Summary of Contents for Dreadbox HYPNOSIS Time Effects Processor
-
Page 2: Table Of Contents
CONTENTS Overview ............3 Powering the unit ........4 Quick Start ..........5 Chorus-Flanger ..........6 Delay ............7 Master ............7 Spring reverb ..........8 LFO ............. 9 Patching examples ........10 Warranty ............. 11 Cautions ............. 11... -
Page 3: Overview
OVERVIEW Peak LED Chorus-Flanger This will blink when your signal LFO Rate LED is overdriving the circuit ACTIVE ACTIVE ACTIVE Spring Master Levels Chorus-Flanger Delay External LFO (This needs to be Reverb Controls patched) -
Page 4: Powering The Unit
POWERING THE UNIT Even though the Hypnosis is an analog effects unit, – Power the Hypnosis and all the devices connected it can be powered with a simple USB cable. If you to it, from the same mains power line. You should want the unit to have some extra mobility, you can use specifically avoid using different mains. -
Page 5: Quick Start
QUICK START GUIDE Connect an instrument to the IN patch. Connect the OUT patch to an Amplifier or Mixer. Start playing and set the IN slider so that the peak indicator (below the spring cut on the right) occasionally flashes. Set the OUT slider at your own preference. -
Page 6: Chorus-Flanger
THE CHORUS-FLANGER Difference between Chorus and Flanger Turns the effect ON or OFF. ACTIVE: Both Chorus and Flanger are actually quite Expects a pulse 5V, in ACTIVE PATCH: similar effects: It is a Delay that its time is order to be activated. modulated by an LFO. -
Page 7: Delay
THE DELAY THE MASTER Turns the effect ON ACTIVE: section is where master or OFF. you set up your audio levels. Please note that if the unit is Expects ACTIVE PATCH: clipping, then the INPUT is a 5V pulse, in order to be activated. responsible for it and you need Sets the balance between MIX:... -
Page 8: Spring Reverb
THE SPRING REVERB What is a Spring Reverb? A Spring Reverb is the broadband resonance Turns the effect ON or OFF. ACTIVE: that is generated when vibrating a metal coil, Expects a 5V pulse, in ACTIVE PATCH: order to be activated. which is held under tension. -
Page 9: Lfo
THE LFO This part of Hypnosis, is an extra LFO, that is not connected anywhere unless it is patched. It has 4 different waveforms, that can be circled via the WAVE button: –Triangle –Square (when LAG=0%, it can be also used to activate an effect through its patch). –Random (the classic Sample &... -
Page 10: Patching Examples
PATCHING EXAMPLES Triggering effects Modulated Delay Set the LFO: Set the LFO: WAVE = Square WAVE = Triangle LAG = 0% LAG = 0% RATE = About 1 sec circle to start with RATE = About 0,5 sec circle to start with LVL = MAX LVL = 10% Then send the... -
Page 11: Warranty
Dreadbox to be the fault of the user, are not covered by vibrations. this warranty (normal service rates will be applied).
