Toshiba Satellite M65-S9092 Specifications

Satellite M65-S9092 Series Detailed Product Specification
Model Name Description
M65-S9092 Microsoft® Windows® XP Media Center Edition 2005, Intel® Pentium® M Processor
760, 1024MB DDR2, 100GB (5400 RPM) PATA, 8x DVD SuperMulti (+/-R Double
Layer), 17" Widescreen TruBrite™ WXGA,TV-Out, Intel® Graphics Media Accelerator
900, ATI MOBILITY™ RADEON® X600 SE, Intel® PRO/Wireless 2200BG, CD control
buttons, Smart Indigo, 5-in-1 Bridge Media Adapter, ExpressCard™, harmon/kardon®,
1-year Limited Warranty
2
Operating System
• Microsoft® Windows® XP Media Center Edition 2005
• TOSHIBA Express Media Player
o Quick access for CD and DVD watching
3
Processor and Chipset
Intel® Centrino™ Mobile Technology featuring:
• Intel Pentium® M Processor 760
o 2.0GHz, 2MB L2, 533MHz FSB
• Mobile Intel 915PM Express Chipset
• Intel PRO/Wireless 2200BG (802.11b/g)
4
Memory
• Configured with 1024MB DDR2 SDRAM (both memory slots may
be occupied)
• 1024MB (Min)/2048MB (Max), 2 memory slots using 512MB or
1024MB PC4200 DDR2 533MHz SDRAM 1.8V SODIMM
memory modules, dual-channel support requires two memory
modules of same capacity and clockspeed
5
Hard Disk Drive
• 100GB (5400 RPM); Enhanced IDE (ATA-6) hard disk drive; 9.5mm
height; user removable
Fixed Bay Optical Disk Drive
• DVD SuperMulti (+/-R double layer) drive supporting 11 formats
maximum speed and compatibility:
CD-ROM(24x:read), CD-R(24x:write), CD-
o
RW(4x:write), DVD-ROM(8x:read), DVD-R(8x:write),
DVD-RW(2x:write), DVD+R(4x:write), DVD+R[Double
Layer](8x:read/write), DVD+RW(2.4x:write), DVD-
RAM(4x:write)
6
Display
• 17.0" diagonal widescreen TruBrite™ TFT active-matrix LCD
display at 1440x900 native resolution (WXGA)
7
Graphics
• ATI MOBILITY™ RADEON® X600 SE with128MB DDR discrete
graphics memory
Sound
• Realtek ALC250 16-bit stereo software sound
o Supports 3D Sound, Direct 3D Sound, DirectSound,
Direct Music, MIDI (playback)
• Sound Volume Control Dial
• Built-in harman/kardon® stereo speakers
• SRS Labs audio enhancements
o SRS TruSurround XT® virtual surround sound
o SRS WOW™ stereo enhancement
8
© Copyright 2005 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Satellite M65-S9092 BTS Rev. 1.03 2005-09-22 DSM T20050726 CB1.10
1
Part Number
PSM60U-0CF02M
Input Devices
• Keyboard
o 82 key US keyboard with 10-key
o Hot Key Functions (Fn)
o Windows Key Function
o Application Key Function
• TouchPad™ pointing device
• TouchPad™ Enable/Disable (FN+F9 or by help of software)
• Control Buttons:
o Internet button to launch default browser
o Express Media Player CD/DVD launch button
o CD/DVD control buttons (Skip to Previous/Next Track,
Play, Stop)
Communications
• Integrated V.92 software modem
• 10/100 Base-TX Ethernet
• Integrated Intel Pro/Wireless Network Connection 2200BG
10
(802.11b/g):
Expandability
• 2 main memory slots. Both slots may be occupied.
• 1 PC Card slot support 1 Type II, PCMCIA R2.01, PC Card16,
CardBus
• ExpressCard slot supporting ExpressCard/34 and ExpressCard/54
• 5-in-1 Bridge Media Adapter (Secure Digital, Memory Stick™,
Memory Stick PRO™, Multi Media Card, xD Picture Card [shared
slots])
Ports
• RGB (monitor) port
• TV-out (S-Video)
• i.LINK(tm) IEEE-1394
• 3 Universal Serial Bus (USB) ports (v2.0)
• External Microphone jack
• Headphone jack
• RJ-45 LAN port
• RJ-11 modem port
Physical Description
• Dimensions (WxDxH Front/H Rear): 15.5'' (394.0mm) x 11.0''
(280.3mm) x 1.2'' (29.8mm)[F]/1.5'' (37.0mm)[R] without feet
• Weight: From 7.3 lbs to 7.8 lbs (3.32 to 3.55 kg) depending upon
11
configuration
• Indicators: DC-In, Power/Sleep, Hard Drive, CD-DVD ROM Access,
Caps Lock, Numeric Lock, Scroll Lock, Battery Charging Status,
Wireless, Multiple Digital Media Card Slot
• Chassis Description
o Case material: Polycarbonate ABS
o LCD Cover Color: Smart Indigo
• Physical Security
o Slot for cable lock;
o Items protected by a screw: Memory, Hard Disk Drive,
Built in Modem/LAN
UPC
032017415218
9
