Instructions - Parts List
180° Spray Nozzle Adapter
For professional use only.
Important Safety Instructions
Read all warnings and instructions in this manual. Be familiar
with the controls and the proper usage of the equipment.
Save these instructions.
3600 psi (24.8 MPa, 248 bar) Maximum Working Pressure
Model 235486
For use on any Graco high pressure gun or extension and with the
RAC
®
IV, RAC
®
5, and RAC X™ DripLess™ Tip Guard or a Standard
flat tip guard.
ti26835a
Ref.
Part
Description
1
166969 GASKET, non-metallic
2
NOZZLE, spray angle 180°
308244C
1
2
Qty.
1
1
EN
