Summary of Contents for Knick P43000
- Page 1 P43000 User Manual High Voltage Transducer Read before installation. www.knick.de Keep for future use.
- Page 2 P43000 Supplemental Directives READ AND SAVE THIS DOCUMENT FOR FUTURE REFERENCE. BEFORE ATTEMPTING TO ASSEMBLE, INSTALL, OPERATE OR MAINTAIN THE PRODUCT, PLEASE ENSURE A COMPLETE UNDERSTANDING OF THE INSTRUC- TIONS AND RISKS DESCRIBED HEREIN. ALWAYS OBSERVE ALL SAFETY INFORMATION. FAILURE TO COMPLY WITH INSTRUCTIONS IN THIS DOCUMENT COULD RESULT IN SERIOUS INJURY AND/OR PROPERTY DAMAGE.
-
Page 3: Table Of Contents
P43000 Table of Contents 1 Safety............................. 1.1 Intended Use ................................. 1.2 Personnel Requirements ........................... 1.3 Isolation ................................... 2 Product ............................2.1 Package Contents ..............................2.2 Product Identification............................2.3 P43000D2 Basic Type Ranges .......................... 2.4 Nameplates ................................2.5 Symbols and Markings............................ -
Page 4: Safety
Messgeräte GmbH & Co. KG (sometimes hereafter referred to as “Knick”) using the information provided on the back page of this document. 1.1 Intended Use The P43000 is a high voltage transducer for measuring unipolar or bipolar input currents in the range of 0 … (±)100 mA to 0 … (±)5 A Application Example, p. 9 ➜... -
Page 5: Product
Note: The User Manual (this document) is published in electronic form. knick.de ➜ 2.2 Product Identification The different versions of the P43000 are encoded in a model designation. The model designation can be found on the nameplate and the delivery note. Nameplates, p. 7 ➜... -
Page 6: P43000D2 Basic Type Ranges
Installation and Commissioning, p. 11 ➜ Note: The terminal assignments for the current input are dependent on the version of the P43000. The assignments are specified on the nameplate and are available on request. info@knick.de ➜... -
Page 7: Nameplates
P43000 2.4 Nameplates The P43000 is identified by nameplates on the side and front of its housing. The information on the nameplates varies depending on the version of the product. Product Identification, p. 5 ➜ Additional Input Ratings (UL 347):... -
Page 8: Symbols And Markings
The P43000 is available in different versions. The product properties vary depending on the version. Product Identification, p. 5 ➜ The unipolar or bipolar input signal is detected by the P43000 and converted into a standardized ana- log output signal. Block Diagram, p. 9 ➜... -
Page 9: Block Diagram
P43000 2.6.2 Block Diagram C 1 nF Current Input Z 15 V Output V/I – ≤ 5 A – – ≤ 2 A Power supply 20 ... 253 V AC/DC 2.6.3 Application Example Note: The figure shows an example of direct measurement at high input potential. The specified values refer to the P43100D2-nnnn version. -
Page 10: Terminal Assignments
Installation and Commissioning, p. 11 ➜ Note: The terminal assignments for the current input are dependent on the version of the P43000. The assignments are specified on the nameplate and are available on request. info@knick.de ➜... -
Page 11: Installation And Commissioning
Reset the electrical system to its initial state. Reverse the steps taken to ensure voltage-free operation. Switch on the power supply. Note: The power supply to operate the P43000 is provided by an integrated broad-range power supply (20 … 253 V AC/DC). See also Nameplates, p. -
Page 12: Operation
Nameplates, p. 7 ➜ 2.10 Maintenance The P43000 does not require any maintenance. Because it is fully encapsulated, it is not possible to repair the product. 2.11 Troubleshooting USE CAUTION WHEN CONDUCTING ANY TROUBLESHOOTING. FAILURE TO ABIDE BY THE REQUIREMENTS SET FORTH HEREIN MAY RESULT IN SERIOUS INJURY OR DEATH, AS WELL AS DAMAGE TO PROPERTY. -
Page 13: Decommissioning
Check the input of the P43000 to ensure it is dead. Switch off the power supply. Open the screw terminals with a screwdriver and remove the cables. Pull down the housing’s base latch using a screwdriver. Lift the P43000 up and off the 35 mm DIN rail. 2.12.2 Return If required, send the product in a clean condition and securely packed to your local contact. -
Page 14: Dimension Drawings
P43000 2.13 Dimension Drawings Note: All dimensions are given in millimeters [inches]. -
Page 15: Specifications
P43000 2.14 Specifications Input Input P43000D2 ±1 A, ±1,5 A, ±2 A, ±3 A, ±5 A, bipolar Calibrated switching Factory setting: ±5 A P43000D2‑nnnn 0 … (±)100 mA to 0 … (±)5 A, unipolar/bipolar 1 to 16 ranges to customer requirements, calibrated switching P43100D2‑nnnn 0 … (±)100 mA to 0 … (±)5 A, unipolar/bipolar To customer requirements, fixed setting Input resistance < 0.6 Ω... - Page 16 3600 V AC (45 … 65 Hz) / DC Input impedance < 0.6 Ω BIL/rated surge voltage 30 kV (1.2/50 µs) Overvoltage category Pollution degree P43000 does not contain any components that require maintenance. Use copper cables only. Standards and Approvals Product standard EN 61326‑1 Emitted interference Class B Immunity to interference Industrial applications Listed according to UL 347...
- Page 17 P43000 Device MTBF Approx. 96 years Ambient temperature Operating −10 … 70 °C (14 … 158 °F) Transport and storage -40 … 85 °C (-40 … 185 °F) Ambient conditions Indoor use Relative humidity 5 … 95 %, no condensation Altitude up to 2000 m (6500 ft), air pressure: 790 … 1060 hPa Design Modular housing with screw terminals (max. tightening torque 0.8 Nm)
-
Page 18: Abbreviations
P43000 Abbreviations Basic impulse level (rated insulation voltage according to UL 347) Conformité Européenne (European conformity) Electromagnetic compatibility European standard Electrostatic discharge International Protection / Ingress Protection MTBF Mean time between failures Overvoltage category Pollution degree UKCA United Kingdom Conformity Assessed... -
Page 19: Index
P43000 Index 35 mm DIN rail Nameplate Device front 7 Side 7 Application example 7 Approvals Notes on safety information Base latch Order code Basic type Output Causes, malfunctions Package contents Conformity Personnel Personnel requirements Power supply Product code Dimension drawing... - Page 20 Knick Elektronische Messgeräte GmbH & Co. KG Headquarters Beuckestraße 22 • 14163 Berlin Germany Phone: +49 30 80191-0 Fax: +49 30 80191-200 info@knick.de www.knick.de Local Contacts www.knick-international.com Translation of the original instructions Copyright 2023 • Subject to change Version 6 • This document was published on April 20, 2023.
