Summary of Contents for kincrome KP1460
- Page 1 BATTERY LOAD TESTER TEST TEST ANALYZE 6/12V VEHICLES STARTER BATTERY CHARGING MOTOR CONDITION SYSTEMS UP TO 100AMPS KP1460 (SEPT 15)
-
Page 2: Know Your Product
5. Battery Load Switch 6. Battery Analysis Label (On Rear of Product), (Refer to Page 7 of This Manual) Specifications Model: ..................KP1460 Battery Test Capability: ............6VDC or 12VDC Lead Acid Batteries Load Test Capacity: ...............100Amps @ 12VDC or 50Amps @ 6VDC Amps Capacity: ..............200 to 1000CCA... -
Page 3: General Safety Warnings
This product is not a toy. Keep it out of reach of children. h) Maintain labels and nameplates on the unit. These carry important safety information. If unreadable or missing, contact Kincrome Tools for a replacement. People with pacemakers should consult their physician(s) before use. Electromagnetic fields in close proximity to heart pacemaker could cause pacemaker interference or pacemaker failure. - Page 4 7) Unpacking Unpack all the components from the box. When unpacking the KP1460 100A Battery Load Tester, carefully inspect for any damage that may have occurred during transit. Check for loose parts, missing parts or damaged parts. 1. Ensure all packaging materials are disposed of as per your local council guide lines.
-
Page 5: Operation
Doing so can cause damage to the battery tester or vehicles components and this is not covered under warranty by Kincrome. 4. Be sure the battery load tester is OFF prior to use. Ensure the battery load tester switch (5) is in the OFF (O) position before attaching or removing the RED (+ positive) battery clamp (3) or BLACK (- negative) battery clamp (1) to prevent arcing or potential explosion from battery gasses. - Page 6 BATTERY LOAD TESTER <100A 11) Testing a Vehicles Charging System Note: The engine should be at normal operating temperature during this test. WARNING: Be sure load is OFF before attaching or removing + or - battery clamps (1 & 3) to prevent arcing and potential explosion from battery gases.
-
Page 7: Charging System
BATTERY LOAD TESTER <100A 12) Battery Condition Analysis Table Load Test / 15 Seconds DC Volts Display Meter Details (Display Reading) OK (GREEN Area) Battery capacity is good. May or may not be fully charged. Check the charge state by testing the Specific Gravity (SG) with a Hydrometer. - Page 8 BATTERY LOAD TESTER <100A 13) Testing the Vehicles Starter Motor NOTE: The vehicles engine should be off, at normal operating temperature and the vehicles battery should be fully charged before doing this test. CAUTION: Do not press the battery load switch (5) during this test! 1.
-
Page 9: Warranty
(12 months) commences on the date that the product is purchased. If this product has materials or workmanship defects (other than defects caused by abnormal or non warranted use) you can, at your cost, send the product to place of purchase, an authorised Kincrome service agent or one of Kincromes addresses for repair or replacement. - Page 10 BATTERY LOAD TESTER <100A Notes:...
- Page 11 BATTERY LOAD TESTER <100A...
- Page 12 www.kincrome.com.au...
