.2.1 on page 33), then to each transport stream is assigned a destination address. -
Page 29: Mpts
4.3.2. MPTS If MPTS (Multi Program Transport Stream) is selected as the transport stream output (see 5.2.1 on page 33), then each of the 8/16 output MPTS is individually configured. Output mode Choose between the following options: • Disabled = no output transport stream •... -
Page 30: Fill Level
Operation instructions | MIP 8-00 | MIP 16-00 | MIP 8-06 | MIP 16-06 4.3.3. Fill level The fill level depends on the number of activated channels in Phase 2. The data rate of the channels on the DVB-S/S2/S2x transponders may vary depending on the image contents and on the transmission quality. -
Page 31: Maintenance
5. Maintenance In the menu item MAINTENANCE, status information of the head-end can be viewed and the technical conditions can be configured. 5.1. STATUS 5.1.1. Current Settings Under Current Settings, you will find the following information: • Firmware version: Displays the firmware version •... -
Page 32: Updating Software
We recommend the AXING SMARTPortal for easier handling and overview (see 1.6 on page 8) Download You can find software/firmware updates for download by entering the article in the search field on www.axing.com. On the product page you will find the current software/firmware in the Downloads tab. -
Page 33: Output
5.2. OUTPUT 5.2.1. Select transport stream output Under TS OUTPUT, the type of transport stream and the number of transport stream packets are selected. Depending on the configured transport stream, the output signals are output as MPTS (Multi Program Transport Stream) or as SPTS (Single Program Transport Stream). -
Page 34: System
Operation instructions | MIP 8-00 | MIP 16-00 | MIP 8-06 | MIP 16-06 5.3. SYSTEM 5.3.1. Changing the IP addresses The network options are configured under the menu item SYSTEM OPTIONS. • In the Control tab, the Control interface to which the computer is connected to configure the MIP is configured. •... -
Page 35: Changing The Password
5.3.2. Changing the password The default password is: Ramsen8262. The default password should be changed right after commissioning the device. Type an new password with 8-10 characters (letters and/or digits). Re-enter the password. Click SAVE CHANGES to confirm and save the changes. When the changes are saved, the frontpage will be shown. -
Page 36: Save Initialization Data
Operation instructions | MIP 8-00 | MIP 16-00 | MIP 8-06 | MIP 16-06 5.4.2. Save Initialization Data In the section SAVE SYSTEM INITILIZATION DATA TO FILE you can save the current initilization data from phase 1 to 3 into a file on your computer. -
Page 37: Output List For All Devices
5.4.4. Output list for all devices You can create a common output list for all devices in the network. Select the headends to be included in the channel list. Notes: The device to which you are logged on is named "This device" and is always selected. ... -
Page 38: Smartportal
In the State field, select Enabled. Activate, if required, the option AXING support allowed. In the field Location, enter a name for the location of the device. This name will appear later in the SMARTPortal to help you identify the device. -
Page 39: Snmp
MIB object definition The MIB object definition is stored in the device. Click AXING-MIB.txt to open the definition. If you are connected to the device in the network, then you can download the file from the device. URL = [IP address of device] /MIB/AXING-MIB.txt For example: 192.168.0.145/MIB/AXING-MIB.txt... -
Page 40: M3U
By default, the headend supports the "SNMP v1/v2 Public" profile (community name "public"). The following SNMP settings must be changed to also display the CPU load: Select Axing Device → Settings Scroll down to "SNMP Compatibility Options". Disable "Inherit from". -
Page 41: Adding Further Streams To The M3U List
5.8.2. Adding further streams to the M3U list The M3U list initially contains only streams of the MIP headend. If additional streams, e.g. from an HKI headend, are fed in, then these streams can be added under Other Services. These are then also contained in the M3U file and can be read out by the set-top boxes or Smart TVs. -
Page 42: Licenses
Purchase licenses You can purchase a license by ordering the appropriate software extension from AXING. When ordering, you must provide the serial number of the headend. A license file will be generated for you to match exactly this serial number. Important: The... - Page 43 Under UPLOAD A NEW LICENSE, select a LICENSE FILE. Click on UPLOAD. The upload will take a few seconds. The new license is listed in the ACTIVATED LICENSES dialog. Reboot the device and log in again. The new function is only available after a restart of the headend. 2022-12-13 | Technical improvements, changes in design, printing- and other errors reserved.
-
Page 44: Use Of Ca Modules (Mip 08-06 And Mip 16-06)
Operation instructions | MIP 8-00 | MIP 16-00 | MIP 8-06 | MIP 16-06 6. Use of CA modules (MIP 08-06 and MIP 16-06) 6.1. Insertion of CA modules Up to six CA modules can be inserted into the CI slots at the front side of the MIP 8-06 or MIP 16-06. ... -
Page 45: Using Ci Menu And Rebooting The Cam
6.2.1. Using CI menu and rebooting the CAM The content of the CI menu depends on the CAM manufacturer and the card being used. Depending on the manufacturer, various settings are possible. Information on validity and authorisation are the most important. ... -
Page 46: Decryption Of Programmes
Operation instructions | MIP 8-00 | MIP 16-00 | MIP 8-06 | MIP 16-06 6.3. Decryption of programmes Scrambled programs are indicated by the abbreviation CA in the column Encryption of the TUNER table. By default, in the column Decrypt the option no is choosen. If CA modules are plugged in, the corresponding programs can be decrypted. -
Page 47: Technical Specifications
7. Technical specifications Type MIP 8-00 MIP 8-06 MIP 16-00 MIP 16-06 Inputs Number of tuners 8 × DVB- 8 × DVB- 16 × DVB- 16 × DVB- S/S2/S2x/T/T2/C S/S2/S2x/T/T2/C S/S2/S2x/T/T2/C S/S2/S2x/T/T2/C Connector 8 × F-female 8 × F-female 16 × F-female 16 ×... - Page 48 IEEE 802.3, 1000 Base-T /1 GbE Configuration interface 1 × RJ-45 Compliance configuration IEEE 802.3, 100 Base-T interface Supported configuration protocols HTTP, SNMP v1, SNMP, v2c, AXING SMARTPortal* General Operating voltage 100…240 VAC/50…60 Hz Power consumption 70 W Redundant power supply 2 ×...
