TOSHIBA
1
Tecra M4
Model
Description
Tecra M4-S115TD
Microsoft® Windows® XP Tablet Edition, Intel® Pentium® M 730 (1.6GHz 2MB L2
533MHz FSB), 40GB(Serial-ATA/5400rpm), 256MB PC4200 DDR2 533MHz SDRAM,
CD-RW/DVD-ROM, nVIDIA® GeForce™ Go 6200 TE 64M (64MB), 14.1" TFT LCD at
(1400 x 1050) native resolution (SXGA+), 6-cell battery, Bluetooth Antenna, Integrated
Wi-Fi™ Intel PRO\Wireless 2200BG (802.11b/g) Wireless-LAN, Gigabit Ethernet, TPM,
1-year standard limited warranty
System Characteristics
3
Operating System
•
Microsoft® Windows® XP Tablet Edition 2005
Intel® Centrino™ Mobile Technology featuring:
Choice of Processors
•
Intel Pentium® M Processor 730 [1.6GHz, 2MB L2, 533MHz
FSB]
•
Intel Pentium® M Processor 740 [1.73GHz, 2MB L2, 533MHz
FSB]
•
Intel Pentium® M Processor 750 [1.86GHz, 2MB L2, 533MHz
FSB]
•
Intel Pentium® M Processor 760 [2.0GHz, 2MB L2, 533MHz
FSB]
•
Intel Pentium® M Processor 770 [2.13GHz, 2MB L2, 533MHz
FSB]
Chipset
•
Mobile Intel 915PM Express Chipset
Choice of Integrated Wi-Fi™ compliant wireless LAN
•
Intel® PRO/Wireless 2200BG (802.11b/g)
•
Intel® PRO/Wireless 2915ABG (802.11a/b/g)
4
Memory
•
Configured with 256MB DDR2 SDRAM
•
256MB(min)/2048MB (max), 2 memory slots using 256MB,
512MB, or 1024MB PC4200 DDR2 533MHz SDRAM, dual-
channel support requires two memory modules. (both memory
slots may be occupied).
Mass Storage
Choice of Hard Disk Drives:
•
40GB (5400 RPM) Serial-ATA (SATA) hard disk drive; 9.5mm
height
•
60GB (5400 RPM) Serial-ATA (SATA) hard disk drive; 9.5mm
height
•
80GB (5400 RPM) Serial-ATA (SATA) hard disk drive; 9.5mm
height
Choice of Optical Disk Drives:
•
Slim SelectBay CD-RW/DVD-ROM
Maximum Speed:
CD-ROM (24x:read), CD-R (24x:write), CD-RW
(10x:write), DVD-ROM (8x:read)
Compatibility:
CD-ROM (read), CD-R (read/write), CD-RW (read/re-
write), DVD-ROM (read), DVD-R (read), DVD-RW (read),
DVD+R (read), DVD-RAM (read)
•
Slim SelectBay DVD SuperMulti drive (single layer):
Maximum Speed:
CD-ROM (24x:read), CD-R (24x:write), CD-RW
(10x:write), DVD-ROM (8x:read), DVD-R (8x:write), DVD-
RW (4x:write), DVD+R (8x:write), DVD+RW (4x:write),
DVD-RAM (3x:write)
•
Slim SelectBay DVD SuperMulti drive (double layer):
Maximum Speed:
CD-ROM (24x:read), CD-R (24x:write), CD-RW
(10x:write), DVD-ROM (8x:read), DVD-R (8x:write), DVD-
RW (4x:write), DVD+R (Double Layer) (2.4x:write),
DVD+RW (4x:write), DVD-RAM (3x:write)
5
Display
•
14.1" diagonal TFT active-matrix LCD display at 1400x1050
native resolution (SXGA+)
•
Contrast: 500:1
•
Brightness Control by Fn+F6/F7 and TOSHIBA Power Saver
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
2
© Copyright 2005 Toshiba America Information Systems Inc. All Rights reserved.
Tecra M4 BTO Rev. 1.06 2005-06-09 KK T20050418CB1.00
6
Choice of Graphics
•
NVIDIA® GeForce™ Go 6200 TE 64M (64MB DDR discrete
graphics memory)
•
NVIDIA® GeForce™ Go 6600 TE 128M (128MB DDR discrete
graphics memory)
Sound
•
Analog Devices AD1981B integrated 16-bit stereo software
sound
•
Built-in stereo speakers
•
Built-in microphone
•
Direct 3D Sound (supported by driver); DirectSound (supported
by driver), Direct Music (supported by driver), MIDI (play back)
support,
•
Sound Volume Control Dial
Input Devices
•
Keyboard
85 key US keyboard, 2.7mm key stroke, 6mm keyboard
o
height, 19.05mm key pitch
Hot Key Functions (FN); please see electronic User's Guide
o
for more information
Windows Key Function
o
Application Key Function
o
•
Pointing Devices:
Toshiba TouchPad™ and Accupoint™ dual pointing device;
o
Enable/Disable (FN+F9 or by help of software)
Toshiba Digitizer Tablet Pen
o
•
Buttons
Toshiba Presentation Button
o
Windows Security Button
o
ESC/Display Rotation Button
o
Cross Functional Button
o
Expandability
•
2 main memory slots. Both slots may be occupied.
•
1 Type II, PCMCIA R2.01, PC Card16, CardBus PC Card slot
•
Secure Digital®,slot
•
Docking port for Advanced Port Replicator III or Tablet Dock II
(see accessories)
Communications
•
Integrated V.92 modem
•
Marvell 88E8053 10Base-T / 100Base-TX / 1000Base-T
("Gigabit") Ethernet
•
Optional Bluetooth Version 2.0 plus Extended Data Range
(EDR) with TOSHIBA Bluetooth stack software
•
Choice of Integrated Wi-Fi™ wireless-LAN:
Intel® Pro/Wireless Network Connection 2200BG
o
(802.11b/g)
Intel® Pro/Wireless Network Connection 2915ABG
o
(802.11a/g)
Ports
•
RGB (monitor) port
•
TV-out (S-Video)
•
i.LINK(tm) IEEE-1394
•
3 Universal Serial Bus (USB) ports (v2.0)
•
External Microphone jack (monaural)
•
Headphone jack (stereo)
•
RJ-45 LAN port
•
RJ-11 modem port
•
Fast Infrared (4Mbps) (IrDA 1.1) port
•
240-pin docking connector
Part Number
UPC
PTM40U-01U00D
032017367326
7
