Toshiba Satellite L35-S2366 Specifications

Satellite L35 Detailed Product Specification
Model Name
: L35-S2366
C1 2
Operating System
• Genuine Windows Vista™ Home Basic (32-bit version)
Processor and Chipset
• Intel® Pentium® dual-core processor T2060
o 1.60GHz, 1MB L2, 533MHz FSB
• ATI Radeon® Xpress 200M Chipset
4
Memory
• Configured with 512MB PC4200 DDR2 SDRAM (both memory slots
may be occupied). Maximum capacity 2048MB
5
Hard Disk Drive
• 80GB (5400RPM); Serial ATA hard disk drive; 9.5mm height; user
removable
Fixed Optical Disk Drive
• DVD SuperMulti (+/-R double layer) drive supporting 11 formats
o Maximum speed and compatibility: CD-ROM (24x), CD-R (4x),
CD-RW (10x), DVD-ROM (8x), DVD-R (Single Layer, (8x)),
DVD-R (Double Layer, (2x)), DVD-RW (4x), DVD+R (Single
Layer, (8x)), DVD+R (Double Layer, (2.4x)), DVD+RW (4x),
DVD-RAM (5x)
7
Display
• 15.4" diagonal widescreen TFT LCD display at 1280x800 native
resolution (WXGA)
o Native support for 720p content
8
Graphics
• ATI Radeon® Xpress 200M 8MB-128MB dynamically allocated
shared graphics memory
Sound
• Built-in stereo speakers
Input Devices
• 84 key US keyboard
Communications
• Modem 9
• 10/100 Base-TX Ethernet
• Integrated Wi-Fi® compliant wireless:
o Atheros® 802.11b/g wireless-LAN
Expandability
• 2 main memory slots. Both slots may be occupied.
• One PCMCIA – Type II/Type I Card Slot
Ports
• Video
o RGB (monitor) output port
• Audio
o Microphone input port
o Headphone output port
• Data
o USB v2.0 – 2 ports
Physical Description
• Dimensions (WxDxH Front/H Rear): 14.1" x 10.3" x 1.46 without feet
• Weight: Starting at 5.1 lbs depending upon configuration
• LCD Cover Color: Silver
Power
• 65W (19V x 3.42A) 100-240V AC Adapter.
o Dimensions (WxDxH): 4.25" x 1.16" x 1.85"
o Weight: starting at 0.56 lbs
12
Battery
• 2000mAh Lithium Ion battery pack
o Dimensions (WxDxH): 8.10" x 0.78" x 2.40"
o Weight: starting at 0.60 lbs
Part Number:
3
6
10
© Copyright 2006 – 2007 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Satellite L35-S2366 BTS Rev. 1.00 2007-03-02 MCL T20070214 CB1.10
This product specification is variable and subject to change prior to product launch.
1
PSL33U-03W02K
Environmental Specifications
13
Temperature
Thermal Gradient
Relative Humidity
(non-condensing)
Altitude
(relative to sea level)
Shock
Vibration
• This product is RoHS
SATELLITE – 1 YEAR STANDARD LIMITED
WARRANTY
Service Upgrades and Extensions
Toshiba offers many different enhanced services such as SystemGuard®,
On-Site Repair, and ServiceExpress to provide additional support to your
notebook PC. For a full description and complete list of programs and
program terms and conditions, please visit www.pcsupport.toshiba.com.
Recommended Services
Extended Service Plan
Provides an extended service plan for up to 4 total years from the original
notebook purchase date.
Part Number
WSN-PEQQ2V
WSN-PEQQ3V
WSN-PEQQ4V
SystemGuard Accidental Damage Service w/ ServiceExpress
Provides advanced protection from damage caused from handling. Select
your express repair service with either Depot Express or Carry-In Express
and go to the front of the line. Extended Service Plan included except with 1
Year plan. SystemGuard coverage must be purchased within the first 30
days of notebook purchase.
Part Number
WSN-PSGP1V
WSN-PEGP2V
WSN-PEGP3V
SystemGuard Accidental Damage Service + On-Site Repair
Combines SystemGuard and Business On-Site Repair coverage. Extended
Service Plan included except with 1 Year plan. SystemGuard coverage
must be purchased within the first 30 days of notebook purchase.
Part Number
WSN-PSGN1V
WSN-PEGN2V
WSN-PEGN3V
ServiceExpress
Select your express repair service with either Depot Express or Carry-In
Express. Depot Express: Your notebook will be repaired and returned via
11
overnight shipment (excluding weekends and holidays). Carry-In Express:
Take your notebook into a Premier ASP and go to the front of the line for
expedited repair service. Extended Service Plan included except with 1
Year plan.
Part Number
WSN-PSQP1V
WSN-PEQP2V
WSN-PEQP3V
On-Site Repair Service
UPC:
Operating
5° to 35° C
(41° to 95° F)
15° C per hour (max)
20% to 80%
0 to 3,000 meters
10G
0.5G
14
compatible
15
Description
2nd Year Extended Service Plan
2nd/3rd Year Extended Service Plan
2nd/3rd/4th Year Extended Service Plan
Description
1st Year
1st/2nd Year + Extended Service Plan
1st/2nd/3rd Year + Extended Service Plan
Description
1st Year
1st/2nd Year + Extended Service Plan
1st/2nd/3rd Year + Extended Service Plan
Description
1st Year
1st/2nd Year + Extended Service Plan
1st/2nd/3rd Year + Extended Service Plan
032107833227
Non-operating
-20° to 65° C
(-4° to 149° F)
20° C per hour (max)
10% to 95%
-60 to 10,000 meters
60G
1.0G
16
16
Page 1 of 4
