Summary of Contents for MVP OSION OCM-350
- Page 1 Commercial Ice Makers USER INSTALLATION & MAINTENANCE MANUAL OSION MODULAR MODELS: OCM‐350, OCM‐500, OCM-1000...
-
Page 2: Table Of Contents
Contents Safety information Warning information ....................... Caution information ....................... Installation information Unpacking ..........................Water supply and ambient temperature................Electrical ..........................Pre-start up Check........................Operating instruction Digital & indicator display and controller ................6 Ice production .......................... Ice harvest ..........................Standby............................Ice full............................ -
Page 3: Safety Information
Safety information Before using your ice machine, please read this manual thoroughly to ensure that you know how to operate the features and functions that the equipment offers safely and efficiently. Important safety symbols and precautions: Please read and always follow all safety instructions in this manual. This is the safety alert symbol. -
Page 4: Installation Information Unpacking
All replacement parts must be Original Equipment Manufacturer (OEM) and obtained from the equipment manufacturer (MVP Group). 5- Due to potential safety hazard risk, make sure that the power plug is not bent, or damaged;... -
Page 5: Water Supply And Ambient Temperature
Water supply and ambient temperature 1- The water used for the ice machine must be in accordance with local drinking water quality standards. We recommend installation of an incline water filter to the ice machine, this will reduce limescale build up, improve efficiency and extend the overall lifespan of the machine. 2- Water supply pressure should be between 0.2psi and 0.8psi. -
Page 6: Electrical
Electrical The ice machine must be plugged into an independent power source or an electrical socket of voltage and frequency specified. Electrical rating information can be found on the name plate of the machine. Do not operate this machine above or below the voltage specified on the machine name plate;... -
Page 7: Pre-Start Up Check
Pre-start up checklist 1- Has the unit been connected to the proper water supply and no leaks? 2- Has the unit been connected to a drain and no leaks? 3- Has the unit connected to the proper electrical supply? 4- Has the unit been leveled? 5- Have all packing materials been removed from the ice machine? 6- Is there proper ventilation around all sides of the ice machine? 7- Has the unit been correctly grounded? -
Page 8: Operating Instruction
Operating instruction Your ice machine features a touch control to operate the controls, please lightly tap the control button with your fingertip. The control panel also features an easy read display which showing the status of the ice machine all times. Digital&... -
Page 9: Ice Production
Ice production Tap the start/standby button for 3 seconds to start ice making, The button will illuminate green and the ice making indicator will illuminate green, ice making time will be display in the digital window. Water inlet valve, compressor & water pump will start and operate step by step to cool the evaporator to begin to make ice. -
Page 10: How To Set Up Ice Making Cycle Time
Note: When first starting the ice maker, the system will rinse itself prior to making any ice. The rinsing process takes about 5 minutes. How to set the delay and resume ice production The delay is a key feature that allows the operator to set 0-24 hours delay in ice production. This makes it possible to better manage ice production and lower costs. -
Page 11: Maintenance & Cleaning
Maintenance & Cleaning Periodic cleaning and proper maintenance will extend the life of your ice machine, ensure maximum efficiency and delivery better ice to your customer. Warning: Disconnect the ice machine from the main electrical and water source before performing and cleaning or any maintenance Warning: Inspection, descaling and servicing should only be undertaken by a qualified technician. -
Page 12: Water Distributor, Water Tank And Float Switch Cleaning
Warning: Failure to clean the condenser could cause component failure and will VOID your warranty. Warning: Be careful when doing the condenser cleaning as the edges of the condenser and pins are very sharp. Water distributor, water tank and float switch cleaning Minerals, dirt and lime scale that are present in the water during the freezing cycle will build up in the water distributor, water tank and other areas. - Page 13 or disconnect. Inefficient Check the compressor, compressor replace if necessary solenoid valve not Check and replace valve harvest opening if necessary overtime Ice making time set Make sure the set time too short (ice too of ice making cycle is thin) comply with the suggest time...
-
Page 14: Wiring Diagram
short circuit Condenser sensor fault of the defective condenser Connector lose or sensor disconnect open circuit Water temperature Check water fault of water sensor defective temperature sensor, temperature replace if necessary Connector lose or disconnect short circuit Water temperature fault of water sensor defective temperature Connector lose or...
