Summary of Contents for Pelgrim PKS14088

  • Page 1 PKS14088 PKS14102 PKS14122 PKD13102 PKS14140 PKS24088 PKS24102 PKS24122 PKD23102 PKS24140 Instructions for use Built-in refrigerator...
  • Page 2 Please visit our website where you can enter your appliance model number, indicated on the rating plate or the warranty sheet, to find detailed description of your appliance, tips on use, troubleshooting, service information, instructions for use etc. www.pelgrim.nl Important safety warning General warnings and tips Protecting the environment...
  • Page 3: Table Of Contents

    CONTENTS INTRODUCTION 4 IMPORTANT NOTES AND PRECAUTIONS 4 BEFORE USING THE APPLIANCE FOR THE FIRST TIME 5 IMPORTANT SAFETY INSTRUCTIONS 7 IMPORTANT INFORMATION ON THE USE OF APPLIANCE 8 ENVIRONMENT PROTECTION 9 ADVICE FOR SAVING POWER WITH REFRIGERATION APPLIANCES APPLIANCE 10 INSTALLATION AND CONNECTION DESCRIPTION 12 APPLIANCE DESCRIPTION...
  • Page 4: Important Notes And Precautions

    IMPORTANT NOTES AND PRECAUTIONS BEFORE USING THE APPLIANCE FOR THE FIRST TIME Before connecting the appliance to the power mains, please read carefully the instructions for use which describe the appliance and its correct and safe use. The instructions apply to several appliance types/models; thus, settings or equipment may be described herein which is not available in your appliance.
  • Page 5: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS The appliance must be connected to the power mains and grounded in compliance with the effective standards and regulations. Before cleaning the appliance, unplug it from the power mains (unplug the power cord from the wall outlet). If the power cord is damaged, it must be replaced by a service technician or other adequately trained person.
  • Page 6 Danger of frostbite Never put frozen food in your mouth and avoid touching frozen food as this may cause frostnip or frostbite. Safety of children and vulnerable persons This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or metal capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe...
  • Page 7: Important Information On The Use Of Appliance

    IMPORTANT INFORMATION ON THE USE OF APPLIANCE WARNING! Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. The appliance may not be used outdoors and it may not be exposed to rain. Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance.
  • Page 8: Environment Protection

    ENVIRONMENT PROTECTION Packaging is made of environmentally friendly materials that can be recycled, disposed of, or destroyed without any hazard to the environment. Removing an obsolete appliance To protect the environment, take the obsolete appliance to an authorized home appliance collection centre. Before doing so, do the following: •...
  • Page 9: Appliances

    ADVICE FOR SAVING ENERGY WITH REFRIGERATION APPLIANCES • Install the appliance as specified in the instruction manual. • Do not open the door more often than necessary. • Occasionally make sure air circulation underneath the appliance is unobstructed. • Condenser unit on the rear wall should be kept clean (see chapter Cleaning the appliance).
  • Page 10: Installation And Connection

    INSTALLATION AND CONNECTION SELECTING THE ROOM • Install the appliance in a dry and well ventilated room. The appliance will operate correctly if the environment temperature is in the interval specifi ed in the table. The appliance class is indicated on the rating plate / label with the basic information on the appliance.
  • Page 11 CONNECTING THE APPLIANCE • Connect the appliance to the power mains using the power cord. The wall outlet should be fi tted with a ground contact (safety socket). Nominal voltage and frequency are indicated on the rating plate/label with basic information on the appliance.
  • Page 12: Appliance Description

    APPLIANCE DESCRIPTION Appliance interior equipment may change according to the appliance model. 1 Control unit 2 LED lighting 3 Glass shelves 4 Fruit and vegetable drawer with humidity control 5 Door balconies 6 Bottle balcony...
  • Page 13 1 Control unit 2 LED lighting 3 Glass shelves 4 Fruit and vegetable drawer with humidity control 5 Fruit and vegetable drawer 6 Door balconies 7 Bottle balcony...
  • Page 14: Operating The Appliance

    OPERATING THE APPLIANCE A Temperature setting and on/off knob Use the dial to switch the appliance on or off , set the temperature, and control the ECO function. B Lighting on/off key Lighting will switch on automatically when you open the refrigerator compartment door, and it will switch off when you close it.
  • Page 15 ADJUSTING THE TEMPERATURE IN THE APPLIANCE • After the appliance is switched on, it may take several hours for the set temperature to be reached. Do not place any food into the refrigerator before the temperature drops to the selected setting. •...
  • Page 16: Appliance Interior Equipment

    APPLIANCE INTERIOR EQUIPMENT SHELF • Empty shelves can be distributed in the refrigerator interior without having to remove the shelf from the refrigerator. To move the shelf to a diff erent height, lift it at the front, hold it at the back, pull forward a little and move it higher or lower.
  • Page 17 FRUIT AND VEGETABLE DRAWER WITH HUMIDITY CONTROL • The drawer at the bottom of the refrigerator is intended for storing fruit and vegetables. It provides humidity and prevents the food from drying out. The drawer has integrated humidity regulator which allows setting the humidity level.
  • Page 18 INTERIOR SIDE OF THE REFRIGERATOR DOOR The balconies mounted on the interior side of the refrigerator door are intended for storing cheese, butter, eggs, yoghurt and other smaller packages, tubes, cans, etc. There is a bottle balcony at the lower end of the door. ADJUSTABLE DOOR BALCONIES The height of the balconies is adjustable.
  • Page 19: Recommended Distribution Of Food In The Appliance

    RECOMMENDED DISTRIBUTION OF FOOD IN THE APPLIANCE Sections in the refrigerator compartment: - Upper part: canned food, bread, wine, pastry, etc. - Middle part: dairy products, ready-made meals, desserts, soft drinks, beer, cooked food, etc. - Lower part: meat, meat produce, delicatessen; - Fruit and vegetable drawer: fresh fruit, vegetables, salads, root vegetables, potatoes, onions, garlic, turnips, etc.
  • Page 20: Storing Food In The Refrigerator

    STORING FOOD IN THE REFRIGERATOR IMPORTANT WARNINGS REGARDING FOOD STORAGE Correct use of the appliance, appropriate packaging, maintaining the right temperature, and observing the food hygiene standards have a decisive impact on the quality of food storage. Observe the expiry dates for the food, indicated on the packaging.
  • Page 21: Defrosting The Appliance

    DEFROSTING THE APPLIANCE AUTOMATIC REFRIGERATOR DEFROSTING This refrigerator does not need defrosting because the ice on the back interior wall is thawed automatically. Any accumulated ice will melt when the compressor unit is inactive. Drops will flow through an opening in the refrigerator rear wall into a tray fitted above the compressor, from where they will evaporate.
  • Page 22: Cleaning The Appliance

    CLEANING THE APPLIANCE Before cleaning, unplug the appliance from the power mains – switch off the appliance (see chapter Operating the Appliance) and unplug the power cord from the wall outlet. • Use a soft cloth to clean all surfaces. Cleaners that contain abrasive substances, acids, or solvents are not suitable for cleaning as they may damage the surface.
  • Page 23: Troubleshooting

    TROUBLESHOOTING Problem: Cause or remedy Appliance is connected • Make sure there is voltage in the power outlet and to the power mains but that the appliance is switched on. it does not work. Cooling system • Too high environment temperature. operates continuously •...
  • Page 24 Problem: Cause or remedy Door is difficult to open: • If you are trying to open the freezer door after just having closed it, this could be difficult to do. As you open the door, some cool air escapes from the appliance and it is replaced by warm air from the environment.
  • Page 25: Information About Appliance Noise

    INFORMATION ABOUT APPLIANCE NOISE Cooling in refrigerators is made possible by a cooling system that also includes a compressor (and a fan with some appliances), which generates some noise. The level of noise depends on installation, proper use, and age of the appliance. •...
  • Page 28 COOLER BI540-F2 ESS PEL en (03-19)
