R-410A
ZV SERIES W/SMART EQUIPMENT™
6.5 - 12.5 Ton
60 Hertz
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Preceding installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Limitations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Rigging and handling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Ductwork . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Side panels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Condensate drain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Compressors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Power and control wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Optional electric heat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Optional gas heat. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Options and accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Economizer sequences . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Power exhaust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Smart Equipment™ economizer board . . . . . . . . . . . . . . . . . . 44
Airflow performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
1 Component location table . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2 ZVT06 through T12 unit limitations . . . . . . . . . . . . . . . . . . . . . 8
5 ZVT06 through T12 unit accessory weights . . . . . . . . . . . . . 11
6 ZVT06 through T12 unit physical dimensions . . . . . . . . . . . . 13
7 ZVT06 through T12 unit clearances . . . . . . . . . . . . . . . . . . . 14
8 ZVT06 through T08 side duct dimensions . . . . . . . . . . . . . . . 17
9 ZVT10 through T12 side duct dimensions . . . . . . . . . . . . . . . 17
10 Left/end duct dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
11 Control wire sizes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
12 Electrical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
13 Physical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
14 Electric heat minimum supply air . . . . . . . . . . . . . . . . . . . . . . 35
15 Gas pipe sizing - capacity of pipe . . . . . . . . . . . . . . . . . . . . . 36
16 Gas heat minimum supply air . . . . . . . . . . . . . . . . . . . . . . . . 36
17 Supply air limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
18 Altitude/temperature correction factors . . . . . . . . . . . . . . . . . 49
19 Airflow performance - side duct application . . . . . . . . . . . . . . 51
20 Airflow performance - bottom duct application . . . . . . . . . . . 54
21 RPM selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
22 Indoor blower specifications . . . . . . . . . . . . . . . . . . . . . . . . . 56
1 Unit shipping bracket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2 Barometric relief hood - shipping location . . . . . . . . . . . . . . . 5
3 Compressor section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
4 ZV component location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
5 4 point and 6 point load weight for W units . . . . . . . . . . . . . . 10
6 4 point and 6 point load weight for V units . . . . . . . . . . . . . . 10
7 Center of gravity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
8 ZVT06 through T08 physical dimensions . . . . . . . . . . . . . . . 12
9 ZVT10 through T12 physical dimensions . . . . . . . . . . . . . . . 13
10 ZVT06 through T12 unit bottom duct openings . . . . . . . . . . 15
11 ZVT06 through T12 unit electrical entry . . . . . . . . . . . . . . . . 16
12 ZVT06 through T12 unit left/end duct opening . . . . . . . . . . . 18
13 ZVT06 through T12 roof curb . . . . . . . . . . . . . . . . . . . . . . . . 18
14 ZVT06 through T12 transition roof curb . . . . . . . . . . . . . . . . 19
15 Side panels with hole plugs . . . . . . . . . . . . . . . . . . . . . . . . . 20
16 Return downflow plenum with panel . . . . . . . . . . . . . . . . . . . 20
17 Discharge panel in place . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Table of contents
Air balance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Checking air quantity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Cooling operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Cooling Operation Errors . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Reheat mode sequence of operation . . . . . . . . . . . . . . . . . . . 62
Electric heating sequence of operations . . . . . . . . . . . . . . . . . 64
Electric heat operation errors . . . . . . . . . . . . . . . . . . . . . . . . 64
Gas heating sequence of operations. . . . . . . . . . . . . . . . . . . . 64
Ignition control board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Gas heating operation errors . . . . . . . . . . . . . . . . . . . . . . . . 65
Cooling start-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Gas heat start-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Checking gas heat input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Smart Equipment™ unit control board . . . . . . . . . . . . . . . . . . . . . 70
Charging the unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Start-up sheet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
List of tables
23 Power exhaust specifications . . . . . . . . . . . . . . . . . . . . . . . . 56
24 Motor sheave datum diameters . . . . . . . . . . . . . . . . . . . . . . 58
mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
26 Electric heat limit setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
27 Electric heat anticipator setpoints . . . . . . . . . . . . . . . . . . . . . 64
28 Gas heat anticipator setpoints . . . . . . . . . . . . . . . . . . . . . . . 66
29 Gas rate cubic feet per hour . . . . . . . . . . . . . . . . . . . . . . . . . 68
30 Gas heat stages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
31 Gas heat limit control settings . . . . . . . . . . . . . . . . . . . . . . . . 68
33 Ignition control flash codes . . . . . . . . . . . . . . . . . . . . . . . . . . 76
34 ZVT06 charging table - system 1 . . . . . . . . . . . . . . . . . . . . . 77
35 ZVT06 charging table - system 2 . . . . . . . . . . . . . . . . . . . . . 77
36 ZVT07 charging table - system 1 . . . . . . . . . . . . . . . . . . . . . 78
37 ZVT07 charging table - system 2 . . . . . . . . . . . . . . . . . . . . . 78
38 ZVT08 charging table - system 1 . . . . . . . . . . . . . . . . . . . . . 79
39 ZVT08 charging table - system 2 . . . . . . . . . . . . . . . . . . . . . 79
40 ZVT10 charging table - system 1 . . . . . . . . . . . . . . . . . . . . . 80
41 ZVT10 charging table - system 2 . . . . . . . . . . . . . . . . . . . . . 80
42 ZVT12 charging table - system 1 . . . . . . . . . . . . . . . . . . . . . 81
43 ZVT12 charging table - system 2 . . . . . . . . . . . . . . . . . . . . . 81
List of figures
18 Side panels for economizer hood tops . . . . . . . . . . . . . . . . . 21
19 Condensate drain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
20 Field wiring disconnect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
21 Typical control wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
22 Side entry gas piping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
23 Bottom entry gas piping . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
24 Simplified VFD wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
25 SE-ECO1001-0 economizer controller . . . . . . . . . . . . . . . . . 44
26 Belt adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
27 Altitude/temperature correction factors . . . . . . . . . . . . . . . . 49
28 Dry coil delta P . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
29 Cooling operation piping schematic - circuit no. 1 . . . . . . . . 63
30 Reheat operation piping schematic - circuit no. 1 . . . . . . . . 63
31 Typical flame . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
32 Typical two stage gas valve . . . . . . . . . . . . . . . . . . . . . . . . . 69
33 Unit control board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
5567613-TIM-B-1218
Advertisement
Table of Contents
Related Manuals for TempMaster ZV Series
Summary of Contents for TempMaster ZV Series
-
Page 1: Table Of Contents
R-410A ZV SERIES W/SMART EQUIPMENT™ 6.5 - 12.5 Ton 60 Hertz Table of contents General ..........2 Air balance. -
