Toshiba Satellite R20-ST2081 Series Specifications

Satellite R20-ST2081 Series Detailed Product Specification
Model Name Description
R20-ST2081 Genuine Windows® XP Tablet Edition 2005, Intel® Celeron® M 430 Processor, 512MB
DDR2, 40GB 5400rpm (S-ATA), CD-RW/DVD-ROM Drive, 14.1" WXGA+ Wide Viewing
Angle, Intel® Graphics Media Accelerator 950, 10/100Mbps LAN, Fingerprint Reader, 5-
in-1 Bridge Media Adapter, 1-year standard limited warranty.
Section 1.01 Operating System
• Genuine Windows® XP Tablet Edition 2005
• Windows Vista™ Capable
Section 1.02 Processor and Chipset
• Choice of Processor
o Intel® Celeron® M Processor 430
1.73GHz, 1MB L2, 533MHz FSB
o Intel® Core™ Solo Processor T1350
1.86GHz, 2MB L2, 533MHz FSB
o Intel® Core™ Duo Processor T2050
1.60GHz, 2MB L2, 533MHz FSB
o Intel® Core™ Duo Processor T2250
1.73GHz, 2MB L2, 533MHz FSB
o Intel® Core™ 2 Duo Processor T5200
1.60GHz, 2MB L2, 533MHz FSB with
64-bit
o Intel® Core™ 2 Duo Processor 5500
1.66GHz, 2MB L2, 667MHz FSB with
64-bit
o Intel® Core™ 2 Duo Processor T7200
2.00GHz, 4MB L2, 667MHz FSB with
64-bit
o Intel® Core™ 2 Duo Processor T7600
2.33GHz, 4MB L2, 667MHz FSB with
64-bit
• Chipset
o Mobile Intel® 945GM Express Chipset
Section 1.03 Memory
• Configured with 512MB PC4200 DDR2 SDRAM (1 memory slot
occupied, 1 available)
• 512MB (Min)/4096MB (Max), with 256MB, 512MB, 1024MB or
2048MB PC4200 or PC5300 DDR2 memory modules.
Section 1.04 Choice of Hard Disk Drive
• 40GB, 60GB, 80GB, 100GB, 120GB (5400RPM) or 100GB
(7200RPM) Serial-ATA (SATA) hard disk drive; 9.5mm height;
user removable
Section 1.05 Choice of Fixed Optical Disk Drive
• CD-RW/DVD-ROM
o Maximum speed and compatibility: CD-ROM (24x), CD-R
(24x), CD-RW (10x), DVD-ROM (8x)
• DVD SuperMulti (+/-R double layer) drive supporting 11 formats
o Maximum speed and compatibility: CD-ROM (24x), CD-R
(24x), CD-RW (10x), DVD-ROM (8x), DVD-R (Single
Layer, (8x)), DVD-R (Double Layer, (2x)), DVD-RW (4x),
DVD+R (Single Layer, (8x)), DVD+R (Double Layer,
(2.4x)), DVD+RW (4x), DVD-RAM (3x)
Section 1.06 Display
• 14.1" diagonal widescreen TFT active-matrix High Brightness LCD
display at 1440x900 native resolution (WXGA+) with Wide
Viewing Angle
2
3
4
CPU_64
CPU_64
CPU_64
CPU_64
5
6
8
© Copyright 2005 – 2006 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Satellite R20-ST2081 BTO Rev. 1.03 2006-12-03 SK T20060428 CB1.00
1
Section 1.07 Graphics
• Intel® Graphics Media Accelerator 950 with 8MB-128MB
dynamically allocated shared graphics memory
Section 1.08 Sound
• Built-in stereo speakers
• Sound Volume Control Dial
• Built-in microphone
Section 1.09 Input Devices
• Keyboard
• TouchPad™ pointing device
• TouchPad™ Enable/Disable
• Control Buttons:
Section 1.10 Communications
• Toshiba V.92 software modem
• Intel® PRO/100 VE Network Connection - 10/100 Base-TX Ethernet
• Choice of Optional Integrated Wireless-LAN
• Optional Bluetooth® version 2.0 plus Enhanced Data Rate (EDR)
with Toshiba Bluetooth driver software
Section 1.11 Expandability
• 2 main memory slots. Both slots may be occupied.
• One PCMCIA – Type II/Type I Card Slot
• 5-in-1 Bridge Media Adapter
7
Section 1.12 Ports
• Video
• Audio
• Data
Part Number
PSR20U-0TE00T
9
o 84 key US keyboard
o Hot Key Functions (Fn)
o Windows Key Function
o Application Key Function
o Internet button to launch default browser
o CD/DVD control buttons (Skip to Previous/Next Track,
Play, Stop)
10
o Intel® PRO/Wireless Network Connection 3945ABG
(802.11a/b/g)
o Atheros® 802.11a/b/g wireless-LAN
o Secure Digital, Memory Stick™, Memory Stick PRO™,
Multi Media Card, xD Picture Card [shared slots]
o Secure Digital slot supports SDIO
o RGB (monitor) output port
o S-Video output port
o Microphone input port
o Headphone output port
o i.LINK™ IEEE-1394
o USB v2.0 – 4 ports
o RJ-45 LAN port
o RJ-11 modem port
o 140-pin docking connector
UPC
032017720800
11
:
Page 1 of 5
