Maintenance guide – Dust box, guide plate,
driving wheel cleaning
[Install guide plate]
There are 2 gaps on one side of guide
plate. Place this side face-in. Then, insert
the guide plate into robot and push it
upward to finish the install.
4
[Dust box]
Insert the dust box, close the lower shell
and lock the buckle.
5
Vacuum 40
[Driving wheel]
Check the shaft of driving wheel, clean any
debris or hairs wrapping around the shaft to
avoid blocking driving wheel.
6
