Instructions – Parts List
180_ Spray Nozzle
Adapter
Important Safety Instructions
Read all warnings and instructions in this manual.
Save these instructions.
3600 psi (24.8 MPa, 248 bar) Maximum Working Pressure
Model 235486
For use on any Graco high pressure gun or extension and with the
RACr IV, RACr 5, and RAC Xt DripLesst Tip Guard or a Standard
flat tip guard.
GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440-1441
Copyright 1992, Graco Inc. is registered to I.S. EN ISO 9001
308244 Rev.B
01512
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Graco 235486
Summary of Contents for Graco 235486
- Page 1 3600 psi (24.8 MPa, 248 bar) Maximum Working Pressure Model 235486 For use on any Graco high pressure gun or extension and with the RACr IV, RACr 5, and RAC Xt DripLesst Tip Guard or a Standard flat tip guard.
- Page 2 WARNING INJECTION HAZARD Spray from the gun, leaks or ruptured components can inject fluid into your body and cause extremely serious injury, including the need for amputation. Fluid splashed in the eyes or on the skin can also cause serious injury. D Fluid injected into the skin may look like just a cut, but it is a serious injury.
- Page 3 Installation Installation WARNING 1. Install the adapter on the gun as shown, but do not install a spray tip yet. Be sure the gaskets are in INJECTION HAZARD place. Follow the Pressure Relief Procedure when you stop spraying and before 2.
- Page 4 With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
