TOSHIBA
1
Tecra M4
Model
Description
Tecra M4-S435
Microsoft® Windows® XP Tablet Edition, Intel® Pentium® M 740 (1.73GHz 2MB L2
533MHz FSB), 60GB (Serial-ATA/5400rpm), 512MBx1 PC4200 DDR2 533MHz
SDRAM, DVD-SuperMulti (Double Layer), nVIDIA® GeForce™ Go 6200 TE (64MB),
14.1" TFT LCD at (1400 x 1050) native resolution (SXGA+), 6-cell battery, Bluetooth
Antenna, Integrated Wi-Fi™ Intel PRO\Wireless 2200BG (802.11b/g) Wireless-LAN,
Gigabit Ethernet, TPM, 3-year standard limited warranty; 1-year standard limited
warranty for battery and AC adapter
System Characteristics
3
Operating System
•
Microsoft® Windows® XP Tablet Edition 2005
Intel® Centrino™ Mobile Technology featuring:
•
Intel Pentium® M Processor 740 [1.73GHz, 2MB L2, 533MHz
FSB]
•
Mobile Intel 915PM Express Chipset
•
Intel® PRO/Wireless 2200BG (802.11b/g) Integrated Wi-Fi™
compliant wireless LAN
4
Memory
•
Configured with 512MB DDR2 SDRAM (512MBx1)
•
512MB(min)/2048MB (max), 2 memory slots using 256MB,
512MB, or 1024MB PC4200 DDR2 533MHz SDRAM, dual-
channel support requires two memory modules (both memory
slots may be occupied)
Mass Storage
•
60GB (5400 RPM) Serial-ATA (SATA) hard disk drive; 9.5mm
height
Optical Disk Drive:
•
Slim SelectBay DVD SuperMulti drive (double layer):
Maximum Speed:
CD-ROM (24x:read), CD-R (24x:write), CD-RW
(10x:write), DVD-ROM (8x:read), DVD-R (8x:write), DVD-
RW (4x:write), DVD+R (Double Layer) (2.4x:write),
DVD+RW (4x:write), DVD-RAM (3x:write)
5
Display
•
14.1" diagonal TFT active-matrix LCD display at 1400x1050
native resolution (SXGA+)
•
Contrast: 500:1
•
Brightness Control by Fn+F6/F7 and TOSHIBA Power Saver
6
Graphics
•
NVIDIA® GeForce™ Go 6200 TE 64M (64MB DDR discrete
graphics memory)
Sound
•
Analog Devices AD1981B integrated 16-bit stereo
•
Built-in stereo speakers,
•
Built-in microphone (monaural)
•
Direct 3D Sound (supported by driver); DirectSound (supported
by driver), Direct Music (supported by driver), MIDI (play back)
support
•
Sound Volume Control Dial
Input Devices
•
Keyboard
85 key US keyboard, 2.7mm key stroke, 6mm keyboard
o
height, 19.05mm key pitch
Hot Key Functions (FN); please see electronic User's Guide
o
for more information
Windows Key Function
o
Application Key Function
o
•
Pointing Devices:
Toshiba TouchPad™ and Accupoint™ dual pointing device;
o
Enable/Disable (FN+F9 or by help of software)
Toshiba Digitizer Tablet Pen
o
•
Buttons
Toshiba Presentation Button
o
Windows Security Button
o
ESC/Display Rotation Button
o
Cross Functional Button
o
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
2
© Copyright 2005 Toshiba America Information Systems Inc. All Rights reserved.
Tecra M4-S435 BTS Rev. 1.07 2005-05-19 KK T20050418CB1.00
Expandability
•
2 main memory slots. Both slots may be occupied.
•
1 Type II, PCMCIA R2.01, PC Card16, CardBus PC Card slot
•
Secure Digital®,slot
•
Docking port for Advanced Port Replicator III or Tablet Dock II
(see accessories)
Communications
•
Integrated V.92 modem
•
Marvell 88E8053 10Base-T / 100Base-TX / 1000Base-T
("Gigabit") Ethernet
•
Intel® Pro/Wireless 2200BG (802.11b/g) Integrated Wi-Fi
compliant wireless LAN
Ports
•
RGB (monitor) port
•
TV-out (S-Video)
•
i.LINK(tm) IEEE-1394
•
3 Universal Serial Bus (USB) ports (v2.0)
•
External Microphone jack (monaural)
•
Headphone jack (stereo)
•
RJ-45 LAN port
•
RJ-11 modem port
•
Fast Infrared (4Mbps) (IrDA 1.1) port
•
240-pin docking connector
Physical Description
•
Dimensions (WxDxH Front/H Rear): 12.91'' (289.7mm) x 11.41''
(328mm) x 1.45'' (36.9mm)[F]/1.51'' (38.4mm)[R] without feet
•
8
Weight
: 6.2 lbs. (2800g) (min) ~ 6.4 lbs. (2900g) (max)
depending upon configuration
Power Supply
•
75W (15V x 5A) Auto sensing external AC Adapter, 100~240V
50/60Hz (Universal) input.
•
Weight: starting at 0.78 lb. (355 g)
•
Dimensions (WxDxH): 5.00'' (127.0mm) x 2.01'' (51.0mm) x
1.20'' (30.5mm)
9
Battery
•
6-cell (4700 mAh) rechargeable, removable Lithium Ion (Li-Ion)
battery pack
Battery Life (6-cell battery): Up to 3 hours 22 minutes
o
(measured by MobileMark™)
Weight: starting at 0.75 lb. (338 g)
o
Recharge Time: approximately 3.0 hours (System Off) or
o
approximately 5.5 to 13.0 hours (System On)
•
Optional: 6-cell (3600 mAh) Slim SelectBay rechargeable,
removable Lithium Ion (Li-Ion) battery pack (see Accessories)
Battery Life (6-cell primary battery + 6-cell secondary
o
battery): Up to 6 hours 9 minutes (measured by
11
MobileMark™)
Weight: starting at 0.62 lb. (280 g)
o
Recharge Time (6-cell primary battery + 6-cell secondary
o
battery): approximately 6.0 hours (System Off) or
approximately 9.5 to 22.5 hours (System On)
Toshiba EasyGuard
Secure
•
Infineon® Trusted Platform Module embedded security chip
(Version 1.1)
•
Execute Disable Bit (XD Bit)
•
Physical Security
Part Number
UPC
PTM40U-0F0021
032017352216
7
10
Page 1 of 4
