- Page 1 INSTALLATION INSTRUCTIONS VOLT LOW VOLTAGE LANDSCAPE LIGHTING ® VOLT Mini Brass MR8 Spotlight (Bronze) ® ITEM: VAL-2016 1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)
- Page 2 INSTALLATION INSTRUCTIONS VOLT Mini Brass MR8 Spotlight - VAL-2016 ® IMPORTANT: PLEASE READ BEFORE INSTALLATION This luminaire is intended for installation in accordance with local codes and the National Electric Code (NEC). Failure to adhere to these codes and instructions may result in serious injury, property damage and void the warranty.
- Page 3 PACKAGE CONTENTS A. (1) Fixture Body PARTS REQUIRED A. (1) MR8 Bulb B. Mounting Accessory PRODUCT DIMENSIONS 4” 1.13” 1.5” 1” Remove Glare Guard Loosen the set screw and Glare remove the glare guard from the Guard fixture body. Fixture Body Set Screw 813.978.3700 •...
- Page 4 INSTALLATION INSTRUCTIONS VOLT Mini Brass MR8 Spotlight - VAL-2016 ® Install MR8 Bulb Insert MR8 bulb with correct wattage and type marked on fixture label. MR8 Bulb CAUTION: Do not exceed maximum wattage marked Socket on luminaire label. Install Glare Guard...
- Page 5 Install Stake Determine the desired location for mounting the fixture. Hammer the Board stake into the ground until flange of stake is flush to grade. To avoid dam- age to the stake, place a board on top of the stake while hammering. Stake NOTE: If the ground is hard and the stake is difficult to install, make a...
- Page 6 INSTALLATION INSTRUCTIONS VOLT Mini Brass MR8 Spotlight - VAL-2016 ® Wire Connection Pigtail Wire Connectors Main Supply Cable Strip both the leads from the luminaire pigtail. Using two UL listed wire connectors (sold separately), connect the leads from the lumi- naire to the main supply cable leads.
- Page 7 813.978.3700 • customersupport@voltlighting.com • www.voltlighting.com...
- Page 8 1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST) Specifications and product details subject to change without notice. © Copyright 2023, VOLT Lighting, Lutz FL USA 33549 • All rights reserved. ® customersupport@voltlighting.com • www.voltlighting.com...
