  • Page 1 Commissioning Manual 03/2006 Edition sinamics SINAMICS S120...

  • Page 3: Commissioning Manual

    System Overview Preparations for Commissioning Commissioning SINAMICS S120 PROFIdrive PROFIBUS Commissioning Manual SINAMICS Safety Integrated Diagnostics Basic Information about the Drive System Motor/Encoder Code Lists Availability of HW Components List of Abbreviations References Index Valid for Drive Firmware release SINAMICS S120...
  • Page 4 Registered trademarks All of the designations with the trademark R are registered trademarks of Siemens AG. Other names used in this publication may be trademarks, which, if used by third parties for their own means, may violate the rights of their owners.
  • Page 5 SIZER configuration tool Configuration Manuals, Motors Decision/ordering SINAMICS S Catalogs Installation/assembly SINAMICS S120 Equipment Manual SINAMICS S120 Equipment Manual Control units and additional system components SINAMICS S120 Equipment Manual Booksize power sections SINAMICS S120 Equipment Manual Chassis power sections SINAMICS S120 Equipment Manual AC DRIVE ©...
  • Page 6 SINAMICS S drive system. Objective The Commissioning Manual describes all the procedures and operational instruc- tions required for commissioning and servicing SINAMICS S120. The Commissioning Manual has the following structure: Chapter 1 System overview...
  • Page 7 For reasons of clarity, this documentation does not contain all of the detailed infor- mation on all of the product types. This documentation cannot take into consider- ation every conceivable type of installation, operation and service/maintenance. © Siemens AG 2006 All Rights Reserved SINAMICS S120 Commissioning Manual, 03/2006 Edition...
  • Page 8 Questions on the manual Up–to–date information about our products can be found on the Internet at the following address: http://www.siemens.com/motioncontrol Internet address for SINAMICS http://www.siemens.com/sinamics © Siemens AG 2006 All Rights Reserved viii SINAMICS S120 Commissioning Manual, 03/2006 Edition...
  • Page 9 Adjustable parameter 795, bit 4 Notation for faults and alarms (examples): S F12345 Fault 12345 S A67890 Alarm 67890 General notation: S The sign ”8” means ”is equal to” © Siemens AG 2006 All Rights Reserved SINAMICS S120 Commissioning Manual, 03/2006 Edition...
  • Page 10 – The measuring device is grounded (with a protective conductor, for example). – The measuring head has been temporarily discharged before measurements are taken on a floating measuring device (e.g. touching a bare metal controller housing). © Siemens AG 2006 All Rights Reserved SINAMICS S120 Commissioning Manual, 03/2006 Edition...
  • Page 11 Only protective extra–low voltages (PELVs) that comply with EN60204–1 must be connected to all connections and terminals between 0 and 48 V. © Siemens AG 2006 All Rights Reserved SINAMICS S120 Commissioning Manual, 03/2006 Edition...
  • Page 12 Motors must be connected in accordance with the circuit diagram provided, otherwise they can be destroyed. Note When operated in dry operating areas, SINAMICS equipment with AC motors conforms to low–voltage Directive 73/23/EEC. © Siemens AG 2006 All Rights Reserved SINAMICS S120 Commissioning Manual, 03/2006 Edition...
  • Page 13 ......3-77 © Siemens AG 2006 All Rights Reserved xiii SINAMICS S120 Commissioning Manual, 03/2006 Edition...
  • Page 14 ........5-197 © Siemens AG 2006 All Rights Reserved SINAMICS S120 Commissioning Manual, 03/2006 Edition...
  • Page 15 ..........7-284 © Siemens AG 2006 All Rights Reserved SINAMICS S120 Commissioning Manual, 03/2006 Edition...
  • Page 16 ..........A-384 © Siemens AG 2006 All Rights Reserved SINAMICS S120 Commissioning Manual, 03/2006 Edition...
  • Page 17 ..............E-403 © Siemens AG 2006 All Rights Reserved xvii...
  • Page 18 Table of Contents Space for your notes © Siemens AG 2006 All Rights Reserved xviii SINAMICS S120 Commissioning Manual, 03/2006 Edition...

  • Page 19: System Overview

    System Overview Application SINAMICS is the new range of drives from Siemens designed for mechanical and plant engineering applications. SINAMICS offers solutions for all drive tasks: S Simple pump and fan applications in the process industry. S Complex individual drives in centrifuges, presses, extruders, elevators, as well as conveyor and transport systems.
  • Page 20 S SINAMICS S handles complex drive tasks with synchronous/induction motors and fulfills stringent requirements regarding – Dynamics and accuracy, – Integration of extensive technological functions in the drive control system. © Siemens AG 2006 All Rights Reserved 1-20 SINAMICS S120 Commissioning Manual, 03/2006 Edition...
