Setting up the Case Sealer

Adjusting the Deck Height

Wheel Brake
1. Begin by lifting the case sealer to the desired height with a pallet fork, dolly, or jack and
secure it safely in place.
2. Loosen the "adjustment bolts" on each leg and allow the "Height adjustment Insert" to drop
the floor.
3. Tighten the adjustment bolts and repeat these steps for each leg.
4. Once you have tightened all of the legs remove the lifting device holding the case sealer
in place.
Always consider safety and never lay down underneath the case sealer while
adjusting the legs.
www.sneedcoding.com
Lock Nut
Castor
Figure 1
| (833)926-3464
Leg
Height Adjustment inserts
Adjustment bolts
