TOSHIBA
1
Satellite M65 Series
Model Name
Description
M65-S9062
Microsoft® Windows® XP Professional, Intel® Pentium® M Processor 740, 512MB, 60GB
(5400 RPM), 8x DVD SuperMulti (Double Layer), 17" WXGA,TV-Out, Intel® GMA 900,
802.11b/g, CD play/Instant play button, Bridge Media Adapter, ExpressCard™, 1-year Limited
Warranty
System Characteristics
3
Operating System
•
Microsoft® Windows® XP Professional
•
Toshiba® Express Media Player for quick access to CD, DVD
Intel® Centrino™ Mobile Technology featuring:
4
Processor
:
•
Intel Pentium® M Processor 740 [1.73GHz, 2MB L2, 533MHz
FSB]
Chipset
•
Mobile Intel 915GM Express Chipset
Integrated Wi-Fi™ compliant wireless LAN
•
Intel® PRO/Wireless 2200BG (802.11b/g),
5
Memory
•
Configured with 512MB DDR2 SDRAM (both memory slots may
be occupied)
•
512MB(min)/2048MB (max), 2 memory slots using 512MB, or
1024MB PC4200 DDR2 533MHz SDRAM, dual-channel support
requires two memory modules
Mass Storage
6
Hard Drive
•
60GB (5400 RPM) Enhanced IDE (ATA-6) hard disk drive;
9.5mm height; user removable
Optical Disk Drive
•
Fixed Bay 8x DVD SuperMulti Double Layer Drive
Maximum Speed:
CD-ROM(24x:read), CD-R(24x:write), CD-RW(10x:write),
o
DVD-ROM(8x:read), DVD-R(8x:write), DVD-RW(4x:write),
DVD+R(8x:write), DVD+R [Double Layer]
(2.4x:write),DVD+RW(4x:write), DVD-RAM(3x:write)
7
Display
•
17" diagonal widescreen TruBrite™ TFT active-matrix LCD
display at 1440x900 native resolution (WXGA)
•
Maximum Brightness 200 Cd/m
•
Brightness Control
8
Graphics
•
Intel Graphics Media Accelerator 900; up to 128MB of graphics
memory is taken from the main memory via UMA (Unified
Memory Architecture)
Sound
•
Realtek ALC250 Software Sound
•
16-bit stereo
•
Built-in harman/kardon® stereo speakers
•
3D Sound Support, Direct 3D Sound; DirectSound, Direct Music,
MIDI (playback) Support
•
Sound Volume Control Dial
•
SRS® TruSurround XT® and SRS® WOW™ Audio
9
Enhancements
Input Devices
•
Keyboard with 10-Key Pad
103 key US keyboard, 2.5mm key stroke, 5.7mm keyboard
o
height, 19.05mm key pitch
Hot Key Functions (FN); please see electronic User's Guide
o
for more information
Windows Key Function
o
Application Key Function
o
•
Pointing Device:
TouchPad™
o
TouchPad™ Enable/Disable (FN+F9 or by help of software)
o
•
Others:
CD Buttons (Skip to Previous Track, Play, Stop, Skip to Next
o
Track)
Internet Browser Launch Function
o
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
2
2
© Copyright 2005 Toshiba America Information Systems Inc. All Rights reserved.
Satellite M65-S9062 BTS Rev. 1.00 2005-05-23 CBB T20050418 CB1.0
Express Media Player Launch Button
o
Expandability
•
2 main memory slots. Both slots may be occupied.
•
1 PC Card slot supports 1 Type II PC Card, PCMCIA R2.01, PC
Card16, CardBus
•
ExpressCard™
•
Bridge Media Adapter (Secure Digital®, Memory Stick™,
Memory Stick PRO™, Multi Media Card, xD Picture Card
[shared slots])
Communications
•
Integrated V.92 modem
•
Intel® PRO/100 VE Network Connection - 10/100 Base-TX
Ethernet
•
Integrated Intel® Pro/Wireless Network Connection 2200BG
11
(802.11b/g)
Ports
•
RGB (monitor) port
•
TV-out (S-Video)
•
(TM)
i.LINK
IEEE-1394
•
3 Universal Serial Bus (USB) ports (v2.0)
•
External Microphone jack
•
Headphone jack
•
RJ-45 LAN port
•
RJ-11 modem port
Physical Description
•
Dimensions (WxDxH Front/H Rear): 15.5'' (394.0mm) x 11.0''
(280.3mm) x 1.2'' (29.8mm)[F]/1.5'' (37.0mm)[R] without feet
•
12
Weight
: From 7.3 lbs to 7.8 lbs (3.32 to 3.55 kg) depending
upon configuration
•
Indicators: DC-In, Power/Sleep, Hard Drive, CD-DVD ROM
Access, Caps Lock, Numeric Lock, Scroll Lock, Battery
Charging Status, Wireless, Multiple Digital Media Card Slot
Power Supply
•
75W (19V 3.95A) Auto sensing external AC Adapter, 100-240V /
50-60Hz frequency (Universal) input.
•
Weight: starting at 0.77 lbs (350g)
•
Dimensions (WxDxH): 5.0'' (128mm) x 2.0'' (51mm) x 1.2''
(30.0mm)
13
Battery
•
8-cell (4300mAh) rechargeable, removable Lithium Ion (Li-Ion)
battery pack
•
Weight: starting at 0.95 lbs. (430g)
•
Dimensions (WxDxH): 5.4'' (136.1mm) x 3.6'' (92.6mm) x 0.76''
(19.4mm)
•
Battery Life: Up to 4:45 (hours:minutes) (8-cell battery)
•
Recharge Time
Main Battery Off/On – up to 4 hrs/up to 12.0 hrs
o
Security
•
Physical Security
Slot for cable lock
o
Items protected by a screw: Memory, Hard Disk Drive, Built
o
in Modem/LAN
Items protected by a sliding latch: Battery
o
•
Software Security
Passwords: User Power-on password, Supervisor Password,
o
Setup Password
•
Hotkey locks: Screen Blank (by Hotkey), Screen Saver (by
software)
BIOS
•
ACPI v1.0b, PNP v1.0a, VESA v2.0, DPMS, DDC, SM BIOS
v2.34, PCI BIOS v2.2 support
Part Number
UPC Code
PSM60U-02101U
032017367821
10
14
Page 1 of 4
