- Page 1 Kompakt Solid fuel boiler User manual Maintenance and installation JSC Aukstaitijos katilai www.highland-heat.com Linų str. 85, Ukmerge, Lithuania +370 683 33 388 | info@highland-heat.com...
-
Page 2: Table Of Contents
Kompakt Table of content Safety provisions 1. Introduction 1.1. General information 1.2. Standards and regulations 2. Technical parameters 3. Construction 3.1. Boiler components 3.2. Boiler 3.3. Boiler set 4. Boiler installation 4.1. General information 4.2. Boiler location and position 4.3. Connecting the boiler to the chimney 4.4. -
Page 3: Safety Provisions
Kompakt Safety provisions During the use of the boiler, its individual parts: chimney, door, individual points of the body - can heat up and cause burns if touched. Do not allow children to touch or use the boiler without adult supervision. -
Page 4: Introduction
The enlarged loading opening makes it possible to load larger firewood. Kompakt - small but powerful boilers suitable for burning wetter fuel. Before connecting the boiler to the heating system, read this manual carefully and check that all boiler components and equipment are working properly. -
Page 5: Technical Parameters
Kompakt 2. Technical parameters Models and power output 12 kW 16 kW 20 kW Heated area iki m Combustion chamber load l/dm Combustion chamber depth Combustion chamber opening size 29x23 29x23 29x23 Heat exchanger area Number of horizontal heat exchangers... -
Page 6: Construction
Kompakt 3. Construction 3.1 Boiler components 1. Chimney 8. Thermometer 2. Heat exchanger 9. Cleaning door 3. Combustion chamber 10. Ignition valve 4. Cast iron grates 11. Door handle 5. Return branch pipe 12. Fuel loading door 6. Adjustable legs 13. -
Page 7: Boiler
Kompakt 3. Construction 3.2 Boiler The boiler heat exchanger consists of three main zones. Two (three 20 kW) horizontal heat exchangers (2) are located in the area of the upper door. The cleaning door (9) is used when it is necessary to clean the surface of the heat exchanger. -
Page 8: Boiler Installation
Kompakt boilers are delivered to the buyer fully assembled, but the thermometer and chain mounting plate are not installed in order to avoid damage during transportation. -
Page 9: Connecting The Boiler To The Chimney
Kompakt 4. Boiler installation 4.3 Connecting the boiler to the chimney The chimney must be installed to meet the requirements of the country where it is installed. The recommended chimney draft is 15-20 Pa. The minimum chimney liner recommended by the boiler manufacturer dimensions are: •... -
Page 10: Recommended Connection Diagrams
Kompakt 4. Boiler installation 4.5 Recommended connection diagrams With four-way valve 1. Small perimeter pump 2. Big perimeterpump 3. Boiler pump 4. Four-way valve 5. Reverse valve 6. Boiler With 4-way valve for older (gravity) systems: 1. Small perimeter pump 2. -
Page 11: Changing The Door Direction
Kompakt 4. Boiler installation 4.6 Changing the door direction 1. Screw DIN 912 M10x16 4. Door handle 2. Screw DIN 912 M10x12 5. Spring washer 3. Eccentric M10 6. Screw DIN 912 M8x14 The direction of the upper and middle doors is changed by turning the door together with the hinge (hinges) away from the boiler body and screwing it on the opposite side of the boiler. -
Page 12: Adjustment Of The Air Supply Valve
Kompakt 4. Boiler installation 4.7 Adjustment of the air supply valve The draft regulator automatically operates the air valve in front of the lower door by chain. During combustion, when the temperature rises, the damper is closed, and when it falls, it is opened. -
Page 13: Using The Boiler
Wood. The boiler will reach the power specified in the technical parameter table if you burn wood with a moisture content of no more than 20%. However, the Kompakt design allows for the burning of wetter wood as well. The burning duration depends on the amount of fuel charged, its quality, outdoor and indoor temperature, the building’s thermal resistance, the... -
Page 14: Ignition
Kompakt 5. Using the boiler 5.3 Ignition 1) Check the water pressure and tightness of the boiler and system. 2) Check the draft and the condition of the smoke channels. 3) Clean the boiler ash grates, smoke channels and internal side walls of the boiler. -
Page 15: Boiler Operation
Kompakt 5. Using the boiler 5.4 Boiler operation 1) Depending on the heat demand and burning intensity, refuel periodically. 2) When leaving the boiler to operate during the night, the air supply valve can be set - thereby reducing the boiler power. But... -
Page 16: Warranty Conditions
Kompakt 6. Warranty conditions When selling the boiler, the seller must familiarize the buyer with the terms of the warranty. 1. The manufacturer provides: • 4-year warranty for the tightness of the boiler heat exchanger. • 2-year warranty for the included parts. -
Page 17: Efficiency And Emissions
List of equivalent models Kompakt 12, Kompakt 20 SP – solid particles, GOC – Gaseous organic compounds, CM – carbon monoxide NOx - nitrogen oxides, ηs - Seasonal energy consumption efficiency for space heating (Efficiency factor - 3%) ηn - Seasonal energy consumption efficiency for space heating at maximum power... - Page 18 Kompakt Notes...
- Page 19 Kompakt Notes...
- Page 20 www.highland-heat.com +370 683 33 388 | info@highland-heat.com...
