Toshiba Satellite M100-ST5111 Specifications

Satellite M100 Series Detailed Product Specification
Model Name Description
M100-ST5111 Microsoft® Windows® XP Home Edition, Intel® Core™ Solo Processor T1300, 256MB
DDR2, 40GB 5400rpm (S-ATA), CD-RW/DVD-ROM, 14.1" wide-screen WXGA, Intel®
Graphics Media Accelerator 950, CD control buttons, 5-in-1 Bridge Media Adapter,
Gigabit LAN, 1-year standard limited warranty.
2
Operating System
• Microsoft® Windows® XP Home Edition
• Microsoft® Windows® XP Professional
• TOSHIBA Express Media Player
o Quick access for CD and DVD watching
Choice of Processor and Chipset
Intel® Core™ Solo or Intel® Core™ Duo Processor:
• Intel® Core™ Solo Processor T1300
o 1.66GHz, 2MB L2, 667MHz FSB
• Intel® Core™ Duo Processor T2300
o 1.66GHz, 2MB L2, 667MHz FSB
• Intel® Core™ Duo Processor T2400
o 1.83GHz, 2MB L2, 667MHz FSB
• Intel® Core™ Duo Processor T2500
o 2.00GHz, 2MB L2, 667MHz FSB
• Intel® Core™ Duo Processor T2600
o 2.16GHz, 2MB L2, 667MHz FSB
Chipset
o Mobile Intel® 945GM / PM Express Chipset
4
Memory Options
• Configured with 256MB DDR2 533MHz SDRAM (using service
accessible memory slot)
• 256MB(min)/4096MB (max), 256MB in service-accessible memory
slot plus one available user-accessible memory slot for 256MB,
512MB, 1024MB, or 2048MB PC4200 DDR2 533MHz SDRAM or
PC5300 DDR2 667MHz SDRAM, dual-channel support requires
two memory modules of same capacity and clockspeed
Choice of Hard Disk Drive
• 40GB, 60GB, 80GB, 100GB,120GB (5400 RPM) or 100GB
(7200RPM) Serial-ATA (S-ATA) hard disk drive; 9.5mm height
Choice of Fixed Bay Optical Disk Drive
• CD-RW/DVD-ROM
o Maximum speed and compatibility: CD-ROM (24x:read),
CD-R (24x:write), CD-RW (10x:write), DVD-ROM
(8x:read)
• DVD SuperMulti (+/-R double layer) drive supporting 11 formats
o Maximum speed and compatibility: CD-ROM (24x:read),
CD-R (24x:write), CD-RW (10x:write), DVD-ROM
(8x:read), DVD-R (Single Layer, 8x:write), DVD-R
(Double Layer, 2x: write), DVD-RW (4x:write), DVD+R
(Single Layer, 2x:write), DVD+R (Double Layer,
2.4x:write), DVD+RW (4x:write), DVD-RAM (5x:write)
7
Choice of Display
• 14.1" diagonal widescreen high-brightness TFT active-matrix LCD
display at 1280x768 native resolution (WXGA)
• 14.1" diagonal widescreen TruBrite™ TFT active-matrix LCD
display at 1280x768 native resolution (WXGA)
8
Graphics
• PCI-Express™ x16 graphics subsystem, featuring:
3
5
6
© Copyright 2006 Toshiba America Information Systems Inc. Al
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Satellite M100-ST5111 BTO Rev. 1.03 2006-02-09 SK T20060113 CB1.20
1
o Intel® Graphics Media Accelerator 950 with 8MB-128MB
dynamically allocated shared graphics memory
o ATI MOBILITY™ RADEON® X1300 with 64MB DDR
discrete graphics memory
o ATI MOBILITY™ RADEON® X1400 with 128MB DDR
discrete graphics memory
Sound
• Built-in stereo speakers
• Optional harman/kardon speakers
• Realtek ALC861 stereo software sound
o Supports Direct 3D Sound, DirectSound, Direct Music,
MIDI (playback)
o Connected BUS: Intel High Definition Audio
• Sound Volume Control Dial
• Built-in microphone
Input Devices
• Keyboard
o 85 key US keyboard
o Hot Key Functions (Fn)
o Windows Key Function
o Application Key Function
• TouchPad™ pointing device
• TouchPad™ Enable/Disable (FN+F9 or by help of software)
• Control Buttons:
o Internet button to launch default browser
o Express Media Player CD/DVD launch button
o CD/DVD control buttons (Skip to Previous/Next Track,
Play, Stop)
Communications
• Toshiba V.92 software modem
• Optional Bluetooth® version 2.0 plus Enhanced Data Rate (EDR)
with Toshiba Bluetooth® driver software
• Intel® 10 /100 /1000Base-T Ethernet
• Choice of Wireless-LAN
o Intel® PRO/Wireless Network Connection 3945ABG
(802.11a/b/g)
o Atheros® 802.11a/b/g Wireless-LAN
Expandability
• 2 main memory slots.
• 1 PC Card slot support 1 Type II, PCMCIA R2.01, PC Card16,
CardBus
• 5-in-1 Bridge Media Adapter
o Secure Digital, miniSD™ (with adapter), Memory Stick™,
Memory Stick PRO™, xD Picture Card [shared slots]
o Secure Digital slot supports SDIO
Ports
• Video
o RGB (monitor) output port
o S-Video output port
• Audio
o Microphone input port
o Headphone output port
• Data
o i.LINK™ IEEE-1394
o Universal Serial Bus (USB v2.0) – 4 ports
l Ri ghts reserved.
Part Number UPC
PSMA0U-03300C 032017535268
9
10
