- Page 1 Manual Frame Size: 205mmx60mmx121mm wheel b ase: 145mm Full weight: 550g Motor: 2030/20T 4650KV Brushless ESC: Brushless 18A Battery: 7.4V/25C 1000mAh LiPo Servo: Digital 1.5kg...
- Page 2 Thank you for purchasing ALZRC Rider R-100S. We believe that this new motorcycle will bring you infinite happiness. Before use, please read the manual carefully and safe keeping. Accidents arecaused by illegal use, the company doesn't undertake any responsibility. Rider R-100S is a high performance mini RC motorcycle. This product has like the real motorcycle setting, the perfect design of the front wheels inverted shock absorber and rear wheel pendulum arm suspension, achieves reliable grip performance.
- Page 3 【Safety Precautions / 】 安全说明 1. The specification of the logo 关于本说明书中使用标识 Caution: this symbol indicates where caution is essential to avoid injury to yourself or others. Note: this symbol indicates where give you a tip in use. 注意：此标识提醒您注意避免伤害到自己及其他人。 提示：此标识是作为一个小提示供使用过程中一个参考。 2.
- Page 4 5. The range of use 关于产品的使用范围 · Do not run your car in sandy,dusty,wet conditions,on long wool carpet. Such surfaces can damage its operating parts. · Do not operate the model on public roads, in crowded places or near infants. It may cause accidents or injury. ·...
- Page 5 链条 Driver Chain Tail Frame 车架尾兜 Rear Fender 后轮挡泥板 Shock Absorber 减震器 Steering Linkage set 转向杆 Handle Arm 车头扶手 Steering Triple 前减震器固定板 Servo 机 舵 Main Frame 车架 Oil Damped FR Fork 前避震器 Front Brake Disc 前刹车碟 Front Brake Caliper 前刹车卡钳...
- Page 6 Tool Required： 以下工具在操作中有可能会使用到 Hex screwdriver,Cross Wrench,Cross Screwdrive,Tweezers,Hex Wrench. 内六角螺丝刀，车用小十字扳手，十字螺丝刀，镊子，内六角扳手。 Step 2. Remove the R-Clip and the body shell. 将车壳和车尾壳底部的R扣拆下并取出上下壳 Step 3. Connect the battery with the ESC 连接电池与电子调速器的接线 the ESC in off state.Do not reverse the positive and negative charges. 注意：电池连接电调前，请保持电调处于关闭状态接线时不要接反...
- Page 7 Channel Antenna Wire “1”: Steering(CH1) 转向 通道 天线 “2”: Throttle(CH2) 油门 “3”: Aux（CH3) 第三动作 LED Indicator “B”: Power 电源 Pair/Setup Button LED指示灯 配对/设置按键 *Transmitter Battery Installation 发射机电池安装* To open slide cover Install Batteries To close slide cover 打开滑动盖 安装电池 关闭滑动盖 *Transmitter Adjustment 发射机教准...
- Page 8 *Fall Safe Setup 失控保护 的设定方法 Please note the setup must based on pair procedure well. 1. Turn the power switch on the transmitter & receiver to the ON position, the LED on transmitter & receiver are continuously lit. 2. Move the steering wheel or throttle trigger to the position where you want the servo to move, press and hold the receiver setup button for 2 second until the red LED on the receiver flash slowly, then press and hold the receiver setup button again within 5 seconds(Note: after 5 seconds F/S setup will reset, you have to start over at step one above)until the receiver LED is continuously lit, that’s mean the F/S function has been correctly set.
- Page 9 【Steering Setup / 】 正确行驶的技术要领 Basic Controls: 基本操作 Caution : RC Motorcycle comes with a Counter-Steering System. It means the direction between thetransmitter steering wheel and the motorcycle front wheel are opposite. 注意：遥控摩托车的操作系统是反向的，遥控器的操控轮与摩托车前轮的方向相反。 N eut r a l R igh t Le ft 【Steering Setup / 】...
- Page 10 To make a right turn,turn the If the balance bar touches the ground, When upright,straighten(neutral) steering wheel to the right. The steering. the motorcycle will not turn well. Turn motorcycle should lean to the steering left to return to upright posture. right.
- Page 11 【Instal lat ion Inst ruct ions / 】 安装说明 Install Note：To prevent parts from rolling off and protect the working surface,you could put all the small parts into a container. 安装注意 : 为保护零配件,可以将所有的零配件放入容器中。 【P1-1】 B/M2x5 M2(S) P/M2x5 BL/Ø8xØ5x2.5 JM/M2x3 B/M1.6x6 A#22 B/M2x5 【P1-2】...
- Page 12 FB/M2x12 【P2-2】 B/M1.6x4 ？ Note：Apply gear silicone oil#10000 on the shaft and the spring. ？ 提示：管身和弹簧涂 上#10000号专 用波箱润滑油。 05-L 【P3-2】 【P3-1】 FB/M2x5 FB/M2x5 FB/M2x8 05-R 【P3-3】 【P3-4】 FB/M2x20 FB/M2x8 BL/Ø6xØ3x2.5 04-X BL/Ø7xØ3x3 FP/M2x10 FP/M2x5 B/M2x5 Note：These three frame posts is individuallyon the metal transmission, should use the socket 97-1 ？...
- Page 13 【P3-5】 【P3-6】 R/M2.5x4 JM/M3x3 FB/M2x6 Caution: The space between the two gears should be the same thickness as one piece of A4 paper. We can put one piece of A4 paper between the two gears before assembly and take it away after finish. 注意：...
- Page 14 64-L 03-L 【P3-8】 【P3-9】 FB/M2x8 FP/M2x5 SM2.5 R/M3x20 FB/M2x4 FB/M2x5 R/M1.6x4 FB/M2x20 【P4-1】 【P4-2】 B/M1.6x4 40-B 42-A BL/Ø6xØ3x2.5 JM/M3x3 BL/Ø6xØ3x2.5 B/M2x14 Note: The suer could adjust the effect of the rear suspension according to different ？ racing ground by installing shock body spacer. 提示：...
- Page 15 【P4-5】 【P4-6】 *The receiver is not install by default. *出厂默认没有安装接收机。 FR/M2x5 【P4-7】 【P4-8】 JM/M2x3 JM/M3x3 R/M1.6x4 62-B JM/M3x3 B/M1.6X6 JM/M3x3 【P4-9】 【P4-10】 左刹车 Left 右刹车 24/Ø1.5xØ 0.3x115(Left)(左) Right 23/Ø1.5xØ 0.3x120(Right)(右) 22/Ø1.5xØ 0.3x150(Back)(后) 18/Ø04x200(Left/Right)(左/右) 19/Ø04x230(Back)(后) JM/M2x3...
- Page 16 【P4-11】 电调开关 ESC Switch Note：Factory have made sp for the LED light and exhaust pipe on the tail frame part, the user can according to personal preference to install. ？ 提示：在尾兜部分预留了LED灯与排烟管的位置，客户可根据个人喜好安装。 FB/M2x6 69-B 【P4-12】 【P4-13】 FB/M2X5 69-B 79-R 67-B 79-L A#71-1 A#71-2 69-B A#72...
- Page 17 Rider/R-100S Parts List 零件表 Part Name 零件名称 Qty/数量 Ref ./No图号 Fork Bottom Plug 37-B 前油压盖 （底） Ref ./No图号 Part Name 零件名称 Fork body Qty/数量 37-C 前油压管身 波箱 Steering Pivot 转向臂 Transmission 波箱盖 Frame Post 39-B 车架支柱 Transmission Cover 车架侧板 Frame Post...
- Page 18 Ref ./No 图号 Part Name 零件名称 Qty/数量 Part Name Qty/数量 Ref ./No图号 零件名称 Side Frame Plate Post 车架侧板定位柱 Rear Tire A#99 后轮胎 Socket Head ScrewM1.6x4 Brake Disc Holder 转向拉杆弹簧 B/M1.6x4 杯头螺丝M1.6x4 78-B Socket Head ScrewM1.6x6 Brake Disc Holder 刹车碟托 B/M1.6x6 杯头螺丝...
-
Page 19: Troubleshooting
【Trouble Shooting / 】 常见故障排除 The motorcycle does The motorcycle is out of Poor performance of Trouble Short run time not move control the motorcycle Battery in motorcycle or Transmitter or antenna Battery maby be Suspension may not run freely. transmission is no power.
