- Page 1 组装手册 INSTRUCTION MANUAL RC HELICOPTERS...
- Page 2 操作之前，请务必详阅本说明书，相信一定能够给您带来相当大的帮助，也请您妥善保管这本说明书，以作为日后参考。 Thanks for choosing ALZRC, there’s some matters need attention and knowledge you need to know, then just enjoy flying with remote control helicopter. Before you begin, please read this manual very carefully for your safety and also keep this manual properly for reference.
- Page 3 DEVIL 380 FAST 三桨旋翼头升级套件 TBR UPGRADE SET 金属主旋翼夹座组 x 3 Metal Main Rotor Holder Assembly x 3 Chapter 1 TBR 金属主旋翼夹座摇臂 TBR Metal Main Rotor Holder Arm 金属主旋翼夹座 Metal Main Rotor Holder 轴承 Bearing Φ5xΦ10x4mm 已经完成组装 AIready Assembled 圆头内六角螺丝 Socket Button Head Screw 出厂零件包装如果是已组装品，请务必确认各部件是否...
- Page 4 DEVIL 380 FAST 三桨旋翼头升级套件 TBR UPGRADE SET TBR 主旋翼夹座连杆组 x 3 TBR Blade Grip Linkage Assembly x 3 法兰轴承 Chapter 3 Flange Bearing Φ2.5xΦ6x2.5mm 十字盘到主旋翼夹座摇臂的初始长度。 Initial length for the rods from the swashplate to the main rotor holder arm. 主旋翼夹座连杆...
- Page 5 DEVIL 380 FAST 三桨旋翼头升级套件 TBR UPGRADE SET TBR 主旋翼组 TBR Main Rotor Head Assembly Chapter 5 对于强劲3D飞行或高转速转动，建议横轴垫圈与轴承之间至少 加一片垫片。大约20个起落后，请检查虚位，如果感觉松散， 可以再增加一片垫片。 We recommend assembling with at least one washer between the damper and bearing for 3D flight or high RPM. After about 20 flights, please manually check the head dampening, you can add one 0.1mm washer if the...
- Page 6 DEVIL 380 FAST 三桨旋翼头升级套件 TBR UPGRADE SET TBR 主旋翼组安装 Installation of TBR Main Rotor Head Chapter 7 第6步组装完成 圆头内六角轴套螺丝 Assembled in Chapter 6 Socket Collar Screw 防松螺帽 M3x18mm Locking Nut TBR 碳纤主旋翼 TBR Carbon Fiber Blades 360mm 第4步组装完成 Assembled in Chapter 4 防松螺帽...
- Page 7 RC HELICOPTERS...
