Toshiba Satellite M30X-S171ST Specifications

TOSHIBA
Satellite M30X series
Model Name Description
M30X-S171ST Intel® Celeron® M Processor 350, 15" XGA, 256MB, 40GB (4200 RPM), DVD/CD-RW,
802.11bg, TV-out, CD Keys, IEEE 1394, Microsoft® Windows® XP Home (SP2), 1-year
Limited Warranty
System Characteristics
Operating System
•
Microsoft® Windows® XP Home (SP2)
2
Processor and Chipset
•
Intel Celeron® M Processor 350 [1.3GHz, 1MB L2 cache,
400MHz FSB]
•
Intel 855GME Chipset
3
Memory
•
Configured with 256MB
•
256MB (Min)/2048MB (Max), 2 available memory slots for
256MB, 512MB, or 1024MB PC2700 DDR333 SDRAM 2.5V
SODIMM memory modules. Both slots may be occupied.
Mass Storage
4
Hard Drive
•
40GB (4200 RPM). Enhanced IDE (ATA-6) hard disk drive;
9.5mm height; user removable
Optical Disk Drive
•
Fixed Bay CD-RW/DVD drive:
Maximum Speed:
CD-ROM (24x:read), CD-R (24x:write), CD-RW (4x:write),
DVD-ROM (8x:read)
Compatibility:
CD-ROM (read), CD-R (read/write), CD-RW (read/re-
write), DVD-ROM (read), DVD-R (read), DVD-R/RW/RAM
(read only)
5
Display
•
15" diagonal TFT active-matrix LCD display at 1024x768 native
resolution
•
Maximum Brightness 150 Cd/m
•
Brightness Control
6
Graphics
•
Intel Extreme Graphics 16MB-64MB (DVMA) shared video
memory
Input Devices
•
Keyboard
85 key US keyboard, 2.7mm key stroke, 6mm keyboard
o
height, 19.05mm key pitch
Hot Key Functions (FN); please see electronic User's Guide
o
for more information
Windows Key Function
o
Application Key Function
o
•
Pointing Device:
Touch Pad
o
•
CD Keys
Expandability
•
2 main memory slots. Both slots may be occupied.
•
1 PC Card slot support 1 Type II, PCMCIA R2.01, PC Card16,
CardBus
7
Communications
•
Integrated V.92 modem
•
Atheros® 802.11b/g wireless-LAN supporting Atheros SuperG™
8
technology
•
Realtek -10/100Base-TX Ethernet
Ports
•
RGB (monitor) port
•
TV-out (S-Video)
•
i.LINK(TM) IEEE-1394
•
3 Universal Serial Bus (USB) ports (v2.0)
•
External Microphone jack
•
Headphone jack
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
1
2
© Copyright 2005 Toshiba America Information Systems Inc. All Rights reserved.
Satellite M35X Series Rev. 1.20 30-03-2005 CBB Source: CB V.1.1
•
RJ-45 LAN port
•
RJ-11 modem port
Physical Description
•
Dimensions (WxDxH Front/H Rear): 14.4'' (365mm) x 10.83''
(275mm) x 1.16'' (29.5mm)[F]/1.48'' (37.5mm)[R] without feet
• 9
Weight : Starting at 6.8 lbs depending upon configuration
•
Indicators: Power, Hard Drive, CD/DVD-ROM, Wireless
indicator, Caps Lock, Arrow Lock, Numeric Lock, Main Battery
Charging Status, Sleep Suspend Mode.
Sound
•
Software Sound
•
16-bit stereo; Built-in stereo speakers
•
3D Sound Support, Direct 3D Sound; DirectSound, Direct Music,
MIDI (playback) Support
•
Sound Volume Control Dial
Power Supply
•
65W (19V 3.42A) Auto sensing external AC Adapter, 100-240V /
50-60Hz frequency (Universal) input.
•
Dimensions (WxDxH): 4.25'' (108mm) x 1.85'' (47mm) x 1.10'
(28mm)
•
Weight: starting at 0.67 lbs (305g)
10
Battery
•
4-cell (2150mAh) rechargeable, removable Lithium Ion (Li-Ion)
battery pack
•
Weight: starting at 0.58 lbs (265g)
•
Dimensions (WxDxH): 5.56'' (141.2mm) x 3.64'' (92.4mm) x
0.76'' (19.4mm)
•
Battery Life: Up to 1:30 hours:minutes (measured by
MobileMark™) (4-cell battery)
•
Recharge Time
Main Battery Off/On – approximately 4.0 hrs/approximately
o
12.0 hrs
Security
•
Slot for cable lock;
•
Items protected by a screw: HDD, memory
•
Passwords: User Power-on password, Supervisor Password
•
Hotkey locks: Screen Blank
•
Software: Screen Saver
BIOS
•
ACPI v1.0b, PNP v1.0a, VESA v3.0, DPMS, DDC, SM BIOS
v2.34, PC BIOS v2.2 support
11
Software
Toshiba Software and Utilities
•
Toshiba Notebook Maximizer
•
Toshiba Speech System
•
Toshiba ConfigFree™
•
Toshiba Custom Utilities
•
Toshiba Touch and Launch
•
TOSHIBA MyConnect™ - 45 day free trial offer
MYCONNECT OFFER DETAILS: 1 Valid in the US only! You must cancel your Access
Plan before the end of the trial period to avoid being charged the $39.95 monthly
Access Service fee for the six month plan commitment period. Monthly automatic
renewal feature after end of commitment period. Available to new members in the U.S.,
age 18 or older, and a major credit card for billing is required. Offer is for unlimited dial-
up, wired broadband, or Wi-Fi remote access connection time in the 50 United States
and the District of Columbia within the MyConnect service area for 30 day continuous
service periods. Use of optional 800 telephone number dial-up usage will incur
additional fees even during the trial period. Other terms and conditions apply. Offer
expires June 30, 2005. Information, prices, and availability subject to change without
notice.
Third-party Software
•
Microsoft® Works
•
Microsoft® Office Trial Version Student/Teacher
Part Number UPC Code
PSA72U-3HC01Q 032017350359
Page 1 of 7
