LD MAILA COL User Manual page 9

Use the optionally available EasyMount+ flying bracket for truss mounting (item number LDMAILATMB).
To secure the MAILA COL speaker column during truss mounting, there is an M10 thread
on the back of the enclosure in the recessed grip 1 .
Remove the inserted blind screw using a suitable tool. An M10 eyebolt is included in
the scope of delivery of the MAILA COL. Screw the eyebolt into the now free thread and
make sure it is firmly fixed. Use a suitable safety rope to secure the speaker column
1
and also take into account the total weight of the satellite speakers mounted on the
column.
NOTE
The satellites do not need to be secured by a safety rope, as the SmartLink+®
connection meets the criteria for inherent safety.
However, if desired, the satellite speakers can be secured using the second M10 thread
2
on the speaker column if desired.
2
9
