CARBON PILE
BATTERY LOAD
TESTER
12V
UP TO
500
AMPS
KP1461
ED1
(SEPT 15)
TEST
ANALYZE
VEHICLES
BATTERY
CHARGING
CONDITION
SYSTEMS
TEST
STARTER
MOTOR

Advertisement

loading
Need help?

Need help?

Do you have a question about the KP1461 and is the answer not in the manual?

Questions and answers

Summary of Contents for kincrome KP1461

  • Page 1 CARBON PILE BATTERY LOAD TESTER TEST TEST ANALYZE VEHICLES STARTER BATTERY CHARGING MOTOR CONDITION SYSTEMS UP TO AMPS KP1461 (SEPT 15)
  • Page 2 6. (-) Negative Battery Clamp 7. Battery Analysis Label (On R/H Side) 8. Product Safety Label (On L/H Side) Specifications Model: ..................KP1461 Battery Test Capability: ............12VDC Lead Acid Batteries Load Test Capacity: ...............Adjustable Carbon Pile 0-500Amps @ 12VDC Amps Meter: .................0 -160Ah (Amp Hour)
  • Page 3 This product is not a toy. Keep it out of reach of children. h) Maintain labels and nameplates on the unit. These carry important safety information. If unreadable or missing, contact Kincrome Tools for a replacement. People with pacemakers should consult their physician(s) before use. Electromagnetic fields in close proximity to heart pacemaker could cause pacemaker interference or pacemaker failure.
  • Page 4 Read the instruction manual before use. 7) Unpacking Unpack all the components from the box. When unpacking the KP1461 500A Carbon Pile Battery Load Tester, carefully inspect for any damage that may have occurred during transit. Check for loose parts, missing parts or damaged parts.
  • Page 5 Doing so can cause damage to the battery tester or vehicles components and this is not covered under warranty by Kincrome. 4. Be sure the carbon pile battery load tester is OFF prior to use. Ensure the battery load tester dial (4) is in the OFF position (rotated anti clockwise as far as possible) before attaching or removing the RED (+ positive) battery clamp (5) or BLACK (- negative) battery clamp (6) to prevent arcing or potential explosion from battery gasses.
  • Page 6 CARBON PILE BATTERY LOAD TESTER <500A 11) Load Testing the Battery WARNING: Ensure the battery load tester dial (4) is fully rotated anti-clokwise (can not rotate any further) before attaching or removing + or - battery clamps (5 & 6) to prevent arcing and potential explosion from battery gases. Always shield eyes and keep sparks, flames or cigarettes away from batteries.
  • Page 7 CARBON PILE BATTERY LOAD TESTER <500A 12) Battery Condition Analysis Table Load Test / 15 Seconds DC Volts Display Meter Details (Display Reading) OK (GREEN Area) Battery capacity is good. May or may not be fully charged. Check the charge state by testing the Specific Gravity (SG) with a Hydrometer.
  • Page 8 CARBON PILE BATTERY LOAD TESTER <500A 14) Testing the Vehicles Starter Motor Note: The vehicles engine MUST be OFF, at normal operating temperature and the vehicles battery should be fully charged before doing this test. Caution: Ensure the battery load tester dial (4) is fully rotated anti-clokwise (can not rotate any further) before performing this test.
  • Page 9 (12 months) commences on the date that the product is purchased. If this product has materials or workmanship defects (other than defects caused by abnormal or non warranted use) you can, at your cost, send the product to place of purchase, an authorised Kincrome service agent or one of Kincromes addresses for repair or replacement.
  • Page 10 CARBON PILE BATTERY LOAD TESTER <500A Notes:...
  • Page 11 CARBON PILE BATTERY LOAD TESTER <500A...
  • Page 12 www.kincrome.com.au...
