INSTALLATION INSTRUCTIONS

VOLT

Solar Landscape Lighting

VOLT

Solar Spotlight

VSAL-9002-BBZ

Help Hotline:

1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)

Specifications and product details subject to change without notice.

customersupport@voltlighting.com • 813.978.3700

- 1 -

Need help?

Do you have a question about the VSAL-9002-BBZ and is the answer not in the manual?

Page 1 VSAL-9002-BBZ Help Hotline: 1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST) Specifications and product details subject to change without notice. © Copyright 2019, VOLT Lighting, Lutz FL USA 33549 • All rights reserved. ® customersupport@voltlighting.com • 813.978.3700 - 1 -...
Page 2 INSTALLATION INSTRUCTIONS Product Dimensions VOLT Solar Spotlight ® VSAL-9002-BBZ 6” Important: Please Read Before Installation 5.25” This luminaire is intended for installation in accordance with local codes and the National Electric Code (NEC). Failure to adhere to these codes and instructions may result in serious injury, property damage and void the warranty.
Page 3 INSTALLATION INSTRUCTIONS Adjust Luminaire Direction VOLT Solar Spotlight ® VSAL-9002-BBZ Loosen the set screw on the fixture, then rotate to the desired direction. Tighten the Install Stake set screw once the desired direction is achieved. Determine the location for Luminaire Board mounting the stake.
Page 4 INSTALLATION INSTRUCTIONS VOLT Solar Spotlight ® VSAL-9002-BBZ IMPORTANT INFORMATION Please note that these solar fixtures are equipped with built-in photocells, so they will not turn on until it is dark enough. These fixtures will also require plenty of sunlight to function properly. It’s best to have the fixture in an area where the sun will get to it at all times throughout the day and where no ambient lighting will affect the photocell at night.
